System Components
Blue User Tag
Allows holder to release the door
Green Programming Tag
Allows holder to ADD
additional user tags
APDSPXMW
APPOWMW
APSEPMW
APBC4MW
Red Programming Tag
Multi-Way Door Station
System Power Supply Unit
Power Supply Seperator
System Branch Controller
Allows holder to REMOVE
additional user tags
Site the door station a
The camera needs to point in
Avoid areas of
Surface mount the sunshield of the door station and
recommended 1 .5 meters from the
the direction of where a visitor
high sunlight and
connect the system cabling . Mount the camera to the
ground, or to suit application .
will stand during operation .
noise levels .
sunshield by fixing with the supplied hex screw .
3
APDSPXMW Manual.indd 3
23/01/2018 10:11:03
