Server Technology switched pro2 User Manual page 99

Custom User Certificate Messages
Message
Cert & Key
Cert
No Cert
Factory Encrypted
None
4. Installed Certificate: Shows the type of certificate that was installed – Factory, User, Company.
To configure Sentry Power Manager (SPM) options:
The Sentry Power Manager (SPM) is Server Technology's enterprise management software product for the data
center. The configuration options provided allow you to enable/disable SPM and reset the SPM password to its
default.
1. SPM Secure Access: Check (or uncheck) the Enable checkbox to enable/disable SPM Secure Access. If
your operation does not currently use SPM, you can disable this option. However, when the option is
disabled, the PRO2 will not be able to use the secure network features or advanced remote configuration
provided by SPM.
2. SPM Password: Each PRO2 unit has a unique default SPM password that communicates between SPM
and the PRO2. For added security, when SPM discovers a PRO2 in the network, SPM changes the default
password to a different (and unique) password and continues to manage or alter passwords as required for
on-going system security. To reset the SPM password, click the Reset button.
3. Click Apply.
Notes:
•
The SPM options apply only if you are currently using SPM.
•
Both HTTP and HTTPS/SSL must be enabled or the SPM Secure Access will not be allowed. When
allowed, the SPM Secure Access checkbox is enabled by default.
•
Do not reset the SPM Password if SPM communication has already been established.
Using the Web Interface
Description and Valid Values/Range
Both the user certificate and its key were uploaded successfully.
User certificate was uploaded without a key.
User certificate was not uploaded.
User certificate was encrypted and uploaded at product assembly.
Neither the user certificate nor its key were uploaded.
Switched PRO2 – User Guide
•
99
