5-4. Instance attribute2 (I/O: Poll message)
ID Access rule
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
8 Get
9 Get/Set
12 Get/Set
13 Get
14 Get
15 Get
16 Get
17 Get
5-5. Instance common service
Service code
0Eh
10h
Description
State
Instance_type
TransportClass_trigger
TM
DeviceNet _produced_connection_id
TM
DeviceNet _consumed_connection_id
TM
DeviceNet _initial_comm_characteristics
Produced_connection_size
Consumed_connection_size
Expected_packet_rate
Watchdog_timeout_action
Produced_connection_path_length
Produced_connection_path
Consumed_connection_path_length
Consumed_connection_path
Production_inhibit_time
Description
Get_Attribute_Single
Set_Attribute_Single
-26-
Value
-
01h
83h
-
-
01h
02h: EX12∗-SDN1/-X2
00h: EX12∗-SDN1-X26/-X77
02h
-
-
6: EX12∗-SDN1/-X2
0: EX12∗-SDN1-X26/-X77
20h, 04h, 24h, 05h, 30h, 03h:
EX12∗-SDN1/-X2
None: EX12∗-SDN1-X26/-X77
6
20h 04h 24h 23h 30h 03h
0
