Sub-System Status
This Sub-System section of the Summary page provides a quick status view of the current operational state of
major PRO2 areas (units, cords, branches, etc.) showing a color-coded status icon.
Also provided is a link from each of the sub-system areas to the related monitoring page:
Click the name of one of the PRO2 system areas to display
its corresponding Monitoring page.
Using the Web Interface
View detailed operating status on the Monitoring page.
