The AWS Sonar Control screen
The 8x8 key matrix is used to access three Sonar MCU function groups.
00:00:00:00
Fkys AUTO Trks
Fkys are the eight functions keys. These are defined in Sonar and also output Edit commands in conjunction with
a Modifier key.
Fkys Trks
AUTO
F1 F2 F3
Auto calls up three Automation functions, Snapshot, Disarm and Offset. The main automation Read/Off key is
mapped to a dedicated front panel switch.
Fkys Trks
AUTO
Snap Darm Ofst
Trks bring the four TRACKS function keys on to the bottom row of soft keys.
Fkys Trks
AUTO
NAud NMid FitA
F4 F5 F6
FitP
MCU based DAW Control Guide
SSL
SSL
F7 F8
SSL
SSL
