GV-IPCam H.264
User's Manual
Before attempting to connect or operate this product,
ICH264TIV30-B
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading

Related Manuals for GeoVision GV-BX120D

Summary of Contents for GeoVision GV-BX120D

  • Page 1 GV-IPCam H.264 User's Manual Before attempting to connect or operate this product, ICH264TIV30-B please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Safety Notice UL Certification for GV-MFD120 / 130 / 320 The GV-IPCAM H.264 uses a 3.0V CR2032 Lithium battery as the power supply for its internal real-time clock (RTC). The battery should not be replaced unless required! If the battery does need replacing, please observe the following: •...

  • Page 4: Preface

    BX120D / 130D / 140DW / 220D / 320D / 520D  CB120 / 220  Models installed with a 32 MB NAND flash Firmware Model Model Number Version GV-BX120D Varifocal Lens V2.15 GV-BX140DW GV-BX130D-0 Varifocal Lens GV-BX130D-1 Fixed Lens Box Camera...
  • Page 5 Firmware Model Model Number Version GV-BX1200-0F ~ 2F GV-BX1300-0F ~ 2F GV-BX1500-0F ~ 2F Fixed Lens GV-BX2400-0F ~ 2F GV-BX2500-0F ~ 2F GV-BX3400-0F ~ 2F GV-BX1200-3V GV-BX1300-3V GV-BX1500-3V GV-BX2400-3V Box Camera V3.0 GV-BX2500-3V Varifocal Lens GV-BX2400-4V GV-BX3400-4V GV-BX3400-5V GV-BX5300-6V GV-BX1500-8F GV-BX2400-8F Fixed Lens GV-BX2500-8F...
  • Page 6 Firmware Model Model Number Version Target Box V1.03 GV-EBX1100 Series Fixed Lens Camera V2.15 GV-BX120D-E GV-BX220D-E GV-BX320D-E V2.14 GV-BX520D-E Varifocal Lens IR Arctic Box GV-BX1500-E Camera GV-BX2400-E GV-BX3400-E V3.0 GV-BX5300-E GV-BX2510-E Motorized Varifocal Lens GV-BX5310-E GV-MFD120 GV-MFD130 GV-MFD320 Mini Fixed...
  • Page 7 Firmware Model Model Number Version GV-MDR220 GV-MDR320 GV-MDR520 Mini Fixed V3.0 Fixed Lens Rugged Dome GV-MDR1500 Series GV-MDR3400 Series GV-MDR5300 Series GV-EFD1100 Series Target Mini Fixed Lens V1.03 Fixed Dome GV-EFD2100 Series Target Mini GV-EDR1100 Series Fixed Rugged Fixed Lens V1.03 GV-EDR2100 Series Dome...
  • Page 8 Firmware Model Model Number Version GV-BL120D GV-BL130D GV-BL220D GV-BL320D Varifocal Lens GV-BL1500 GV-BL2400 GV-BL2500 V3.0 Bullet Camera GV-BL3400 GV-BL1210 GV-BL2410 GV-BL3410 Motorized Varifocal GV-BL5310 Lens GV-BL1510 Coming GV-BL2510 Motorized Varifocal GV-BL2510-E IR Arctic Bullet Lens, extreme V3.0 Camera temperature GV-BL5310-E tolerance NTSC V1.09...
  • Page 9 Firmware Model Model Number Version GV-VD120D (IK10+, Transparent Cover) GV-VD121D (IK10+, Smoked Cover) GV-VD122D (IK7, Transparent Cover) GV-VD123D (IK7, Smoked Cover) GV-VD220D (IK10+, Transparent Cover) GV-VD221D (IK10+, Smoked Cover) GV-VD222D Vandal Proof (IK7, Transparent Cover) Varifocal Lens V3.0 IP Dome GV-VD223D (IK7, Smoked Cover) GV-VD320D...
  • Page 10 Firmware Model Model Number Version GV-VD1530 Varifocal Lens, GV-VD2430 high power IR GV-VD2530 LEDs GV-VD3430 Vandal Proof GV-VD1540 IP Dome Motorized GV-VD2440 Varifocal Lens, GV-VD2540 V3.0 high power IR GV-VD3440 LEDs GV-VD5340 Motorized IR Arctic Varifocal Lens, GV-VD2540-E high power IR Vandal Proof GV-VD5340-E LEDs, extreme...
  • Page 11 Firmware Model Model Number Version GV-FD220D GV-FD320D GV-FD1200 Varifocal GV-FD1500 Lens GV-FD2400 GV-FD2500 Fixed IP V3.0 GV-FD3400 Dome GV-FD5300 GV-FD1210 GV-FD1510 Motorized GV-FD2410 Varifocal Lens GV-FD2510 GV-FD3410...

  • Page 12: Table Of Contents

    2.2 Features..................8 2.2.1 Wide Dynamic Range Pro ........... 10 2.3 Overview..................11 2.3.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D................11 2.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series......13 2.4 Connecting the Camera............15...
  • Page 13 Chapter 5 IR Arctic Box Camera ........36 5.1 Packing List................38 5.2 Features..................40 5.3 Overview..................42 5.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400- E / 3400-E / 5300-E ..............42 5.3.2 GV-BX2510-E / 5310-E ............43 5.4 Installation.................44 5.5 Connecting the Camera............50...
  • Page 14 5.5.2 GV-BX2510-E / 5310-E ............52 5.6 Notice for Using the IR Arctic Box Camera ......55 5.6.1 Enabling IR LED after Loading Default ........ 56 5.6.2 Disabling Status LED under Low Light Conditions ....57 Chapter 6 Mini Fixed Dome & Mini Fixed Rugged Dome....
  • Page 15 8.2 Features..................92 8.3 Overview..................94 8.4 Installation.................95 8.5 Connecting the Camera............102 Chapter 9 Bullet Camera ..........103 9.1 Packing List................106 9.2 Features...................107 9.3 Overview...................110 9.4 Installation................111 9.4.1 Connecting the Camera ............ 113 9.4.2 Adjusting the Angles ............117 9.4.3 Adjusting Lens and Inserting a Memory Card ....121 9.4.4 Installing the Sun-Shield Cover .........
  • Page 16 Chapter 12 PTZ Camera ..........151 12.1 Packing List................152 12.2 Features.................153 12.3 Overview................154 12.4 Installation................156 12.4.1 Ceiling Mount ..............156 12.4.2 L-Shaped Wall Mount............158 12.5 Connecting the Camera ............161 12.6 Focus Adjustment..............162 12.7 I/O Terminal Block..............163 12.7.1 Pin Assignment ............... 163 12.7.2 Voltage Load Expansion (Optional) .........
  • Page 17 13.7.2 Voltage Load Expansion (Optional) ......... 187 13.8 PT Control ................188 Chapter 14 Vandal Proof IP Dome (Part I) ....190 14.1 Packing List................192 14.2 Features.................193 14.3 Overview................195 14.4 Installation................197 14.4.1 Hard-Ceiling Mount ............198 14.4.2 In-Ceiling Mount .............. 203 14.5 Connecting the Camera ............206 14.5.1 Wire Definition..............
  • Page 18 16.4.1 Hard-Ceiling Mount ............239 16.4.2 In-Ceiling Mount .............. 243 16.4.3 Wall-Surface Mount............247 16.5 Connecting the Camera ............249 16.6 I/O Terminal Block..............250 16.6.1 Pin Assignment ............... 250 16.6.2 Voltage Load Expansion (Optional) ......... 251 Chapter 17 Cube Camera ..........252 17.1 Packing List................253 17.2 Features.................254 17.3 Overview................255...
  • Page 19 Chapter 20 Accessing the Camera......285 20.1 Accessing Your Surveillance Images ........286 20.2 Functions Featured on the Main Page .........287 20.2.1 The Live View Window ............ 288 20.2.2 The Control Panel of the Live View Window ....293 20.2.3 Snapshot of Live Video............ 299 20.2.4 Video Recording..............
  • Page 20 21.3 Events and Alerts..............346 21.3.1 E-mail ................347 21.3.2 FTP................. 349 21.3.3 Center V2................ 352 21.3.4 Vital Sign Monitor ............354 21.3.5 Backup Center ..............356 21.3.6 Video Gateway / Recording Server........359 21.3.7 ViewLog Server............... 361 21.3.8 RTSP/ONVIF ..............362 21.3.9 Speaker ................
  • Page 21 Chapter 22 Recording and Playback ......401 22.1 Recording ................401 22.2 Playback ................402 22.2.1 Playback from the Memory Card ........402 22.2.2 Playback over Network............ 408 22.2.3 Access to the Recorded Files through FTP Server... 409 22.2.4 Playback of Daylight Saving Time Events ......410 Chapter 23 Advanced Applications ......412 23.1 Upgrading System Firmware..........412 23.1.1 Using the Web Configuration Interface ......
  • Page 22 24.4.2 Connecting to the IP Camera .......... 466 Chapter 25 CMS Configurations........467 25.1 Center V2 ................467 25.2 Vital Sign Monitor..............470 25.3 Dispatch Server..............471 Chapter 26 Smart Device Connection......473 Appendix.................474 A. Settings for Internet Explorer 8 ..........474 B. Supported Lenses for Box Camera .........475 C.
  • Page 23 Specifications: Bullet Camera (Part 2) .........594 Specifications: Ultra Bullet Camera..........606 Specifications: Target Bullet Camera...........618 Specifications: PTZ Camera............623 Specifications: PT Camera............628 Specifications: Vandal Proof IP Dome (Part 1) ......634 Specifications: Vandal Proof IP Dome (Part 2) ......647 Specifications: Fixed IP Dome (Part 1).........660 Specifications: Fixed IP Dome (Part 2).........666 Specifications: Cube Camera............679 Specifications: Advanced Cube Camera........684...

