Installing the Camera on a
Desktop
Set the DIP switch prior to installing the camera.
0
Place the camera on a flat surface.
0
Be sure to place the base of the camera
0
horizontally. The camera will not operate
properly if it is slanted.
Memo :
The use of ceiling mount bracket is not required.
0
Caution :
Do not move the camera while the power of the
0
system is on. Doing so may result in
malfunctions or accidents.
Do not hold the camera head while carrying the
0
camera.
Connect the cables after these procedures.
24

Installing the Camera on a Desktop

Attaching the Camera to a
Tripod
Set the DIP switch prior to installing the camera.
0
Attach a tripod using the screw hole at the
0
bottom of this product.
(1/4-20UNC, ISO1222 (6.35 ㎜))
To prevent the camera recorder from falling off,
0
which may result in injuries or damages, read the
"INSTRUCTIONS" of the tripod to be used and
make sure that it is securely attached.
To ensure proper pan/tilt operation, set the
0
tripod such that the camera is parallel to the
horizontal surface.
Memo :
The use of ceiling mount bracket is not required.
0
Caution :
If the camera recorder exceeds the weight limit
0
of the tripod, do not mount it on the tripod.
Use the tripod on a stable surface.
0
Use screws with a screw length between 4.5 mm
0
and 7 mm.
Do not install the camera at a high location when
0
the camera is attached to a tripod.
Connect the cables after these procedures.
