IVS-300 Embedded System
IVS-300 Embedded System
MODEL:
MODEL:
IVS-300
IEI Fanless Embedded System with Intel® Skylake ULT /
Baytrail Processor, 4 GB DDR3L, Quad GbE LAN with PoE,
On-board GPS, HDMI, VGA, Dual SSD Bay, RoHS Compliant,

User Manual

Page i
Rev. 1.00 – October 5, 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVS-300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology IVS-300

Summary of Contents for IEI Technology IVS-300

  • Page 1: User Manual

    IVS-300 Embedded System IVS-300 Embedded System MODEL: MODEL: IVS-300 IEI Fanless Embedded System with Intel® Skylake ULT / Baytrail Processor, 4 GB DDR3L, Quad GbE LAN with PoE, On-board GPS, HDMI, VGA, Dual SSD Bay, RoHS Compliant, User Manual Page i...
  • Page 2 IVS-300 Embedded System Revision Date Version Changes October 5, 2016 1.00 Initial release Page ii...

  • Page 3: Safety Instructions

    IVS-300 Embedded System Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
  • Page 4 IVS-300 Embedded System Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur Folge haben.
  • Page 5 IVS-300 Embedded System Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 6: Manual Conventions

    IVS-300 Embedded System Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 7: Table Of Contents

    IVS-300 Embedded System Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 B ........................2 ENEFITS 1.3 F ........................3 EATURES 1.4 M ....................3 ODEL ARIATIONS 1.5 F ......................4 RONT ANEL 1.5.1 LED Indicators....................4 1.6 R...
  • Page 8 IVS-300 Embedded System 3.10 E I/O C ................. 30 XTERNAL ONNECTORS 3.10.1 COM Port Connection ................... 30 3.10.2 DIO and RS-422/485 (COM6) Connection............ 31 3.10.3 OBD-II Connection..................32 3.10.4 GPS Speed Pulse/Direction Connection ............33 3.11 P ..................33 OWER ROCEDURE 3.11.1 Installation Checklist..................
  • Page 9 IVS-300 Embedded System 4.5 S ......................... 64 ECURITY 4.6 B ........................65 4.7 S & E ......................67 5 TROUBLESHOOTING AND MAINTENANCE ............. 69 5.1 IVS-300 S ............70 YSTEM AINTENANCE VERVIEW 5.2 S ..................70 YSTEM ROUBLESHOOTING 5.2.1 The System Doesn’t Turn On ................70 5.2.2 The System Doesn’t Boot Up................
  • Page 10 IVS-300 Embedded System List of Figures Figure 1-1: IVS-300 Series Embedded System ................2 Figure 1-2: Front Panel ........................4 Figure 1-3: LED Indicators......................4 Figure 1-4: Rear Panel........................5 Figure 1-5: Bottom Panel .......................6 Figure 1-6: Dimensions (mm) ......................6 Figure 3-1: Bottom Panel Retention Screws................17 Figure 3-2: Internal Chassis Retention Screws .................17...
  • Page 11 IVS-300 Embedded System Figure 3-26: Power Button......................35 Figure 3-27: Mobile AP–Connection ...................38 Figure 3-28: Mobile AP–Dial Up ....................39 Figure 5-1: SO-DIMM Locations ....................73 Figure 5-2: SO-DIMM Installation ....................73 Page xi...
  • Page 12 IVS-300 Embedded System List of Tables Table 1-1: Model Variations ......................3 Table 1-2: LED Indicators ......................5 Table 1-3: Technical Specifications....................8 Table 2-1: Package List........................11 Table 2-2: Optional Items......................12 Table 3-1: mSATA Slot (MINI-PCIE3) Pinouts ................22 Table 3-2: WWAN Module Slot (MINI-PCIE1) Pinouts ...............25 Table 3-3: WLAN Module Slot (MINI-PCIE2) Pinouts..............26...
  • Page 13 IVS-300 Embedded System List of BIOS Menus BIOS Menu 1: Main ........................43 BIOS Menu 2: Advanced ......................44 BIOS Menu 3: ACPI Settings .......................45 BIOS Menu 4: Super IO Configuration..................46 BIOS Menu 5: Serial Port n Configuration Menu...............46 BIOS Menu 6: Hardware Monitor....................51 BIOS Menu 7: Smart Fan Mode Configuration ................52...