  • Page 24: Naming And Definition

    Naming and Definition GeoVision Analog and Digital Video Recording Software. The GV-System also refers to GV-Multicam GV-System System, GV-NVR System, GV-DVR System and GV- Hybrid DVR System at the same time. GV-VMS GeoVision Video Management System for IP cameras. XXII...

  • Page 25: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The power adapter is available for all GV-IP Camera (except Arctic Box Camera, Mini Fixed Rugged Dome and GV-BL2510-E / 5310-E). The supported regions are listed below: •...
  • Page 26 Device Description The GV-PA481 PoE adapter is designed to provide GV-PA481 PoE power and network connection to GV-BX1500-E / Adapter 2400-E / 3400-E / 5300-E over a single Ethernet cable. The GV-PA481 PoE adapter is designed to provide GV-PA482 PoE power and network connection to GV-BX2510-E / Adapter 5310-E over a single Ethernet cable.
  • Page 27 Device Description The smoked cover is an IK7, tinted camera cover designed for GV-Fixed IP Dome to conceal the Smoked Cover direction of the camera lens. Plastic PG21 The plastic PG21 conduit connector is used for Conduit running the wires of Target Mini Fixed Rugged Connector Dome through a 1/2”...

  • Page 28: Note For Connecting To Gv-System

    Note for Connecting to GV-System The GV-IPCAM H.264 is designed to work with GV-System, a hybrid or digital video management system. Note the following when GV-IPCAM H.264 is connected to GV-System: By default, the images are recorded to the memory card inserted in the GV-IP Camera H.264 (except GV-IR Arctic Box Camera and Target Series, which are not equipped with a memory card slot).

  • Page 29: Note For Recording

    Note for Recording By default, the images are recorded to the memory card inserted in the GV-IP Camera H.264 (except GV-IR Arctic Box Camera and Target Series, which are not equipped with a memory card slot). Make sure the Write recording data into local storage option (see 20.1.1 Video Settings) is enabled.

  • Page 30: Note For Adjusting Focus And Zoom

    Note for Adjusting Focus and Zoom When adjusting the Focus and Zoom Screws (on Box Camera, IR Arctic Box Camera, Bullet Camera, IR Arctic Bullet Camera, Vandal Proof IP Dome and Fixed IP Camera), do not over tighten the Focus and Zoom screws.

  • Page 31: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera, Bullet Camera, Ultra Bullet Camera, Target Bullet Camera, Vandal Proof IP Dome, Mini Fixed Rugged Dome or Target Mini Fixed Rugged Dome outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables.
  • Page 32 After opening the camera cover, ensure the screws are tightened and the cover is in place. The silica gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.

  • Page 33: Note For Closing The Bullet Camera Cover

    Note for Closing the Bullet Camera Cover To ensure that the camera performs its full capacity against water and dust, tightly close and lock the camera cover as indicated below. XXXI...

  • Page 34: Note For Usb Storage And Wifi Adapter

    Note for USB Storage and WiFi Adapter Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter: The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above. The USB hard drive’s storage capacity must not exceed 2TB. USB flash drives and USB hubs are not supported.

  • Page 35: Chapter 1 Introduction

    Chapter 1 Introduction The GV-IPCAM H.264 series offers a comprehensive range of IP cameras supporting your needs for IP surveillance in various environmental conditions. For detailed features of each model, refer to the corresponding chapter. 1.1 System Requirement To perform the GV-IPCAM H.264 operations through Web browser, ensure your PC is in good network connection, and use one of the following web browsers: •...

  • Page 36: Chapter 2 Box Camera

    The Box Camera models are detailed below: Box Camera Model No. Specifications Description Auto Iris, f:2.8 ~ 12 1.3 MP, H.264, mm, F/1.4, 1/3” CS GV-BX120D Low Lux, D/N Lens Varifocal Lens Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, mm, F/1.4, 1/3’’ CS...
  • Page 37 Box Camera Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 Varifocal 2 MP, H.264, GV-BX220D-3 mm, F/1.4, 1/3’’ CS Lens Lens Auto Iris, f:3.1 ~ 8 mm, F/1.2, 1/3” CS GV-BX320D-0 Lens 3 MP, H.264, Auto Iris, f: 2.8 ~ 6 Varifocal mm, F/1.3, 1/3’’...

  • Page 38: Specifications

    Model No. Specifications Description 1.3 MP, H.264, GV-BX1200-1F Low Lux, D/N 1.3 MP, H.264, GV-BX1300-1F 1.3 MP, H.264, GV-BX1500-1F Super Low Fixed Iris, f: 8 mm, Lux, D/N F/1.6, 1/2.5’’ CS 2 MP, H.264, Lens GV-BX2400-1F D/N, WDR Pro 2 MP, H.264, GV-BX2500-1F Super Low Lux, D/N...
  • Page 39 Box Camera Model No. Specifications Description 1.3 MP, H.264, GV-BX1200-3V Low Lux, D/N 1.3 MP, H.264, GV-BX1300-3V 1.3 MP, H.264, Auto Iris, f:2.8 ~ 12 GV-BX1500-3V Super Low mm, F/1.4, 1/2.7” CS Lux, D/N Lens 2 MP, H.264, GV-BX2400-3V D/N, WDR Pro 2 MP, H.264, Varifocal GV-BX2500-3V...
  • Page 40 P-Iris Models (Coming) Model No. Specifications Description 1.3 MP, H.264, GV-BX1500-3V Super Low Lux, D/N 2 MP, H.264, D/N, P-Iris, f: 3 ~ 10.5 GV-BX2400-3V WDR Pro mm, F/1.4, 1/2.7” CS Lens 2 MP, H.264, Super GV-BX2500-3V Low Lux, D/N 3 MP, H.264, D/N, GV-BX3400-3V WDR Pro...

  • Page 41: Packing List

    Box Camera 2.1 Packing List • Box Camera • Terminal Block • Fixed Focal or Varifocal Megapixel Lens • Six Lens Rings • One 0.125 mm Lens Ring (for GV-BX140DW only) • Video Out Wire • Camera Holder • Power Adapter •...

  • Page 42: Features

    2.2 Features • Image sensor Camera Model Image Sensor GV-BX120D 1/3’’ progressive scan low lux CMOS GV-BX1200 Series GV-BX130D Series GV-BX1300 Series GV-BX220D Series 1/2.5’’ progressive scan CMOS GV-BX320D Series GV-BX520D GV-BX5300 Series GV-BX140DW 1/3’’ progressive scan CMOS GV-BX1500 Series 1/3’’...
  • Page 43 Box Camera • Dual streams from H.264 or MJPEG • Day / Night function (with removable IR-cut filter) • Wide Dynamic Range Pro (GV-BX140DW / 2400 Series / 2500 Series / 3400 Series only • P-Iris for auto iris adjustment (Coming, for GV-BX1500-3V / 1500-4V / 2400-3V / 2400-4V / 2500-3V / 2500-4V / 3400-3V / 3400-4V / 5300- 6V only) •...

  • Page 44: Wide Dynamic Range Pro

    2.2.1 Wide Dynamic Range Pro Objects may appear as silhouettes when they are backed with intense lights. The Wide Dynamic Range Pro (WDR Pro) is designed to solve this problem using a WDR sensor. In GV-BX140DW, GV-BX2400 Series and GV-BX3400 Series, the WDR sensor is able to process the image and show details in bright and dark areas at the same time.

