Assigning the AWS900+ SE IP Address:

By default, AWS900+ SE uses a fixed IP address of 192.168.1.2. Dynamic (DHCP) address can be selected via
the SSL > MISC > NET menu. The currently assigned address is also shown in the MISC > ABOUT > NET menu.
If your AWS900+ SE is connected to the computer via a network switch or router, it should be assigned a DHCP
IP address; otherwise the fixed option should be used. Once you have altered the IP mode, you need to restart
your AWS for the change to take effect. A software restart option is available in the SSL > MISC > NET menu.
An alternative fixed IP address can be set using the console diagnostic port. This should not be necessary in most
installations. You will need a PC or Mac running terminal emulator software. Connect your computer's serial port
to the rear of the console using a 9 way 'D' type extension cable. The pin out for the console's 9 way 'D' type serial
connector is shown below:
Set the terminal as follows: Baud rate 19200, 8 data bits, No parity, No start bit, 1 stop bit, Flow control Xon/Xoff
Press the 'Return' key (<CR>) and the terminal window should echo a '>' if communication is established. To fix
the IP address type the following:
ip <CR>
setip nnn nnn nnn nnn <CR>
setmask nnn nnn nnn nnn <CR> where 'nnn...' is the subnet mask 192.168.1.1. Note that this should match other
devices local to the console.
setgate nnn nnn nnn nnn <CR> where 'nnn...' is the gateway address e.g. '10 1 1 1'
Pin Description
1 Carrier (linked to 0V)
2 Tx
3 Rx
4 DTR (linked to DSR)
5 0V
6 DSR (linked to DTR)
7 RTS (linked to CTS)
8 CTS (linked to RTS)
9 RI (linked to 0V
where 'nnn...' is the IP address, 192.168.1.2