  • Page 15: Introduction

    IVS-300 Embedded System Chapter Introduction Page 1...

  • Page 16: Overview

    J1900. It is designed for vehicle surveillance applications that require minimum installation space. The IVS-300 accepts a wide range of DC power input (9 V–36 V), allowing it to be powered anywhere. Wi-Fi and WWAN capabilities plus four RJ-45 Ethernet connectors with PoE ensure smooth network connectivity.

  • Page 17: Features

     Optional 802.11b/g/n 1T1R wireless connection 1.4 Model Variations There are three models in the IVS-300 embedded system series. The three models are all preinstalled with 4 GB of DDR3 memory. The model variations are listed in T able 1-1 6 5 3 below.

  • Page 18: Front Panel

    IVS-300 Embedded System 1.5 Front Panel An overview of the front panel is shown in F igure 1-2 below. 6 5 3 Figure 1-2: Front Panel 1.5.1 LED Indicators The LED indicators on the front panel show the status of power, HDD, Wi-Fi, PoE and GPRS/HSUPA connection.

  • Page 19: Rear Panel

    IVS-300 Embedded System At regular intervals: low voltage warning (configured by BIOS option: Section 4.3.4) Blinking At irregular intervals (long-short-short): GPS antenna is not connected. The WWAN module is not installed or the SIM slot is not being used. SIM LED...

  • Page 20: Bottom Panel

    IVS-300 Embedded System 1.7 Bottom Panel The bottom surface of the IVS-300 contains six retention screw holes for installing two side mounting brackets. Figure 1-5: Bottom Panel 1.8 Dimensions The dimensions of the IVS-300 are listed below and shown in F igure 1-6.

  • Page 21: Technical Specifications

    IVS-300 Embedded System 1.9 Technical Specifications The specifications for the Intel based embedded systems are listed below. IVS-300 ® Intel Core™ i5-6300U (dual-core, 2.4 GHz, 15W TDP) CPU (SoC) ® ® Intel Celeron J1900 (quad-core, 2.0 GHz, 10W TDP) System Memory 2 x 204-pin DDR3 SO-DIMM slot (system max.

  • Page 22: Table 1-3: Technical Specifications

    IVS-300 Embedded System 2 x 2.5” SATA 6Gb/s HDD/SSD removable drive bay Storage 1 x mSATA module slot (ULT3 models only) Extruded aluminum alloy Chassis Construction 9 V–36 V (±0.3 V) DC Power Input One 6-pin power input connector Power Consumption 12V@8A (with Intel®...

  • Page 23: Unpacking

    IVS-300 Embedded System Chapter Unpacking Page 9...

  • Page 24: Unpacking

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the IVS-300 was purchased from or contact an IEI sales representative directly by sending an email to ales@ieiworld.com.

  • Page 25: Optional Items

    IVS-300 Embedded System ACC power cable GPS/GSM antenna Screws (M3*5) for SSD installation Screws (M3*6) for mounting brackets Mounting brackets Driver and manual CD Table 2-1: Package List 2.3 Optional Items The following are optional component(s) which may be separately purchased: Wi-Fi kit with AW-NE238H 802.11b/g/n Wi-Fi module...

  • Page 26: Table 2-2: Optional Items

    64-bit for IVS-300-ULT3, DVD-ROM, RoHS (P/N: IVS-300-ULT3-WES7E64-R10) Table 2-2: Optional Items NOTE: The IVS-300 embedded system only supports one Bluetooth connection. It is suggested not to purchase a Wi-Fi kit together with a WWAN kit that both have Bluetooth function, e.g. IVS-3G-KIT01-R10 with IVS-WIFI-KIT02-R10.

