Electrical Installation
4 4
1
9
1 PLC
2 Frequency converter
3 Output contactor
4 Grounding rail (PE)
5 Cable insulation (stripped)
Illustration 4.2 EMC-compliant Electrical Connection
NOTICE
EMC INTERFERENCE
Use screened cables for motor and control wiring and separate cables for input power, motor wiring, and control
wiring. Failure to isolate power, motor, and control cables can result in unintended behaviour or reduced performance.
Minimum clearance requirement between power, motor and control cables is 200 mm (7.9 in).
14
Operating Instructions
10
L1
L2
L3
PE
Danfoss A/S © Rev. 05/2014 All rights reserved.
2
11
8
6 Cable gland
7 Motor, 3-phase and PE
8 Mains, 3-phase and reinforced PE
9 Control wiring
10
Equalising min. 16 mm
6
3
4
7
2
(0.025 in)
MG20MB02
5
U
V
W
PE
