Outlet State/Control State Descriptions
The following table shows the differences between outlet state and control state
•
The outlet state is the current operating state of the outlet.
•
The control state is the last user-issued control action on the outlet.
Outlet State Control State
On On
Off Off
Off Pend On
Off Reboot
On Idle On
On Idle Off
On Wake On
Off Wake Off
On/Wait Off
Off/Wait On
On/Error (varies)
Off/Error (varies)
Off/Fuse On
On/Fuse On
No Comm (varies)
Using the Web Interface
Description
Outlet is on.
Outlet is off.
Outlet is off and about to turn on in response to a sequence timer.
Outlet is off and a Reboot action has been initiated.
A restart has occurred – last control state has been maintained.
A restart has occurred – last control state has been maintained.
A power-loss has occurred – wakeup state has been applied.
A power-loss has occurred – wakeup state has been applied.
Outlet state in transition – re-query of outlet status required.
Outlet state in transition – re-query of outlet status required.
Error state – outlet should be off but current is sensed at the outlet.
Error state – outlet should be on but no current is sensed at the outlet.
Outlet should be on but a blown fuse has been detected.
Outlet should be on but a blown fuse has been detected downstream
Communication to the outlet has been lost – control state will be
applied when communication is re-established.