  • Page 27: Installation

    IVS-300 Embedded System Chapter Installation Page 13...

  • Page 28: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the WAFER series motherboard and the power module. (Dry climates are especially susceptible to ESD.) It is therefore critical that whenever the IVS-300 is opened and any electrical component handled, the following anti-static precautions are strictly adhered to.

  • Page 29: High Surface Temperature

    Air Circulation: Make sure there is sufficient air circulation when installing the IVS-300. The IVS-300’s cooling vents must not be obstructed by any objects. Blocking the vents can cause overheating of the IVS-300. Leave at least 5 cm of clearance around the IVS-300 to prevent overheating.

  • Page 30: Disassemble The System

    Before the internal component can be installed, the system must be disassembled to access the main board. To disassemble the system, please follow the steps below: Turn the IVS-300 over. Step 1: Remove the bottom panel retention screws to detach the bottom panel from the...

  • Page 31: Figure 3-1: Bottom Panel Retention Screws

    IVS-300 Embedded System Figure 3-1: Bottom Panel Retention Screws Remove the four internal retention screws ( Step 3: F igure 3-2). 7 6 3 Figure 3-2: Internal Chassis Retention Screws Remove the front panel retention screws to detach the front panel from the...

  • Page 32: Figure 3-4: Rear Panel Retention Screws

    IVS-300 Embedded System Remove the rear panel retention screws ( Step 5: F igure 3-4). 7 6 3 Figure 3-4: Rear Panel Retention Screws Lift the entire internal platform out of the heatsink enclosure carefully Step 6: (Figure 3-5). Turn the internal platform over to access the front side of the main board.

  • Page 33: Pcie Mini / Msata Card Installation

    IVS-300 Embedded System 3.5 PCIe Mini / mSATA Card Installation The PCIe Mini slot allows installation of either a full-size or half-size PCIe Mini card. To install a full-size PCIe Mini card or an mSATA module, please follow the steps below.

  • Page 34: Figure 3-7: Removing The Retention Screws

    IVS-300 Embedded System Figure 3-7: Removing the Retention Screws Line up the notch on the card with the notch on the slot. Slide the PCIe Mini card Step 4: into the socket at an angle of about 20º (Figure 3-8).

  • Page 35: Msata Slot (Mini-Pcie3) Pinouts

    IVS-300 Embedded System Figure 3-9: Securing the Full-size PCIe Mini Card 3.5.1 mSATA Slot (MINI-PCIE3) Pinouts The pinouts for the mSATA slot (MINI-PCIE3) are listed in the table below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC3 VCC1.5 SIM_VCC SIM_CIO CLK_PCIE_CLK_N...

  • Page 36: Wlan/Wwan Module Installation

    Remove the knockout for antenna installation. The knockouts are located on the Step 2: rear panel of the IVS-300 as shown in Figure 3-10. Figure 3-10: Knockouts for External Antennas Locate the half-size PCIe Mini slot for WLAN modules and the full-size PCIe Mini Step 3: slot for WWAN modules (Figure 3-11).

  • Page 37: Figure 3-11: Wlan And Wwan Card Slot Locations

    IVS-300 Embedded System Figure 3-11: WLAN and WWAN Card Slot Locations Line up the notch on the WLAN/WWAN module with the notch on the slot. Slide Step 5: the WLAN/WWAN module into the slot at an angle of about 20º.

  • Page 38: Wwan Module Slot (Mini-Pcie1) Pinouts

    IVS-300 Embedded System Install the external antenna. Step 11: Figure 3-13: Securing SMA Connector and External Antenna Installation 3.6.1 WWAN Module Slot (MINI-PCIE1) Pinouts The pinouts for the WWAN module slot (MINI-PCIE1) are listed in the table below. PIN NO.