  • Page 45: Overview

    12 13 Figure 2-1 Note: 1. The Auto Iris connector (No. 7) is only functional in GV-BX120D, GV-BX130D-0, GV-BX220D and GV-BX320D. 2. The Light Sensor (No.11) is only available in GV-BX140DW. Keep the Light Sensor unobscured for accurate light detection.
  • Page 46 Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal For details, see 2.6 I/O Terminal Block. Block Indicates the power is supplied. For detail, see Power LED the table below. Auto Iris Plug the iris control cable to the connector.

  • Page 47: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series

    Box Camera 2.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series Figure 2-2 Note: The Auto Iris Connector (No. 8) is only functional for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 3400. The Iris Screw (No.
  • Page 48 Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal Connects to I/O devices. For details, see 2.6 Block I/O Terminal Block. Indicates the power is supplied. For detail, Power LED see the table below.

  • Page 49: Connecting The Camera

    2.4 Connecting the Camera The Box Camera is designed for indoor use. Please make sure the installing site is shielded from rain and moisture. 2.4.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D Figure 2-3 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 50 Connect power using one of the following methods: • plugging the power adapter to the power port. • using the Power over Ethernet (PoE) function and the power will be provided over the network cable. The status LED of the camera will be on. You are ready to access the live view, adjust the image clarity and configure the basics.

  • Page 51: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400

    Box Camera 2.4.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series Figure 2-4 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 52 Optionally connect to input / output devices or an infrared illuminator. For details, see 2.5.2 Infrared Illuminator and 2.6 I/O Terminal Block. Connect power using one of the following methods: • plugging the power adapter to the power port. The power adapter is an optional device.

  • Page 53: Accessory Installation

    Box Camera 2.5 Accessory Installation 2.5.1 C-Mount Lenses If you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then secure the lens onto the camera body. Three types of C-mount lens rings are provided for Box Camera: •...

  • Page 54: Infrared Illuminators (Optional)

    2.5.2 Infrared Illuminators (Optional) If you use an infrared (IR) illuminator with I/O function, follow the steps below to install it. Connect the infrared illuminator to the terminal block on the camera. See 2.6 The I/O Terminal Block. Access the Web interface of the camera. Select Video and Motion, select Video Settings, select Streaming 1 and set the IR Check Function setting to Trigger by Input.

  • Page 55: I/O Terminal Block

    Box Camera 2.6 I/O Terminal Block The terminal block, located on the back panel of the Box Camera, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E- Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 56: Connecting To Gv-Relay V2 (Optional)

    2.6.2 Connecting to GV-Relay V2 (Optional) The Box Camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 57: Chapter 3 Ultra Box Camera

    Chapter 3 Ultra Box Camera The Ultra Box Camera is a series of light-weighted cameras designed for indoor usage. Equipped with IR-cut filter and built-in IR LEDs, the Ultra Box Camera provides excellent image quality. The camera supports PoE and can be installed intuitively.

  • Page 58: Packing List

    3.1 Packing List • Ultra Box Camera • Supporting rack • Screw x 3 • Screw anchor x 3 • Power Adapter • GV-IPCAM H.264 Software DVD • GV-IPCAM H.264 Quick Start Guide • GV-NVR Software DVD • GV-NVR Quick Start Guide Note: The power adapter can be excluded upon request.

  • Page 59: Features

    Ultra Box Camera 3.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 or MJPEG • Frame rate Camera Model Frame Rate GV-UBX1301 Series Up to 30 fps at 1280 x 1024 GV-UBX2301 Series Up to 30 fps at 1920 x 1080 GV-UBX3301 Series Up to 20 fps at 2048 x 1536 •...

  • Page 60: Overview

    3.3 Overview Figure 3-1 Name Description Audio Out Connects a speaker for audio output. Resets the camera to factory defaults. Default See 23.3 Restoring to Factory Default Settings. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store...

  • Page 61: Installation

    Ultra Box Camera 3.4 Installation You can stand the Ultra Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Ultra Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 62 Connect the network and power cables to the camera. See 3.5 Connecting the Camera. Access the live view. See 19.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw. Figure 3-4...

  • Page 63: Connecting The Camera

    Ultra Box Camera 3.5 Connecting the Camera Figure 3-5 Connect power using one of the following methods: • Plug the power adapter to the 5V terminal block. The power adapter is an optional device. For detail, see Options in the manual.

  • Page 64: Chapter 4 Target Box Camera

    Chapter 4 Target Box Camera The Target Box Camera (GV-EBX) is a series of light-weighted cameras designed for indoor usage. Equipped with IR­cut filter and built­in IR LEDs, the camera is an entry-level surveillance solution with all the essential features and excellent image quality. The camera supports PoE and can be installed intuitively.

  • Page 65: Features

    Target Box Camera 4.2 Features • 1/3” progressive scan low lux CMOS for GV-EBX1100 Series • Dual streams from H.264 or MJPEG Up to 30 fps at 1280 x 1024 for GV-EBX1100 Series • Intelligent IR • Day and night function (with removable IR-cut filter) •...

  • Page 66: Overview

    4.3 Overview Figure 4-1 Name Description Resets the camera to factory defaults. Default See 23.3 Restoring to Factory Default Settings. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. DC 12V Terminal Block Connects to power. LED Indicator Description The status LED turns on (green) when the system...

  • Page 67: Installation

    Target Box Camera 4.4 Installation You can stand the Target Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Target Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 68 Connect the network and power cables to the camera. See 4.5 Connecting the Camera. Access the live view. See 19.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw. Figure 4-4...

  • Page 69: Connecting The Camera

    Target Box Camera 4.5 Connecting the Camera Figure 4-5 Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual.

  • Page 70: Chapter 5 Ir Arctic Box Camera

    IR Arctic Box Camera Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, GV-BX120D-E mm, F/1.4, 1/3” CS Low Lux, D/N Lens Auto Iris, f: 2.8 ~ 6 mm, GV-BX220D-E 2 MP, H.264, D/N F/1.3, 1/3’’...
  • Page 71 IR Arctic Box Camera Model No. Specifications Description P-Iris, f: 3.7 ~ 9 mm, 2 MP, H.264, GV-BX2510-E F/1.2, 1/2’’, ø 14 Super Low Lux, mm mount Motorized Varifocal Lens P-Iris, f: 4.5 ~ 9 mm, 5 MP, H.264 GV-BX5310-E F/1.2, 1/2’’, ø...

  • Page 72: Packing List

    5.1 Packing List For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E • IR Arctic Box Camera • Screw Anchor x 4 • Screw x 4 • Washer x 4 • 4 mm Torx Wrench •...
  • Page 73 IR Arctic Box Camera For GV-BX2510-E / 5310-E • IR Arctic Box Camera • Screw Anchor x 4 • Screw x 4 • Washer x 4 • 5 mm Torx Wrench • Silica Gel Bag • Adhesive Tape • Power Adapter (DC 48V, 2.5A, 120 W max.) •...

  • Page 74: Features

    5.2 Features • Image sensor Camera Model Image Sensor GV-BX120D-E 1/3" progressive scan low lux CMOS GV-BX1500-E 1/3" progressive scan super low lux CMOS GV-BX220D-E GV-BX320D-E 1/3.2" progressive scan CMOS GV-BX520D-E GV-BX5300-E GV-BX2510-E 1/2.8” progressive scan super low lux CMOS...
  • Page 75 IR Arctic Box Camera • P-Iris for auto iris adjustment (for GV-BX2510-E / 5310-E) • Vandal resistance (IK10 for metal casing) • Built-in heater and fan • Support for TV-out • Micro SD card slot (SD/SDHC) for local storage (for GV-BX2510-E / 5310-E) •...

  • Page 76: Overview

    5.3 Overview 5.3.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400 -E / 3400-E / 5300-E Figure 5-1 Note: The Iris Screw (No. 7) is only available in GV-BX520D-E and GV- BX5300-E. Name Description Silica gel bag Desiccant that keeps the camera housing dry.

  • Page 77: Gv-Bx2510-E / 5310-E

    IR Arctic Box Camera 5.3.2 GV-BX2510-E / 5310-E Figure 5-2 Name Description Silica gel bag Desiccant that keeps the camera housing dry. Memory Card Inserts a micro SD card (SD/SDHC, version Slot 2.0, Class 10) to store recording data. Turns on when the camera is supplied with Power LED power.

