Danfoss VLT AQUA FC 202 Operating Instructions Manual page 71

Specifications
3x200-240 V, Enclosure Types A, B, and C
Power [kW] Bussmann
Type RK1 1)
0.25-0.37 KTN-R-05
0.55-1.1 KTN-R-10
1.5 KTN-R-15
2.2 KTN-R-20
3.0 KTN-R-25
3.7 KTN-R-30
5.5-7.5 KTN-R-50
11 KTN-R-60
15 KTN-R-80
18.5-22 KTN-R-125
30 KTN-R-150
37 KTN-R-200
45 KTN-R-250
Table 8.25 3x200-240 V, Enclosure Types A, B, and C
Power SIBA
[kW] Type RK1
0.25-0.37 5017906-005
0.55-1.1 5017906-010
1.5 5017906-016
2.2 5017906-020
3.0 5017906-025
3.7 5012406-032
5.5-7.5 5014006-050
11 5014006-063
15 5014006-080
18.5-22 2028220-125
30 2028220-150
37 2028220-200
45 2028220-250
Table 8.26 3x200-240 V, Enclosure Types A, B, and C
1) KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
2) FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
3) A6KR fuses from Ferraz-Shawmut may substitute A2KR for 240 V frequency converters.
4) A50X fuses from Ferraz-Shawmut may substitute A25X for 240 V frequency converters.
MG20MB02
Operating Instructions
Recommended maximum fuse
Bussmann Bussmann
Type J Type T
JKS-05 JJN-05
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
KS-50 JJN-50
JKS-60 JJN-60
JKS-80 JJN-80
JKS-125 JJN-125
JKS-150 JJN-150
JKS-200 JJN-200
JKS-250 JJN-250
Recommended maximum fuse
Littel fuse Ferraz-
Type RK1 Shawmut Shawmut
Type CC
Type RK1
KLN-R-05 ATM-R-05 A2K-05-R
KLN-R-10 ATM-R-10 A2K-10-R
KLN-R-15 ATM-R-15 A2K-15-R
KLN-R-20 ATM-R-20 A2K-20-R
KLN-R-25 ATM-R-25 A2K-25-R
KLN-R-30 ATM-R-30 A2K-30-R
KLN-R-50 - A2K-50-R
KLN-R-60 - A2K-60-R
KLN-R-80 - A2K-80-R
KLN-R-125 - A2K-125-R
KLN-R-150 - A2K-150-R
KLN-R-200 - A2K-200-R
KLN-R-250 - A2K-250-R
Danfoss A/S © Rev. 05/2014 All rights reserved.
Bussmann
Type CC
FNQ-R-5
FNQ-R-10
FNQ-R-15
FNQ-R-20
FNQ-R-25
FNQ-R-30
-
-
-
-
-
-
-
Ferraz- Bussmann Littel fuse
JFHR2
Type JFHR2 2)
3)
FWX-5
FWX-10
FWX-15
FWX-20
FWX-25
FWX-30
FWX-50
FWX-60
FWX-80
FWX-125
FWX-150 L25S-150
FWX-200 L25S-200
FWX-250 L25S-250
Bussmann Bussmann
Type CC
KTK-R-5 LP-CC-5
KTK-R-10 LP-CC-10
KTK-R-15 LP-CC-15
KTK-R-20 LP-CC-20
KTK-R-25 LP-CC-25
KTK-R-30 LP-CC-30
- -
- -
- -
- -
- -
- -
- -
Ferraz- Ferraz-
Shawmut Shawmut
4) J
JFHR2
- - HSJ-6
- - HSJ-10
- - HSJ-15
- - HSJ-20
- - HSJ-25
- - HSJ-30
- - HSJ-50
- - HSJ-60
- - HSJ-80
- - HSJ-125
A25X-150 HSJ-150
A25X-200 HSJ-200
A25X-250 HSJ-250
8 8