  • Page 39: Wlan Module Slot (Mini-Pcie2) Pinouts

    IVS-300 Embedded System USB_DATA_N USB_DATA_P VCC3 VCC3 3GLED_EN VCC1.5 VCC3 Table 3-2: WWAN Module Slot (MINI-PCIE1) Pinouts 3.6.2 WLAN Module Slot (MINI-PCIE2) Pinouts The pinouts for the WLAN module slot (MINI-PCIE2) are listed in the table below. PIN NO. DESCRIPTION PIN NO.

  • Page 40: Sim Card Installation

    To be able to use the WWAN network connection, SIM cards must be installed in the IVS-300. Follow the steps below to install SIM cards. Install a WWAN module into the IVS-300. See Section 3.4. Step 1: Locate the SIM card slots on the rear panel (Figure 3-14).

  • Page 41: Solid-State Drive Installation

    See Section 1.5.1. 3.8 Solid-State Drive Installation Two 2.5” SATA drives can be installed in the IVS-300. The SATA drives are installed into the removable hard drive brackets on the front panel. To install the SSD into the system, please follow the steps below.

  • Page 42: Figure 3-17: Ssd Retention Screws

    IVS-300 Embedded System Place an SSD onto the bracket and secure the SSD with the bracket by inserting Step 3: four retention screws (M3*4) into the bottom of the SSD ( F igure 3-17). 7 6 3 Figure 3-17: SSD Retention Screws Carefully insert the SSD bracket into the slot on the front panel.

  • Page 43: Mounting The System

    IVS-300 Embedded System Repeat the five steps described above to install the second SSD into the other Step 6: SSD bracket. Step 0: 3.9 Mounting the System To mount the embedded system onto a wall or some other surface using the two mounting brackets, please follow the steps below.

  • Page 44: External I/O Connectors

    This section provides an overview of the external I/O connectors of the IVS-300. 3.10.1 COM Port Connection The IVS-300 has two DB-9 connectors for RS-232 serial port connection. The pinouts for the RS-232 connectors (COM1and COM2) are listed in the figure and table below.

  • Page 45: Dio And Rs-422/485 (Com6) Connection

    IVS-300 Embedded System 3.10.2 DIO and RS-422/485 (COM6) Connection The IVS-300 has one DB-15 connector for DIO and RS-422/485 (COM6) connection. The pinouts for the DIO and RS-422/485 connector are listed in the figure and table below. Figure 3-21: DIO and RS-422/485 Connector PIN NO.

  • Page 46: Obd-Ii Connection

    IVS-300 Embedded System 3.10.3 OBD-II Connection The IVS-300 has one DB-9 connector for OBD-II/CAN-bus connection. The pinouts for the OBD-II connector are listed in the figure and table below. Figure 3-22: OBD-II Connector PIN NO. DESCRIPTION OBD-CAN_H ISO-9141-2-K OBD-CAN_L J1850-...

  • Page 47: Gps Speed Pulse/Direction Connection

    IVS-300 Embedded System 3.10.4 GPS Speed Pulse/Direction Connection The IVS-300 has a 2-pin connector for GPS speed pulse/direction connection. The pinouts for the GPS speed pulse/direction connector are listed in the figure and table below. Figure 3-23: GPS Speed Pulse/Direction Connector PIN NO.

  • Page 48: Power Input Connection

    Figure 3-24: Power Input Connector PIN NO. DESCRIPTION Table 3-8: Power Input Connector Pinouts To use ACC power, connect the IVS-300 to the vehicle through the ACC power cable. See Figure 3-25. Figure 3-25: ACC Power Cable Page 34...

  • Page 49: Power-On Procedure

    IVS-300 Embedded System NOTE: The IVS-300 can also be powered through PoE (802.3af). 3.11.3 Power-on Procedure To power-on the IVS-300 please follow the steps below: Connect the power source to the power connector or use PoE to provide power Step 1: to the system.

