Danfoss VLT AQUA FC 202 Operating Instructions Manual page 73

Specifications
3x525-600 V, Enclosure Types A, B, and C
Power Bussmann Bussman
[kW] Type RK1 n
Type J
0.75-1. KTS-R-5 JKS-5
1
1.5-2.2 KTS-R-10 JKS-10
3 KTS-R15 JKS-15
4 KTS-R20 JKS-20
5.5 KTS-R-25 JKS-25
7.5 KTS-R-30 JKS-30
11-15 KTS-R-35 JKS-35
18 KTS-R-45 JKS-45
22 KTS-R-50 JKS-50
30 KTS-R-60 JKS-60
37 KTS-R-80 JKS-80
45 KTS-R-100 JKS-100
55 KTS-R-125 JKS-125
75 KTS-R-150 JKS-150
90 KTS-R-175 JKS-175
Table 8.29 3x525-600 V, Enclosure Types A, B, and C
1) 170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted.
3x525-690 V, Enclosure Types B and C
Power Maximum Bussmann
[kW] prefuse E52273
[A] RK1/JDDZ
11-15 30 KTS-R-30
22 45 KTS-R-45
30 60 KTS-R-60
37 80 KTS-R-80
45 90 KTS-R-90
55 100 KTS-R-100
75 125 KTS-R-125
90 150 KTS-R-150
Table 8.30 3x525-690 V, Enclosure Types B and C
MG20MB02
Operating Instructions
Recommended maximum fuse
Bussmann Bussmann Bussman
Type T Type CC n
Type CC
JJS-6 FNQ-R-5 KTK-R-5
JJS-10 FNQ-R-10 KTK-R-10
JJS-15 FNQ-R-15 KTK-R-15
JJS-20 FNQ-R-20 KTK-R-20
JJS-25 FNQ-R-25 KTK-R-25
JJS-30 FNQ-R-30 KTK-R-30
JJS-35 - -
JJS-45 - -
JJS-50 - -
JJS-60 - -
JJS-80 - -
JJS-100 - -
JJS-125 - -
JJS-150 - -
JJS-175 - -
Recommended maximum fuse
Bussmann Bussmann
E4273 E4273
J/JDDZ T/JDDZ
JKS-30 JKJS-30
JKS-45 JJS-45
JKS-60 JJS-60
JKS-80 JJS-80
JKS-90 JJS-90
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
Danfoss A/S © Rev. 05/2014 All rights reserved.
Bussman SIBA Littel fuse
n Type RK1
Type CC
LP-CC-5 5017906-005 KLS-R-005
LP-CC-10 5017906-010 KLS-R-010
LP-CC-15 5017906-016 KLS-R-015
LP-CC-20 5017906-020 KLS-R-020
LP-CC-25 5017906-025 KLS-R-025
LP-CC-30 5017906-030 KLS-R-030
- 5014006-040 KLS-R-035
- 5014006-050 KLS-R-045
- 5014006-050 KLS-R-050
- 5014006-063 KLS-R-060
- 5014006-080 KLS-R-075
- 5014006-100 KLS-R-100
- 2028220-125 KLS-R-125
- 2028220-150 KLS-R-150
- 2028220-200 KLS-R-175
SIBA LittelFuse
E180276 E81895
RK1/JDDZ RK1/JDDZ
5017906-030 KLS-R-030
5014006-050 KLS-R-045
5014006-063 KLS-R-060
5014006-080 KLS-R-075
5014006-100 KLS-R-090
5014006-100 KLS-R-100
2028220-125 KLS-150
2028220-150 KLS-175
Ferraz- Ferraz-
Type RK1 Shawmut Shawmut
Type RK1 J
A6K-5-R HSJ-6
A6K-10-R HSJ-10
A6K-15-R HSJ-15
A6K-20-R HSJ-20
A6K-25-R HSJ-25
A6K-30-R HSJ-30
A6K-35-R HSJ-35
A6K-45-R HSJ-45
A6K-50-R HSJ-50
A6K-60-R HSJ-60
A6K-80-R HSJ-80
A6K-100-R HSJ-100
A6K-125-R HSJ-125
A6K-150-R HSJ-150
A6K-175-R HSJ-175
Ferraz- Ferraz-
Shawmut Shawmut
E163267/E2137 E2137
RK1/JDDZ J/HSJ
A6K-30-R HST-30
A6K-45-R HST-45
A6K-60-R HST-60
A6K-80-R HST-80
A6K-90-R HST-90
A6K-100-R HST-100
A6K-125-R HST-125
A6K-150-R HST-150
8 8
71
