6. Discrete Output Point Object (Class ID: 09h)
6-1. Class attribute
ID Access rule
- -
6-2. Class common service
Service code
-
6-3. Instance attribute
ID Access rule
3 Get/Set
4 Get
5 Get/Set
6 Get/Set
7 Get/Set
8 Get/Set
∗1: Hold the data in EEPROM.
6-4. Instance common service
Service code
0Eh
10h
6-5 Specific service
None.
Description
-
Description
-
Description
Value
Status
∗ 1
Fault Action
∗ 1
Fault Value
∗ 1
Idle Action
∗ 1
Idle Value
Description
Get_Attribute_Single
Set_Attribute_Single
Value
-
Value
0: OFF
1: ON
-: Unused
0: Fault value
1: Output held
0: CLEAR
1: SET
0: Idle value
1: Output held
0: CLEAR
1: SET