  • Page 50: Driver Installation

    Visit the IEI website or contact technical support for the latest updates. All the drivers for the IVS-300 are on the utility CD that came with the system. The utility CD contains drivers for Windows 7 and Windows 8 operating systems. Please select the corresponding drivers for the system.

  • Page 51: Mobile Ap

    Insert the utility CD into a CD drive connected to the system and install all of the necessary drivers for the IVS-300. 3.13 Mobile AP IEI provides an application tool, Mobile AP, for the users of the IVS-300 with the WWAN module installed to manage mobile network and make a phone call. 3.13.1 Installation To install this application tool, please locate the WLAN folder in the utility CD.

  • Page 52: Usage

    IVS-300 Embedded System 3.13.2 Usage To launch the application, double click the MobileAP icon on the Windows desktop. The user interface appears as shown in Figure 3-27. The functions are described below. Figure 3-27: Mobile AP–Connection  Sim card switch: Select a SIM card to designate a SIM card to use or click the Refresh SIM status button to let the system detect automatically.

  • Page 53: Figure 3-28: Mobile Ap-Dial Up

    IVS-300 Embedded System The Mobile AP also allows the user to make a phone call. To use Mobile AP to make a phone call, click the Dial up tab in the Mobile AP. Then, the user interface appears as shown in Figure 3-28. The functions are described below.

  • Page 54: Bios

    IVS-300 Embedded System Chapter BIOS Page 40...

  • Page 55: Introduction

    IVS-300 Embedded System 4.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 56: Getting Help

    IVS-300 Embedded System Function Decrease the numeric value or make changes Page up Move to the next page Page down Move to the previous page Main Menu – Quit and do not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu --...

  • Page 57: Main

    IVS-300 Embedded System 4.2 Main The Main BIOS menu ( B IOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.

  • Page 58: Advanced

    IVS-300 Embedded System 4.3 Advanced Use the Advanced menu ( B IOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.

  • Page 59: Acpi Settings

    IVS-300 Embedded System 4.3.1 ACPI Settings The ACPI Settings menu ( B IOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI...

  • Page 60: Super Io Configuration

    IVS-300 Embedded System 4.3.2 Super IO Configuration Use the Super IO Configuration menu ( B IOS Menu 4) to set or change the configurations for the serial ports. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced Super IO Configuration...

  • Page 61: Serial Port [Enabled]

    IVS-300 Embedded System 4.3.2.1.1 Serial Port 1 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disable the serial port Disabled  Enable the serial port Enabled EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.
  • Page 62 IVS-300 Embedded System  Serial Port I/O port address is 2E8h and the interrupt IO=2E8h; address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12 IRQ=3, 5, 6, 7, 9, 10, 11, 12 4.3.2.1.2 Serial Port 2 Configuration ...
  • Page 63 IVS-300 Embedded System  Serial Port I/O port address is 3E8h and the interrupt IO=3E8h; address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12 IRQ=3, 5, 6, 7, 9, 10, 11, 12  Serial Port I/O port address is 2E8h and the interrupt IO=2E8h;...
  • Page 64 IVS-300 Embedded System  Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12 IRQ=3, 5, 6, 7, 9, 10, 11, 12  Serial Port I/O port address is 3E8h and the interrupt IO=3E8h;...

  • Page 65: Hardware Monitor

    IVS-300 Embedded System 4.3.3 Hardware Monitor The Hardware Monitor menu ( B IOS Menu 6) displays operating temperature and fan speeds. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced PC Health Status Enable or Disable Smart Smart Fan Function [Enabled] >...

  • Page 66: Smart Fan Mode Configuration

    IVS-300 Embedded System  Fan Speed: Fan1 speed Fan2 speed Voltages:  +SOC_VCC +V5S +12S +1.5S VCC3V VSB3V VSB5V 4.3.3.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 7) to configure fan temperature and speed settings.

