TM
DeviceNet
○DeviceNet Objects
The SI unit supports the DeviceNet
∗: Hexadecimal value is used for □□h indication.
Class code
01h Identity
02h Message Router
03h DeviceNet
04h Assembly
05h DeviceNet
09h Discrete Output Point
0Fh Parameter
64h SMC SI (SMC Specific)
1. Identity Object (Class ID: 01h)
1-1. Class attribute
ID Access rule
- -
1-2. Class common service
Service code
-
1-3. Instance attribute
ID Access rule
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
Objects
TM
object classes below, with pneumatic valves as the device type.
Object class
TM
TM
Connection
Description
-
Service name
-
Description
Vender ID
Device Type
Product Code
Revision
Status
Serial Number
Product Name
Value
-
Value
07h
EX12∗-SDN1/-X2: 10h (16)
EX12∗-SDN1-X26/-X77: 1Bh (27)
EX12∗-SDN1/-X2: 120h (288)
EX12∗-SDN1-X26/-X77: 4B2h (1202)
Per unit
-
Per unit
Valve Manifold SIU
-21-
No.EX##-OME0015-C
