User Guide

A
The visitor
presses the
call button
A chime will sound
Using the lock release code
Enter
4 digit lock
release code
10
B C
The visitor's image will
appear on the monitor
Press
The lock
will release
Preview Lock
Press once to view Press once
door station image to release lock
Chime Volume: Slide switch for High, Medium and Low setting
Chime Selection: Press button to select chime melody
Monitor Brightness: Adjustment for brightness levels
Monitor Chroma: Adjustment for the intensity of colour
Talking Volume: Adjust the volume level of the monitor
D Then choose between these 3 options
Press the 'Talk' Press the
button and 'Talk' button
begin conversation to end call
Gate Talk
Press once Press once
to release lock 2 to talk to visitor
Press the 'Lock' button Press the 'Gate' button
to release lock and to release lock 2 and
press 'Talk' to end call press 'Talk' to end call