  • Page 78: Installation

    5.4 Installation The IR Arctic Box Camera is designed for outdoor use. Follow the steps below to install your camera. Mark the installation site and drill four holes for screw anchors. Insert the supplied screw anchors. Secure the camera to the wall using the supplied washers and screws. Figure 5-3 Connect the camera with wires and cables.
  • Page 79 Pan Adjustment Figure 5-6 For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E , adjust for image clarity based on the live view. A. Unscrew the cover with the supplied 4 mm torx wrench.
  • Page 80 B. Hold and unplug the connector. Figure 5-8 IMPORTANT: Unscrew and remove the cover carefully. Pulling the cover off may cause damages to the inner wiring of the camera. C. Adjust the focus, zoom and iris screws. For a more precise focus, use GV-IP Device Utility.
  • Page 81 IR Arctic Box Camera D. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the sticker several times onto the camera cover to make sure it adheres properly. Figure 5-10 E. Follow steps 7B and 7A to plug the connector back and close the camera cover.
  • Page 82 B. Insert a memory card to the card slot. Memory card slot Figure 5-12 C. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the silica gel bag several times onto the camera cover to make sure it adheres properly.
  • Page 83 IR Arctic Box Camera IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the silica gel bag in the camera within 2 minutes of exposing to open air.

  • Page 84: Connecting The Camera

    5.5 Connecting the Camera 5.5.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E Figure 5-14 Wire Definition RJ-45 Black BNC TV out Green RCA Audio Out Pink RCA Audio In...
  • Page 85 IR Arctic Box Camera Optionally connect a speaker (green) and an external microphone (pink). Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 21.1.1 Video Settings. Connect the camera to a GV-PA481 PoE Adapter as illustrated to supply power and network access.

  • Page 86: Gv-Bx2510-E / 5310-E

    5.5.2 GV-BX2510-E / 5310-E Figure 5-16 Wire Definition Green RCA Audio Out Pink RCA Audio In Brown wire Digital Output Yellow wire Digital Input White wire Terminal Block DC 48V / AC 24V TV Out RJ-45 Ethernet/PoE 1. Optionally connect the audio out (green), audio in (pink), digital output (brown), digital input (yellow), and GND.
  • Page 87 IR Arctic Box Camera 3. Supply the camera with power and network access using one of the following methods: • Use a GV-PA482 Power over Ethernet adapter to connect the camera to power and network as illustrated below. GV-PA482 PoE adapter is an optional accessory.
  • Page 88 Note: The camera also supports AC 24V and a separate power cord is required. 4. You are ready to access the live view.

  • Page 89: Notice For Using The Ir Arctic Box Camera

    IR Arctic Box Camera 5.6 Notice for Using the IR Arctic Box Camera For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E , make sure that you: • enable IR LED function on the Web interface after loading the default settings.

  • Page 90: Enabling Ir Led After Loading Default

    5.6.1 Enabling IR LED after Loading Default Each GV-IR Arctic Box Camera is equipped with 4 IR LEDs to provide infrared illumination at night. The factory-loaded setting for the IR LED function is enabled . If you have restored the camera to default settings, please follow the steps below to enable the IR LED function.

  • Page 91: Disabling Status Led Under Low Light Conditions

    IR Arctic Box Camera 5.6.2 Disabling Status LED under Low Light Conditions If you have a green light spot on the live view, this is likely due to insufficient light at the installation site, which causes the status LED to reflect on the camera cover.

  • Page 92: Chapter 6 Mini Fixed Dome & Mini Fixed Rugged Dome

    Chapter 6 Mini Fixed Dome & Mini Fixed Rugged Dome The Mini Fixed Dome (GV-MFD) and Mini Fixed Rugged Dome (GV-MDR) are fixed, mini-sized ceiling-mount network cameras. The GV-MDR series is designed for outdoor surveillance, conforming to IK10 and IP67 standards. The camera is adjustable in 3 axis (pan, tilt and rotate) and can be connected through PoE.
  • Page 93 Mini Fixed & Rugged Dome Mini Fixed Dome (GV-MFD) Model No. Specifications Description Fixed Iris, f: 4 mm, 1.3 MP Low GV-MFD120 F/1.5, 1/3’’ M12 Lux, H.264, Mount Color Fixed Iris, f: 2.54 mm, 1.3 MP / 2 MP / GV-MFD130 F/2.8, 1/2.5’’...
  • Page 94 Mini Fixed Rugged Dome (GV-MDR) Model No. Specifications Description GV-MDR220 Fixed Iris, f: 2.54 2 MP / 3 MP / 5MP, GV-MDR320 mm, F/2.8, 1/2.5’’ H.264, Color M12 Mount GV-MDR520 GV-MDR1500-1F Fixed Iris, f: 2.8 Fixed 1.3 MP super low GV-MDR3400-1F mm, F/2.0, 1/3’’...

  • Page 95: Packing List

    Mini Fixed & Rugged Dome 6.1 Packing List • Mini Fixed Dome or Mini Fixed Rugged Dome with 3 options for its LAN connector (M12, Waterproof or Non-Waterproof) • Torx Wrench • Self Tapping Screw x 2 • Screw Anchor x 2 •...

  • Page 96: Features

    6.2 Features • Image sensor GV-MFD Camera Model Image Sensor GV-MFD120 1/3’’ progressive scan low lux CMOS GV-MFD130 1/2.5’’ progressive scan CMOS GV-MFD320 1/3’’ progressive scan super low lux GV-MFD1501 series CMOS 1/2.8’’ progressive scan super low lux GV-MFD2501 series CMOS GV-MFD2401 series 1/3.2’’...
  • Page 97 Mini Fixed & Rugged Dome GV-MFD Camera Model Frame Rate GV-MFD120 GV-MFD130 Up to 30 fps at 1280 x 1024 GV-MFD1501 series GV-MFD2401 series Up to 30 fps at 1920 x 1080 GV-MFD2501 series GV-MFD320 Up to 20 fps at 2048 x 1536 GV-MFD3401 series GV-MFD5301 series Up to 10 fps at 2560 x 1920...
  • Page 98 • 2-axis mechanism (GV-MFD series); 3-axis mechanism (GV-MDR series) Camera Type Tilt Rotate GV-MFD series -45° ~ +45° 0° ~ 90° GV-MDR series -45° ~ +45° 0° ~ 90° 0° ~ 360° • Micro SD card slot (SD/SDHC) for local storage •...

  • Page 99: Overview

    Mini Fixed & Rugged Dome 6.3 Overview 6.3.1 GV-MFD120 / 130 / 320 Figure 6-1 Name Description Resets the camera to factory default. See Default Button 23.3 Restoring to Factory Default Settings. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle. Microphone Provides one-way audio.
  • Page 100 LED Name Description 1. Link Turns on when the network is connected. 2. ACT Turns on when data are being transmitted. 3. PWR Turns on when power is on. 4. SW RDY (Status) Turns on when the system is ready.

  • Page 101: Gv-Mfd1501 Series / 2401 Series / 2501 Series / 3401

    Mini Fixed & Rugged Dome 6.3.2 GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series Figure 6-2 Name Description Microphone Receives sound. Pan Screw Loosens the screw to pan. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle.
  • Page 102 Figure 6-3 LED Name Description 1. Link Turns on (green) when the network is connected. 2. ACT Turns on (orange) when data are being transmitted. 3. Status Turns on (red) when the system is ready. 4. Power Turns on (green) when power is on. Note: For details on limitations and requirements of the USB port, refer to Note for USB Storage and WiFi Adapter at the beginning of this manual.

  • Page 103: Gv-Mdr

    Mini Fixed & Rugged Dome 6.3.3 GV-MDR Figure 6-4 Name Description Silica gel bag Absorbs the moisture inside the camera. Prevents water or moisture from entering Conceal paper the camera. Lens Receives image inputs. Rotation Disc Rotates the camera lens. Pan Disc Pans the camera lens.
  • Page 104 Name Description Resets the camera to factory default. See 23.3 Restoring to Factory Default Default Button Settings. Turns red when the power is on. Flashes Power and status orange light twice when the system is ready. LAN LED Turns on when the network is connected. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store...
  • Page 105 Mini Fixed & Rugged Dome Waterproof Connector For this connector type, see 6.4.2 GV-MDR to install the supplied cable connector. Ø27 mm (1.06'') Non-waterproof (Smaller) Connector 16.8 mm (0.66'') 13.8 mm (0.54'')

  • Page 106: Installation

    6.4 Installation To install a Mini Fixed Dome, make sure the installing site is shielded from rain and moisture. 6.4.1 GV-MFD Series Unscrew the housing cover using the supplied torx wrench. Put the camera on the desired location and make 2 marks on the ceiling for screw anchors.
  • Page 107 Mini Fixed & Rugged Dome Adjust image clarity using the GV-IP Device Utility program. For details, see 19.3 Adjusting Image Clarity. Insert a Micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot (No. 7, Figure 6-1). 10.

