DAW Control Guide
Main changes compared to the HUI front panel are:
New Function grouping to assign parameters the Channel D-Pots. CHANNEL is unchanged and assigns the AWS
channel gain element or DAW channel to the D-Pot according to the state of the Console Focus key. The Encoder
switch is used to 'flip' parameters on to the faders as before but now includes all processing parameters not just
send levels. Two 'Flip' modes are available, Duplicate or Exchange, selected via a single or double operation of
the encoder switch.
As in the original HUI three key group that controls the function of the channel SEL key, for the Sonar Template
SEL and RDY control whether the SEL key sends the SEL and REC/RDY MIDI codes. EDIT is now a dedicated
function equivalent to the MCU EDIT/GLOBAL function located in the FADER BANKS section.
The display above the encoder will show the two character plus decimal point Assignment window from the MCU.
The Keys above the transport controls are designated as shown below:
LOOP
MARKER
JOG LOOP
PARAM ON/OFF
Tallies are shown in the status area of the TFT display for Loop ON/OFF, Jog Parameter, together with tallies for
Marker, Loop, Select and Punch. As the later functions intercancel, they share the same on screen area.
Keypad is not a direct MCU function. It will enable the Numerical keypad 0 .... 9 keys plus the '.', '-', and ENTER
and CLR keys for data entry. When operated it send the codes that correspond to M1 ON, EDIT ON, EDIT OFF,
M1 OFF and then enables the numeric key pad keys to send the MIDI codes that correspond to the 1 to 8 keys on
the Sonar overlay and the 4 TRACKS keys. ENTER mimics the main ENTER Key, and CLR the CANCEL Key. A
second operation of the KEYPAD key inhibits the Numeric key pad outputting MIDI codes and should send an EDIT
ON, EDIT OFF command to cancel the mode.
5-36
AWS 900+ SE Owner's Manual
SELECT PUNCH
HOME
KEYPAD
