  • Page 1 A P K I T A O | A U D I O D O O R E N T R Y S Y S T E M A P K I T A O H | A D D I T I O N A L S Y S T E M H A N D S E T U S E R M A N U A L w w w .

  • Page 2: Table Of Contents

    Contents Installation ............... 3 Step 1 .

  • Page 3: Installation

    Installation Step 2 Step 1 Site the door station a recommended 1.5 meters from the ground, Site the handset to suit application. or to suit application. Surface mount the bracket, make the system connections The door station needs to point in the direction of where a visitor to the back of the handset and then slide the handset onto the will stand during operation.

  • Page 4: System Connections Example 1

    System Connections Example 1 Handset Door Station 100 metres Total cable run should not exceed 100 meters between door station and handset 3 and 4 Terminals 3 and 4 are Normally Open, Volt-Free contact for lock release APKITAO & APKITAOH Manual.indd 4 18/05/2016 15:28:34...

  • Page 5: System Connections Example 2

    System Connections Example 2 Handset #2 Handset Door Station 100 metres Total cable run should not exceed 100 meters between door station and handset Maximum 2 handsets to 1 door station is the maximum system configuration APKITAO & APKITAOH Manual.indd 5 18/05/2016 15:28:35...

  • Page 6: User Guide

    User Guide The visitor presses the call A chime Lift up receiver button will sound and begin conversation Then choose between the 2 options; Press the ‘Lock’ button Replace receiver to release lock and to end call replace receiver APKITAO & APKITAOH Manual.indd 6 18/05/2016 15:28:35...
  • Page 7 Product Image APKITAO & APKITAOH Manual.indd 7 18/05/2016 15:28:35...
  • Page 8 Elite Security Products Unit 7, Target Park, Shawbank Rd Lakeside, Redditch B98 8YN Telephone: 01527 51 51 50 Fax: 01527 51 51 43 Web: www.espuk.com E&OE - Errors and omissions excepted.D16 w w w . e s p u k . c o m APKITAO &...