  • Page 108: Gv-Mdr Series

    6.4.2 GV-MDR Series Paste the installation sticker on the desired location. The arrow should point toward the direction that the camera faces. Drill one hole on each of the two curves for screw anchors. Drill the circle (30 mm in diameter) if you want to run the cable into the ceiling. 30 mm Drill a hole on each...
  • Page 109 Mini Fixed & Rugged Dome Install the cable connector to waterproof the cable. You should have 5 parts: Figure 6-10 Prepare an Ethernet cable with the RJ-45 connector on one end only. Figure 6-11 Connect the Ethernet cable to the camera cable. Paste the sticker to the camera cable and slide in all the components as shown below.
  • Page 110 Move all the components toward the RJ-45 connector, fit item 4 to item 2, secure item 3 to the camera cable and finally secure item 5 to item 2 tightly. Figure 6-13 IMPORTANT: Item 5 must be secured tightly to waterproof the cable.
  • Page 111 Mini Fixed & Rugged Dome Tilt Adjustment Figure 6-15 Rotational Adjustment Figure 6-16 Adjust image clarity using the GV-IP Device Utility program. For details, see 18.2 Adjusting Image Clarity. 10. Insert a Micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot (No.
  • Page 112 IMPORTANT: The silica gel bag loses it effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air. 2.

  • Page 113: Connecting The Camera

    Mini Fixed & Rugged Dome 6.5 Connecting the Camera Refer to the wire definition and illustrations below to connect the power and network. 6.5.1 Wire Definition GV-MFD120 / 130 / 320 The data cable provides connections for power and network access. The wires are illustrated and defined below: Figure 6-18 Wire Color...

  • Page 114: Power And Network Connection

    6.5.2 Power and Network Connection Use one of the following methods to power on and connect your camera to network: • Wired connection with PoE: Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 115: Vehicle Installation

    Mini Fixed & Rugged Dome 6.5.3 Vehicle Installation To install the Mini Fixed Rugged Dome on a vehicle, clip the ferrite core to the camera cable. In accordance to EN 50155, the ferrite core is used for reduction of the cable-based and radiated interferences, ensuring stable image quality.

  • Page 116: Chapter 7 Target Mini Fixed Dome

    Chapter 7 Target Mini Fixed Dome The Target Mini Fixed Dome (GV-EFD) is an indoor, fixed, mini-sized network camera equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adjustable in 2 axis (pan and tilt), it offers an entry-level surveillance solution with all the essential features and excellent image quality.

  • Page 117: Features

    Target Mini Fixed Dome 7.2 Features • 1/3’’ progressive scan low lux CMOS for GV-EFD1100 Series; 1/2.8’’ progressive scan low lux CMOS for GV-EFD2100 Series • Dual streams from H.264 or MJPEG • Up to 30 fps at 1280 x 1024 Up to 30 fps at 1920 x 1080 •...

  • Page 118: Overview

    7.3 Overview Figure 7-1 Name Description Lens Receives image inputs. Pan Screw Loosens the screw to adjust pan angle. Tilt Screw Loosens the screw to adjust tilt angle. Microphone Receives sound. Default Resets the camera to factory default. See 22.3 Button Restoring to Factory Default Settings.

  • Page 119: Installation

    Target Mini Fixed Dome 7.4 Installation The Target Mini Fixed Dome can be installed on the wall or the ceiling. Before installing the camera, make sure the installing site is shielded from rain and moisture. Open the housing cover by turning. Figure 7-2 Place the camera where you want to install it and make 2 marks on the ceiling or the wall for screw anchors.
  • Page 120 Drill the marks and insert the screw anchors. Thread the power and / or network cable(s) through the oval-shaped hole or the cable opening on the side, and connect the camera to network and power. For details, see 7.5 Connecting the Camera. Figure 7-4 Secure the Target Mini Fixed Dome to the ceiling or the wall with the supplied screws.
  • Page 121 Target Mini Fixed Dome Loosen the tile screw and pan screw, adjust the angles based on the live view as needed, and tighten the screws again. Tilt Screw Pan Screw Figure 7-5 Place the housing cover back and turn to secure it.

  • Page 122: Connecting The Camera

    7.5 Connecting the Camera Figure 7-6 Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual. • Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 123: Chapter 8 Target Mini Fixed Rugged Dome

    Chapter 8 Target Mini Fixed Rugged Dome The Target Mini Fixed Rugged Dome (GV-EDR) is an outdoor, fixed, mini- sized network camera equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adhering to IK10 and IP67 standards, it offers an entry-level outdoor surveillance solution with all the essential features and excellent image quality.

  • Page 124: Packing List

    8.1 Packing List • Target Mini Fixed Rugged Dome • Screw x 2 • Screw Anchor x 2 • Focus Adjustment Ring • Installation Sticker • Conduit Converter • RJ-45 Connector • Waterproof Rubber Set (for RJ45) • Waterproof Rubber Set (for RJ45 and DC12V) •...
  • Page 125 Target Mini Fixed Rugged Dome Note: Power adapter can be purchased upon request. You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter with a PG21 conduit connector and a self-prepared conduit pipe (of 1/2’’, 3/4’’...

  • Page 126: Features

    8.2 Features • 1/3’’ progressive scan low lux CMOS for GV-EDR1100 Series; 1/2.8’’ progressive scan low lux CMOS for GV-EDR2100 Series • Dual streams from H.264 or MJPEG • Frame rate Camera Model Frame Rate GV-EDR1100 Series 30 fps at 1280 x 1024 GV-EDR2100 Series 30 fps at 1920 x 1080 •...
  • Page 127 Target Mini Fixed Rugged Dome • 31 languages on Web interface • ONVIF (Profile S) conformant Note: For optimal performance and compatibility, it is highly recommended to use a GV-NAS System.

  • Page 128: Overview

    8.3 Overview Figure 8-1 Name Description Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle. Pan Screw Loosens the screw to adjust pan angle. Default Resets the camera to factory default. See 23.3 Button Restoring to Factory Default Settings. DC 12V Port Connects to power.

  • Page 129: Installation

    Target Mini Fixed Rugged Dome 8.4 Installation The Target Mini Fixed Rugged Dome can be installed on the wall or ceiling. You must use the supplied waterproof rubber set to waterproof the cable. Paste the installation sticker where you want to install, and drill two holes that are at a diagonal.
  • Page 130 Unscrew the three screws as indicated below. A back plate can be separated from the bottom. Figure 8-4 Use the 2 supplied screws to secure the back plate onto the ceiling or the wall where the screw anchors were inserted. Figure 8-5 Prepare an Ethernet cable with the RJ-45 connector on one end only.
  • Page 131 Target Mini Fixed Rugged Dome Remove the waterproof cap from the cable opening and thread the power and / or network cable(s) through the opening. Figure 8-6 Install the supplied waterproof rubber set onto the cable(s). The rubber set has two parts. Item 1 comes in two types. For power cable For network cable For network cable (PoE)
  • Page 132 Connect the supplied RJ-45 connector to the Ethernet cable. Insert the power adapter wires into the terminal block. Figure 8-9 Fit item 1 to item 2, and insert them in the cable opening. Use the supplied ruler to make sure the length of the cable(s) from the bottom of the opening to the end of the cable is under 10 cm.
  • Page 133 Target Mini Fixed Rugged Dome Cap the cable opening with the waterproof cap. Use the supplied concave hexagon wrench to tighten. Figure 8-11 Thread the cable(s) under the black cable holder. You can loosen the screw on the cable holder if needed. Figure 8-12 10.
  • Page 134 13. Adjust image clarity using the GV-IP Device Utility program. For details, see 19.2 Adjusting Image Clarity. 14. Loosen the tile screw and pan screw, adjust the angles based on the live view as needed, and tighten the screws again. Figure 8-13 15.
  • Page 135 Target Mini Fixed Rugged Dome IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air.

