Specifications
Type designation
1)
High/normal overload
Typical shaft output [kW]
Typical shaft output at 208 V [hp]
6)
IP20/Chassis
IP21/Type 1
IP55/Type 12
IP66/NEMA 4X
Output current
Continuous (3x200-240 V) [A]
Intermittent (3x200-240 V) [A]
Continuous kVA at 208 V [kVA]
Maximum input current
Continuous (3x200-240 V) [A]
Intermittent (3x200-240 V) [A]
Maximum pre-fuses [A]
Additional specifications
IP20 maximum cable cross-section for mains,
brake, motor, and load sharing
[mm 2 ] ([AWG])
IP21, IP55, IP66 maximum cable cross-section
2
for mains and motor [mm ] ([AWG])
IP21, IP55, IP66 maximum cable cross-section
for brake, and load sharing [mm
2)
Maximum cable cross-section for
2
disconnect [mm ] ([AWG])
3)
Estimated power loss at rated maximum
load [W]
Efficiency 4)
Table 8.5 Mains Supply 3x200-240 V AC, P18K-P45K
For fuse ratings see chapter 8.8 Fuses and Circuit Breakers.
1) High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
2) The 3 values for the maximum cable cross-section indicate single core, flexible wire, and flexible wire with sleeve, respectively.
3) The typical power loss is at normal load conditions and expected to be within
conditions).
Values are based on typical motor efficiency. Lower efficiency motors will also add to the power loss in the frequency converter and vice versa.
If the switching frequency is raised from nominal, power losses may rise significantly.
LCP and typical control card power consumption is included. Further options and customer load may add up to 30 W to the losses. (Though
typically only 4 W extra each for options for slot A or B, or for a fully loaded control card).
Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be allowed for (
4) Measured using 5 m screened motor cables at rated load and rated frequency.
5) Enclosure types A2+A3 can be converted to IP21 using a conversion kit. See also Mechanical mounting and IP21/Type 1 Enclosure kit in the
Design Guide.
6) Enclosure types B3+B4 and C3+C4 can be converted to IP21 using a conversion kit. See also Mechanical mounting and IP21/Type 1 Enclosure
kit in the Design Guide.
MG20MB02
Operating Instructions
P18K
HO NO
15 18.5
20 25
B4
C1
59.4 74.8
89.1 82.3
21.4 26.9
54.0 68.0
81.0 74.8
125
35 (2)
50 (1)
50 (1)
2
] ([AWG])
624 737
0.96
