APKITKP Manual.qxp_Layout 1 28/01/2016 11:45 Page 4
Installation
90 。
Site the door station a
The camera needs to point in
Avoid areas of high sunlight
Surface mount the sunshield of the door station and
recommended 1.5 meters from
the direction of where a visitor
and noise levels.
connect the system cabling. Mount the camera to the
the ground, or to suit application.
will stand during operation.
sunshield by fixing with the supplied hex screw.
1-Gang Mount Box
(if required, not supplied)
Monitor
Monitor Mounting
Bracket
Site the indoor monitor to suit application.
Surface mount the bracket of the monitor or if required onto a 1-gang mount box (not supplied).
Make the system connections to the back of the monitor and then slide the monitor onto the
bracket using the hooks to hold firmly in place.
4