  • Page 136: Connecting The Camera

    8.5 Connecting the Camera Figure 8-15 Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual. • Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 137: Chapter 9 Bullet Camera

    Chapter 9 Bullet Camera The Bullet Cameras are specifically designed for outdoors and are weatherproof (IP66 or IP67). They are equipped with IR LEDs for infrared illumination in night vision applications. The WDR Pro models (see 2.2.1 Wide Dynamic Range Pro for details) enhance the image by processing contrasting intensity of light.
  • Page 138 Model No. Specifications Description 1.3 MP, H.264, GV-BL1210 Low Lux, 3X Optical Zoom 2 MP, H.264, GV-BL2410 WDR Pro, 3X Optical Zoom Auto Iris, f: 3 ~ 9 mm, 1.3 MP, H.264, F/1.2, 1/2.7’’ Super Low Lux, GV-BL1510 3X Optical Zoom ø...
  • Page 139 Bullet Camera P-Iris Models (Coming) Model No. Specifications Description 1.3 MP, H.264, GV-BL1500 Super Low Lux 2 MP, H.264, GV-BL2500 Varifocal lens Super Low Lux 3 MP, H.264, GV-BL3400 WDR Pro P-Iris, f: 3 ~ 9 mm, 1.3 MP, H.264, F/1.2, 1/2.7’’...

  • Page 140: Packing List

    9.1 Packing List • Bullet Camera • Lens (Megapixel and Built-In 16 IR LEDs) • Self Tapping Screw x 3 • Plastic Screw Anchor x 3 • Torx Wrench x 2 • Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) •...

  • Page 141: Features

    Bullet Camera 9.2 Features • Image sensor Camera Model Image Sensor GV-BL120D 1/3’’ progressive scan low lux CMOS GV-BL1210 GV-BL1500 1/3’’ progressive scan super low lux CMOS GV-BL1510 GV-BL130D / 220D / 320D 1/2.5’’ progressive scan CMOS GV-BL5310 / 5310-E GV-BL2400 / 2410 1/3.2’’...
  • Page 142 • Ingress protection (IP66 for GV-BL120D / 130D / 220D / 320D) (IP67 for GV-BL1500 / 2400 / 2500 / 3400 / 1210 / 1510 / 2410 / 2510 / 2510-E / 3410 / 5310 / 5310-E) • Vandal resistance (IK10 for metal casing, GV-BL1500 / 2400 / 2500 / 3400 / 1210 / 1510 / 2410 / 2510 / 2510-E / 3410 / 5310 / 5310-E only) •...
  • Page 143 Bullet Camera • Tampering alarm • Visual automation • Text overlay • Privacy mask • IP address filtering • Smart Phone and 3GPP support • 31 languages on Web interface • ONVIF (Profile S) conformant...

  • Page 144: Overview

    9.3 Overview Figure 9-1 Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10). Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. See 23.3.

  • Page 145: Installation

    Bullet Camera 9.4 Installation These instructions describe the basic installation of the Bullet Camera. Slide the cable clamp to the camera base. Cable Clamp Figure 9-2 Install the Bullet Camera to the wall. Figure 9-3 Remove the protection sticker from the camera’s cover Connect the power, network and other wires to the Bullet Camera.
  • Page 146 Access the live view. For details, see 19.1. Accessing the Live View. Adjust angles of the camera body based on the live view. Three shafts can be adjusted. See 9.4.2 Adjusting the Angles. Loosen the camera’s cover, adjust the focus of the camera and optionally insert a micro SD card (SD/SDHC, version 2.0, Class 10) into the SD card slot.

  • Page 147: Connecting The Camera

    Bullet Camera 9.4.1 Connecting the Camera Wire Definition The 7-Pin Data Cable provides connections for power, ground, 1 sensor input, 1 alarm output, audio input and audio output. The wires are illustrated and defined below: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow)
  • Page 148 Note that the Audio In and Out connectors may also come as terminal blocks: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow) Audio In (Brown) Audio Out (Green) Ethernet (PoE) Figure 9-5 Wire Color...
  • Page 149 Bullet Camera Power Connection Use one of the following methods to supply power to the camera. Note that GV-BL2510-E / 5310-E do not support PoE. • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. •...
  • Page 150 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 151: Adjusting The Angles

    Bullet Camera 9.4.2 Adjusting the Angles The Bullet Camera is designed to be adjustable in three shafts for easy and flexible installation. First Shaft You can adjust the camera body by 360 degrees to the right or the left. Unscrew the panning lock screw with the torx wrench. Panning Lock Screw Torx Wrench Figure 9-9...
  • Page 152 Second Shaft You can adjust the camera body up and down by 90, 112.5, 135, 157.5 or 180 degrees by using the gears inside the camera body and the camera base. Unscrew the tilting lock screw with the torx wrench. Tilting Lock Screw Torx Wrench Figure 9-11...

  • Page 153: Bullet Camera

    Bullet Camera Adjust the angle of camera body to 90°, 112.5°, 135°, 157.5° or 180°. Then move the camera base to the left to combine the gears. 180 ° 157.5° 135 ° 112.5° 90° Figure 9-13 Fasten the tilting lock screw. Third Shaft You can adjust the camera base by 360°.
  • Page 154 Adjust the angle of camera base, and fasten the base fixing screw. 0~360° Figure 9-15...

  • Page 155: Adjusting Lens And Inserting A Memory Card

    Bullet Camera 9.4.3 Adjusting Lens and Inserting a Memory Card To adjust the camera’s zoom and focus or to insert a micro SD card (SD/SDHC, version 2.0 only, Class 10), follow the steps below. Loosen the camera’s cover. For GV-BL2510-E / 5310-E, loosen the camera’s cover and the screw as indicated below.
  • Page 156 To adjust for image clarity, follow the steps below. For models with zoom and focus screws, pull out the camera and remove the silica gel bag to access its focus and zoom screws. Use GV-IP Device Utility to help you. For details, see 19.2 Adjusting Image Clarity.
  • Page 157 Bullet Camera Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. Memory Card Slot Figure 9-20 Push the camera back and fasten the fixing screw. Insert a new silica gel bag to the camera module and fasten the camera’s cover within 2 minutes of opening the silica gel bag package.
  • Page 158 IMPORTANT: 1. The silica gel loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time when you open the camera and conceal the gel bag in the camera within two minutes of exposing to the open air. 2.

  • Page 159: Installing The Sun-Shield Cover

    Bullet Camera 9.4.4 Installing the Sun-Shield Cover After setting up the Bullet Camera, now you can install the sun-shield cover to the camera. Fasten the hexagon screws either on top or below the camera. Hexagon Screws Figure 9-23 Put the sun-shield cover on top of hexagon screws. Make sure to aim the rear hexagon screw at the edge of the sun-shield cover’s aperture for optimal sun-shield performance.

  • Page 160: Chapter 10 Ultra Bullet Camera

    Chapter 10 Ultra Bullet Camera The Ultra Bullet Camera is a series of light-weighted cameras designed for outdoor environments. The camera adheres to the IP67 standard and has full protection against dust and jets of water. The Ultra Bullet Cameras are available in motorized varifocal lens and fixed lens at 1.3, 2 and 3 megapixels.
  • Page 161 Ultra Bullet Camera Model No. Specifications Description Fixed Iris, f: 2.8 mm, GV-UBL1301-0F F/2.0, 1/3’’ M12 Lens Mount 1.3 MP, Low Lux, H.264, D/N Fixed Iris, f: 4 mm, GV-UBL1301-1F F/1.5, 1/3’’ M12 Lens Mount Fixed Iris, f: 4 / 8 mm, GV-UBL1301-2F 1.3 MP, Low F/1.6, 1/3’’...

  • Page 162: Packing List

    10.1 Packing List • Ultra Bullet Camera (with Waterproof or Non-Waterproof LAN connector) • Camera Stand • Black Rubber • Self Tapping Screw x 3 • Plastic Screw Anchor x 3 • Torx Wrench • Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) •...

  • Page 163: Features

    Ultra Bullet Camera 10.2 Features • Image sensor Camera Model Image Sensor GV-UBL1211 1/3’’ progressive scan CMOS GV-UBL1301 Series 1/2.5’’ progressive scan CMOS GV-UBL1511 1/3’’ progressive scan super low lux CMOS 1/2.8’’ progressive scan super low lux GV-UBL2511 CMOS GV-UBL2411 / 3411 GV-UBL2401 Series 1/3.2’’...
  • Page 164 • Micro SD card slot (SD/SDHC) for local storage • Intelligent IR • 3D noise reduction (for GV-UBL1511 / 2511) • 2D noise reduction (except for GV-UBL1511 / 2511) • Motion detection • Tampering alarm • Visual automation • Text overlay •...