  • Page 67: Cpu_Fan1 Smart Fan Control [Auto Duty-Cycle Mode]

    IVS-300 Embedded System  CPU_FAN1 Smart Fan Control [Auto Duty-Cycle Mode] Use the CPU_FAN1 Smart Fan Control BIOS option to configure the CPU Smart Fan.  The fan spins at the speed set in the Manual Manual Duty Mode Duty Mode option ...

  • Page 68: Power Management

    IVS-300 Embedded System 4.3.4 Power Management Use the Power Management menu (BIOS Menu 8) to configure the power management function. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced Current Voltage : +12.2 V Set Low Voltage Warning...
  • Page 69 IVS-300 Embedded System  1 hour  Auto Power Off Delay [20 sec] Use the Auto Power Off Delay option to set the automatic power-off delay time. Configuration options are listed below.  20 sec EFAULT 1 min  5 min ...

  • Page 70: Cpu Configuration

    IVS-300 Embedded System 4.3.5 CPU Configuration Use the CPU Configuration menu ( B IOS Menu 9) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced CPU Configuration When enabled, a VMM can utilize the additional Intel(R) Celeron(R) CPU J1900 @ 1.99GHz...

  • Page 71: Eist [Enabled]

    IVS-300 Embedded System  L3 Cache: Lists the amount of storage space on the L3 cache.  L4 Cache: Lists the amount of storage space on the L4 cache. 64-bit: Indicates if 64-bit system is supported by the CPU. ...

  • Page 72: Ide Configuration

    IVS-300 Embedded System 4.3.6 IDE Configuration Use the IDE Configuration menu ( B IOS Menu 10) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.

  • Page 73: Usb Configuration

    IVS-300 Embedded System 4.3.7 USB Configuration Use the USB Configuration menu ( B IOS Menu 11) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 74: Chipset

    IVS-300 Embedded System  Legacy USB support enabled Enabled EFAULT  Legacy USB support disabled Disabled  Legacy USB support disabled if no USB devices are Auto connected 4.4 Chipset Use the Chipset menu (BIOS Menu 12) to access the North Bridge and South Bridge configuration menus.

  • Page 75: North Bridge Configuration

    IVS-300 Embedded System 4.4.1 North Bridge Configuration Use the North Bridge menu (BIOS Menu 13) to configure the north bridge chipset. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Chipset > Intel IGD Configuration Config Intel IGD Settings.

  • Page 76: Intel Igd Configuration

    IVS-300 Embedded System 4.4.1.1 Intel IGD Configuration Use the Intel IGD Configuration submenu (BIOS Menu 14) to configure the graphics settings. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc. Chipset Intel IGD Configuration Select DVMT 5.0 Pre-Allocated (Fixed)

  • Page 77: South Bridge Configuration

    IVS-300 Embedded System  DVMT Total Gfx Mem [Max] Use the DVMT Total Gfx Mem option to specify the maximum amount of memory that can be allocated as graphics memory. Configuration options are listed below.  128MB  256MB ...

  • Page 78: Security

    IVS-300 Embedded System  onboard High Definition Audio controller Enabled EFAULT automatically detected and enabled  XHCI Mode [Smart Auto] Use the XHCI Mode BIOS option to configure the USB xHCI (USB 3.0) controller.  Enable the xHCI controller. USB 3.0 ports behave as Enabled USB 3.0 ports.

  • Page 79: Boot

    IVS-300 Embedded System  User Password Use the User Password to set or change a user password. 4.6 Boot Use the Boot menu ( B IOS Menu 17) to configure system boot options. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.

  • Page 80: Quiet Boot [Enabled]

    IVS-300 Embedded System  Does not enable the keyboard Number Lock automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The Number Lock LED on the keyboard lights up when the Number Lock is engaged.

  • Page 81: Save & Exit

    IVS-300 Embedded System 4.7 Save & Exit Use the Save & Exit menu ( B IOS Menu 18) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.
  • Page 82 IVS-300 Embedded System  Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options. Page 68...

