•Output condition setting during I/O connection time-out
1) The instant attribute value below is set to 1 via the network.
Class Instance
64h
(SMC)
or
Class Instance
0Fh
(Parameter)
2) Set the fault action and fault values via the network.
Fault setting method is the individual setting per output with DOP object.
Fault setting
Fault
action
Fault
value
∗: For details, refer to "Object mounting".
•Output condition setting when I/O connection is deleted
1) The instant attribute value is set to 1 via the network as indicated below.
Class Instance
64h
01h (01)
(SMC)
2) Set the fault action and fault values via the network.
Fault setting method is the individual setting per output with DOP object.
Fault setting
Fault
action
09h (DOP)
Fault
value
∗: For details, refer to "Object mounting".
Attribute
01h 68h (104)
Attribute
05h 01h
Class Instance
09h n
(DOP) (Output number+1)
Attribute
69h (105)
Class Instance
n
(Output number+1)
Description
Hold Clear
(Connection Delete)
Description
Hold Clear
(Connection Delete)
Attribute
05h
06h
Description
Hold Clear
(Connection Delete)
Attribute
05h
06h
-18-
Value
0: Switch No.9 setting valid
(Default)
1: Fault action valid
Value
0: Switch No.9 setting valid
1: Fault action valid
Value
0: Fault set value
1: Output held
0: CLEAR
1: SET
Value
0: Follow the setting of ID104
(Default)
1: CLEAR
Value
0: Fault set value
1: Output held
0: CLEAR
1: SET
No.EX##-OME0015-C
