Communication specification
Item
Protocol
Slave type
Device type
Product code
Vender ID
Applicable message
Node address setting range
Communication speed
Setting file: EDS file
(Please download from SMC website)
Occupied area
(Number inputs/Outputs)
Compatible valve series
EX120-SDN1(-X2/-X26/-X77)
EX121-SDN1(-X2/-X26/-X77)
EX122-SDN1(-X2/-X26/-X77)
EX124U/D-SDN1(-X2/-X26/-X77)
TM
DeviceNet
Volume1 (Edition 2.1)
Volume3 (Edition 1.0)
Group2 Only Server
EX12∗-SDN1/-X2: 16
EX12∗-SDN1-X26/-X77: 27
EX12∗-SDN1/-X2: 288
EX12∗-SDN1-X26/-X77: 1202
7h (SMC Corp.)
Duplicate MAC ID Check Message
Unconnected Explicit Message
Explicit Message
Poll I/O Message (Predefined M/S connection set)
0 to 63
125 kbps/250 kbps/500 kbps
EX12∗-SDN1/-X2 : ex12#-sdn1_22_v□.eds
EX12∗-SDN1-X26/-X77 : ex12#-sdn1_02_v□.eds
EX12∗-SDN1/-X2: 16/16
EX12∗-SDN1-X26/-X77: 0/16
SV1000, SV2000, SV3000, SV4000
VQ1000, VQ2000
SY3000, SY5000 (Connector connecting manifold)
SY3000, SY5000
SY3000, SY5000
VQ2000, VQ4000, VQ5000
-41-
Specifications
