1.3.3 GV-MDR

No. Name
1 Silica gel bag
2 Conceal paper
3 Lens
4 Rotation Disc
5 Pan Disc
6 Tilt Screw
7 Microphone
1
3
1
4
2
5
8
9
10
Figure 1-4
Description
Absorbs the moisture inside the camera.
Prevents water or moisture from entering
the camera.
Receives image inputs.
Rotates the camera lens.
Pans the camera lens.
Loosens to tilt the camera.
Provides one-way audio.
Mini Fixed & Rugged Dome