  • Page 165: Overview

    Ultra Bullet Camera 10.3 Overview Panel Figure 10-1 Name Description Power & I/O Connects to the data cable. For details, see Connector 10.4.2 Connecting the Camera. Resets all configurations to factory default. See 23.3. Restoring to Factory Default Default Button Settings.
  • Page 166 LAN Connector The Ultra Bullet Camera provides two connector types. Select an option based on your installation environment. • Option 1 (Waterproof) To waterproof the cable, install the supplied cable connector. See 10.4.1 Waterproofing the Cable. • Option 2 (Smaller and non-waterproof)

  • Page 167: Installation

    Put the sun-shield cover on top of the hexagon screws. For optimal sun-shield performance, make sure the rear hexagon screw is at the end of the opening. Figure 10-3 IMPORTANT: The GeoVision logo on the sun-shield cover should be closer to the front of the camera.
  • Page 168 Fasten the Philips head screws with the plastic screw spacers. Philips Head Screw Plastic Screw Spacer Figure 10-4 Optionally insert a micro SD card to the camera. Unscrew and open the back panel with the supplied torx wrench. Figure 10-5 Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the card slot.
  • Page 169 Ultra Bullet Camera Replace the silica gel bag. IMPORTANT: 1. The silica gel loses its effectiveness when the dry camera is opened. To keep the interior dry, replace the silica gel bag every time you open the camera and conceal the gel bag in the camera within two minutes of exposing to the open air.
  • Page 170 Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface Figure 10-8 Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 10.4.1 Waterproofing the Cable and 10.4.2 Connecting the Camera.

  • Page 171: Waterproofing The Cable

    Ultra Bullet Camera 10.4.1 Waterproofing the Cable Waterproof the option 1 LAN / PoE cable (see 10.3 Overview) using the supplied cable connector. The cable connector can be dissembled into 5 parts: Figure 10-9 Cut off the RJ-45 connector on one end of the Ethernet cable. Figure 10-10 Connect the Ethernet cable to the LAN / PoE connector (No.
  • Page 172 Move all the components toward the LAN / PoE connector, fit item 4 to item 2, secure item 3 to the LAN / PoE connector (Item A) and finally secure item 5 to item 2 tightly. Figure 10-12 IMPORTANT: Item 5 must be secured tightly to waterproof the LAN / PoE connector.

  • Page 173: Connecting The Camera

    Ultra Bullet Camera 10.4.2 Connecting the Camera Wire Definition The camera’s 4-pin data cable provides connections for power, ground, 1 sensor input and 1 alarm output. The wires are defined below: Figure 10-13 Wire Color Definition DC 5V Green Digital In Blue Digital Out Black...
  • Page 174 Power Connection Connect the camera to power using one of the following methods: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. • Plug the power adaptor to the terminal block as shown below. The power adapter is an optional device.
  • Page 175 Ultra Bullet Camera Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 176: Chapter 11 Target Bullet Camera

    Chapter 11 Target Bullet Camera The Target Bullet Camera (GV-EBL) is a series of light-weighted cameras designed for outdoor environments. The camera adheres to the IP67 standard and has full protection against dust and jets of water. The camera offers an entry­level surveillance solution with all the essential features and excellent image quality.

  • Page 177: Features

    Target Bullet Camera 11.2 Features • 1/3” progressive scan low lux CMOS for GV-EBL1100 Series 1/2.8’’ progressive scan low lux CMOS for GV-EBL2100 Series • Dual streams from H.264 or MJPEG • Up to 30 fps at 1280 x 1024 Up to 25 fps at 1920 x 1080 •...

  • Page 178: Overview

    11.3 Overview Panel Figure 11-1 Name Description Power Connects to the data cable. For details, see Connector 11.5 Connecting the Camera. Resets all configurations to factory default. Default Button See 23.3. Restoring to Factory Default Settings.
  • Page 179 Target Bullet Camera IMPORTANT: The silica gel loses its effectiveness when the camera cover is opened. If you open the camera to access the load default button, replace the silica gel tape by taping the new silica gel tape to the inside of the camera cover. Make sure you conceal the silica gel tape in the camera within two minutes of exposing to the open air.

  • Page 180: Installation

    Slide the sun-shield cover onto the top of the camera. Figure 11-2 Note: The GeoVision logo on the sun-shield cover should be closer to the front of the camera. Line up the screw hole on the camera with the opening on the sun- shield cover.
  • Page 181 Target Bullet Camera Ceiling Mount: Secure the supporting rack to the opening on the sun-shield cover Figure 11-4 Wall Mount: Insert and tighten the supplied screw on the sun-shield cover. Secure the supporting rack to the bottom. Figure 11-5...
  • Page 182 Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface. Figure 11-6 Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 11.5 Connecting the Camera.

  • Page 183: Connecting The Camera

    Target Bullet Camera 11.5 Connecting the Camera Wire Definition The data cable provides connections for power, ground and network access. The wires are defined below: Figure 11-7 Wire Color Definition DC 12V Black Ground Black (thick) PoE, Ethernet...
  • Page 184 Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. • Plug the power adapter to the 12V terminal block as shown below. The power adapter is an optional device.

  • Page 185: Chapter 12 Ptz Camera

    Chapter 12 PTZ Camera The GV-PTZ010D camera is a ceiling-mount device that provides panning, tilting and zooming functions. The camera is designed to monitor a wide area and also to focus on a specific part on the live view when suspicious events occur.

  • Page 186: Packing List

    12.1 Packing List • GV-PTZ010D • Mounting Base • Mounting Cover • Wall Mount Bracket • Screw Anchor x 3 • Long Screw x 3 • Short Screw x 3 • Round Screw x 3 • GV-PTZ010D Software CD • Washer x 3 •...

  • Page 187: Features

    PTZ Camera 12.2 Features • 1/4" CCD image sensor • Dual streams from H.264, MPEG4 or MJPEG • Up to 30 fps at 704 x 480 / Up to 25 fps at 704 x 576 • Day and night function (electronic) •...

  • Page 188: Overview

    12.3 Overview Figure 12-1 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN/PoE Connects to a 10/100 Ethernet or PoE. I/O Terminal Block For details, see 12.7 I/O Terminal Block. Inserts a micro SD card (SD/SDHC, version Memory Card Slot 2.0 only, Class 10) to store recording data.
  • Page 189 PTZ Camera Name Description Turns green when the power is on and Power LED turns off when the power is off. Microphone Records the sounds. Resets to system default settings. For Default details, see 23.3 Restoring to Factory Default Settings.

  • Page 190: Installation

    12.4 Installation The GV-PTZ010D / GV-PT series is designed for indoor usage. Make sure that the installing location is shielded from rain and moisture. There are two ways to mount the PTZ / PT Camera: Ceiling Mount and L-Shaped Wall Mount.
  • Page 191 PTZ Camera Fix the mounting base (now with the PTZ / PT Camera attached) to the wall with 3 long screws. Figure 12-4 Put on the mounting cover. To fit the installation environment, you can cut the parts indicated by arrows to make an opening for wires and cables.

  • Page 192: L-Shaped Wall Mount

    12.4.2 L-Shaped Wall Mount You may wall-mount the GV-PTZ010D / GV-PT series with or without the mounting cover. Take the wall mount bracket and make 2 marks on the wall for screw anchors. wall Figure 12-6 Drill the marks and insert 2 screw anchors. Insert the long screws and leave enough distance (approximately 2 mm) to hang the wall mount bracket later.
  • Page 193 PTZ Camera Hang the wall mount bracket on the screws and push the wall mount bracket downward. Make sure the long screws are tightened. Figure 12-8 Without Mounting Cover Attach the wall mount bracket with the PTZ / PT Camera using 3 washers and 3 round screws.
  • Page 194 With Mounting Cover To install the mounting cover, attach the mounting base to the camera and then put on the mounting cover. See steps 3 and 5 in the Ceiling Mount section. Attach the wall mount bracket with the PTZ / PT Camera using 3 round screws.

  • Page 195: Connecting The Camera

    PTZ Camera 12.5 Connecting the Camera Figure 12-11 Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Connect power using one of the following methods: • plugging the power adapter to the power port. The power adapter is an optional device.

  • Page 196: Focus Adjustment

    12.6 Focus Adjustment On initial installation, it is advised that you adjust the focus for image clarity. Print out the diagram of radiating lines included on Software DVD and hang up the diagram at the surveillance area. Use the Zoom In / Out and Focus In / Out buttons on the PTZ control panel from the Web interface (No.4 and 5, Figure 12-15) and adjust the PTZ Camera until it displays clear radiating lines as shown in picture on the left.

