SMC Networks EX120-SDN1-X2 Operation Manual page 16

○Settings via network (EX12∗-SDN1, EX12∗-SDN1-X2)
It is possible to set the output operation via the network, when a communication error is generated, in
accordance with the procedure below.
•
Output operation setting at the time of communication error
1) The instant attribute value below is set to 1 via the network
Class
64h
(SMC)
or
Class
0Fh
(Parameter)
2) Set the fault action and fault values via the network.
Fault setting method is the individual setting per output with DOP object.
Fault setting
Fault
action
Fault
value
∗: For details, refer to "Object mounting".
•Output condition setting when I/O connection is deleted
1) The instant attribute value below is set to 1 via the network.
Class
64h
(SMC)
2) Set the fault action and fault values via the network.
Fault setting method is the individual setting per output with DOP object.
Fault setting
Fault
action
Fault
value
∗: For details, refer to "Object mounting".
Instance Attribute
01h 68h (104)
Instance attribute
05h 01h
Class Instance
n
09h (DOP) (Output
number+1)
Instance attribute
01h (01) 69h (105)
Class Instance
n
09h (DOP) (Output
number+1)
Description
Hold Clear (Timeout)
Description
Hold Clear (Timeout)
Attribute
05h
06h
Description
Hold Clear
(Connection Delete)
Attribute
05h
06h
-15-
Value
0: Clear setting valid
(Default)
1: Fault action valid
Value
0: Clear setting valid
1: Fault action valid
Value
0: Fault set value
1: Output held
0: CLEAR
1: SET
Value
0: Follow the setting of
ID104 (Default)
1: CLEAR
Value
0: Fault set value
1: Output held
0: CLEAR
1: SET
No.EX##-OME0015-C