  • Page 83: Troubleshooting And Maintenance

    IVS-300 Embedded System Chapter Troubleshooting and Maintenance Page 69...

  • Page 84: System Maintenance Overview

    Failure to follow these instructions may lead to personal injury and system damage. To preserve the working integrity of the IVS-300 embedded system, the system must be properly maintained. If embedded system components need replacement, the proper maintenance procedures must be followed to ensure the system can continue to operate normally.

  • Page 85: The System Doesn't Boot Up

    WARNING! If all troubleshooting measures have been taken and the system still fails to start, contact the IEI reseller or vendor you purchased the IVS-300 from or contact an IEI sales representative directly. To contact sales representative, please...

  • Page 86: Component Replacement Procedure

    IVS-300 embedded system other than those listed below. If any other components fail or need replacement, contact the IEI reseller or vendor you purchased the IVS-300 from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to ales@ieiworld.com.

  • Page 87: Figure 5-1: So-Dimm Locations

    IVS-300 Embedded System Figure 5-1: SO-DIMM Locations Remove the SO-DIMM by releasing the arms on the SO-DIMM socket. Step 3: Align the new SO-DIMM with the socket. The SO-DIMM must be oriented in Step 4: such a way that the notch in the middle of the SO-DIMM must be aligned with the plastic bridge in the socket ( F igure 5-2).

  • Page 88: A Regulatory Compliance

    IVS-300 Embedded System Appendix Regulatory Compliance Page 74...
  • Page 89 IVS-300 Embedded System DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU)  Low-Voltage Directive (2006/95/EC, 2014/35/EU)  RoHS II Directive (2011/65/EU, 2015/863/EU)  Ecodesign Directive 2009/125/EC  If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 90 IVS-300 Embedded System Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...
  • Page 91 IVS-300 Embedded System Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 2014/53/EU. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU.
  • Page 92 IVS-300 Embedded System FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and  This device must accept any interference received, including interference ...

  • Page 93: B Safety Precautions

    IVS-300 Embedded System Appendix Safety Precautions Page 79...

  • Page 94: Safety Precautions

     Electric shocks can occur if the IVS-300 chassis is opened when it is running. To avoid risk of electric shock, this device must only be connected to a supply mains with protective earth.

  • Page 95: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IVS-300. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the IVS-300 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 96: Product Disposal

    IVS-300 Embedded System B.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 97: Maintenance And Cleaning Precautions

    Always make sure your hands are dry when unplugging the power cable. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the IVS-300, please read the details below.  Never spray or squirt liquids directly onto any other components. To clean the embedded system, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth.
  • Page 98 IVS-300 Embedded System  Water or rubbing alcohol–A cloth moistened with water or rubbing alcohol can be used to clean the device.  Using solvents–The use of solvents is not recommended when cleaning the device as they may damage the plastic parts.

  • Page 99: Cbios Menu Options

    IVS-300 Embedded System Appendix BIOS Menu Options Page 85...

  • Page 100: Bios Configuration Options

    IVS-300 Embedded System C.1 BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 4. 　 System Date [xx/xx/xx] ......................43 　 System Time [xx:xx:xx] .......................43 　 ACPI Sleep State [Suspend Disabled] ................45 　 Serial Port [Enabled]......................47 　...
  • Page 101 IVS-300 Embedded System 　 Save Changes and Reset ....................67 　 Discard Changes and Reset ....................67 　 Restore Defaults ........................67 　 Save as User Defaults ......................67 　 Restore User Defaults ......................68 Page 87...

  • Page 102: D Watchdog Timer

    IVS-300 Embedded System Appendix Watchdog Timer Page 88...
  • Page 103 IVS-300 Embedded System NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.

  • Page 104: Example Program

    IVS-300 Embedded System NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 105: E Hazardous Materials Disclosure

    IVS-300 Embedded System Appendix Hazardous Materials Disclosure Page 91...
  • Page 106 IVS-300 Embedded System The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 107 IVS-300 Embedded System 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...