  • Page 197: I/O Terminal Block

    PTZ Camera 12.7 I/O Terminal Block The 3-pin terminal block, located on the back panel of the PTZ Camera, provides the interface to one digital input and one digital output. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 198: Voltage Load Expansion (Optional)

    12.7.2 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC, 10A 125V AC or 5A 100V DC, connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 199: Ptz Control

    PTZ Camera 12.8 PTZ Control After you have installed the PTZ Camera on network and accessed the camera’s Web interface you are ready to configure the PTZ Camera. To see how to install the PTZ Camera on network, see Getting Started, Chapter 19.
  • Page 200 Buttons on the PTZ control panel: Name Description Exit Closes the PTZ control panel. Moves the PTZ Camera to 8 directions: Pan / Tilt Control up, down, left, right, left up, left down, right up and right down. Brings the camera view back to the home Home point where the camera faces front at a 90 degree angle to the base of the device.

  • Page 201: Automatic Focus

    PTZ Camera 12.8.2 Automatic Focus When the camera view is fuzzy, you may use the auto focus feature to obtain a sharper view. On the PTZ control panel, click the Option button (No. 6, Figure 12-15) and select AF for automatic focus. 12.8.3 PTZ Camera Settings Accessing the PTZ Camera Settings To access PTZ camera settings, click the Option button (No.
  • Page 202 PT Speed: Determines the panning (horizontal movement) and tilting (vertical movement) speed when using the Pan / Tilt Control buttons on the PTZ control panel. The drop-down list contains 5 speed settings: 1 is the slowest and 5 the fastest. Zoom Speed: Determines the zooming speed.

  • Page 203: Image Settings

    PTZ Camera 12.8.4 Image Settings Image Setting provides features on iris control, white balance, image orientation and other image processing tools to generate clearer images. To access these features, open the VISCA OSD Configuration dialog box and select Image Setting . [Iris] adjusts the amount of exposure.
  • Page 204 AWB: Automatic White Balance (AWB) automatically compensates for colors under different light levels. AWB is ideal for scenes with a fixed light source. Use the slider to select from 0 to 8. A higher value produces a brighter image and a lower value produces a dimmer image.
  • Page 205 PTZ Camera Freeze: Instantly freezes the live view image when On is selected. AGC: Automatic Gain Control (AGC) utilizes an electronic circuit which amplifies video signal when the signal strength falls below a given value due to lack of the light on the camera. Adjust camera sensitivity to provide clear images.

  • Page 206: Preset Settings

    12.8.5 Preset Settings For PTZ Camera to automatically move toward a point in live view, establish a Preset. A Preset is a point in live view that can be configured and saved for future use. The PTZ Camera allows up to 256 Preset points. For details on the maximum number of Preset points, see 12.8.3 PTZ Camera Settings.
  • Page 207 PTZ Camera Renaming a Preset Point To rename a Preset point: Click the Option button (No. 6, Figure 12-15), select Preset Set and select Naming . The dialog box appears. Figure 12-18 Click the Preset point you wish to rename and type the new name in the blank at the top.
  • Page 208 Starting and Stopping a Preset Point To start a Preset movement, click the Option button (No. 6, Figure 12-15), select Preset Go , and select a Preset number which has been set previously. Alternatively, you may use the number pad on the PTZ control panel to enable a Preset movement: Click the Show Preset button (No.

  • Page 209: Sequence Settings

    PTZ Camera 12.8.6 Sequence Settings For PTZ Camera to automatically perform a series of movements, you can configure a Sequence. A Sequence links up more than two Preset points to form a sequence of movements. Up to 8 Sequences can be created. Configuring a Sequence After you have configured the Preset points you wish the camera to follow (for details, see 12.8.5 Preset Settings), you are ready to...
  • Page 210 Use the Preset drop-down list to select the Preset points for the Sequence. Use the Dwell Time drop-down list to select the staying time that the camera stays at the Preset point. The dwell time ranges from 0 to 127 seconds at an interval of 0.5 second.

  • Page 211: Auto Pan Settings

    PTZ Camera 12.8.7 Auto Pan Settings For the PTZ Camera to survey a horizontal view, establish an Auto Pan. Up to 4 sets of Auto Pan can be created. Configuring an Auto Pan To configure a horizontal movement: Adjust the angle of the camera view using the Up and Down Control buttons since any vertical movements of the camera will not be recorded by Auto Pan.
  • Page 212 Configuring the Speed of Auto Pan You can configure the speed for each set of Auto Pan differently: Open the VISCA OSD Configuration dialog box and select Advance. Figure 12-20 Select the Auto Pan number you wish to configure and select the Speed .

  • Page 213: Rebooting The Camera

    PTZ Camera Starting and Stopping Autopan To start an Auto Pan, click the Option button (No. 6, Figure 12-15), select Auto and select a desired Auto Pan number. The PTZ Camera will first return to the starting position of the selected Auto Pan and proceeds with the selected Auto Pan movement.

  • Page 214: System Configuration

    12.8.8 System Configuration To configure lens settings, open the VISCA OSD Configuration dialog box and select System Configure . Figure 12-21 Zoom + AF: Automatically focuses after zooming. It is advised to use this feature with a zooming distance of at least 1 meter. Digital Zoom: Allows up to 10x Digital Zoom.

  • Page 215: Chapter 13 Pt Camera

    Chapter 13 PT Camera The GV-PT camera is a series of indoor pan and tilt camera that is designed to monitor a wide surveillance area. The camera support remote pan and tilt control and is capable of storing pre-established panning/tilting movements and points on live view for immediate monitoring.
  • Page 216 • Short Screw x 3 • Round Screw x 3 • Terminal Block • Washer x 3 • Power Adapter • GV-IPCAM H.264 Software • GV-IPCAM H.264 Quick Start • GV-NVR Quick Start Guide Guide • GV-NVR Software DVD Note: The power adapter can be excluded upon request.

  • Page 217: Features

    PT Camera 13.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 and MJPEG • Frame rate Camera Model Frame Rate GV-PT130D 30 fps at 1280 x 1024 GV-PT220D 30 fps at 1920 x 1080 GV-PT320D 20 fps at 2048 x 1536 •...

  • Page 218: Overview

    13.3 Overview 6 7 8 Figure 13-1 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN / PoE Connects to a 10/100 Ethernet or PoE. I/O Terminal Block For details, see 13.7 I/O Terminal Block. Inserts a micro SD card (SD/SDHC, version Memory Card Slot 2.0 only, Class 10) to store recording data.
  • Page 219 PT Camera Name Description Turns green when the system operates Status LED normally and turns off when system error occurs. Turns green when the power is on and turns Power LED off when the power is off. Manually rotates this ring left or right to Focus Ring adjust focus.

  • Page 220: Installation

    13.4 Installation For installation procedures of the GV-PT Camera, see 12.4 Installation. 13.5 Connecting the Camera For procedures of connecting the GV-PT Camera, see 12.5 Connecting the Camera. 13.6 Focus Adjustment After you have followed 12.5 Connecting the Camera and connected all the necessary cables and wires, follow the steps below to adjust image clarity.

  • Page 221: I/O Terminal Block

    PT Camera 13.7 I/O Terminal Block The 3-pin terminal block, located on the back panel of the PT Camera, provides the interface to one digital input and one digital output. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 222: Pt Control

    13.8 PT Control The GV-PT Camera shares similar user interfaces and features with the GV-PTZ010D camera. See below for the supported functions and reference. Supported Function Description PT Control Panel The PT camera supports the following buttons on the control panel: Exit, Pan / Tilt Control, Home, Option and Show Preset.
  • Page 223 PT Camera Supported Function Description Sequence A Sequence consists of a series of Preset points. Configure a Sequence to direct the camera to perform s series of movements. For details, see 12.8.6 Sequence Settings. Auto Pan The camera can be configured to monitor the surveillance area in a horizontal movement.

  • Page 224: Chapter 14 Vandal Proof Ip Dome (Part I)

    Chapter 14 Vandal Proof IP Dome (Part I) The Vandal Proof IP Dome is a series of outdoor camera designed for vandal protection. They are equipped with automatic infrared cut filters and IR LED for day and night surveillance. The WDR Pro models can produce clear image for scenes containing contrasting intensity of lights (see 2.2.1 Wide Dynamic Range Pro for details).The super low lux models can display color live view in near darkness.
  • Page 225 Vandal Proof IP Dome (Part I) Model No. Specification Description GV-VD220D (IK10+, Transparent Cover) GV-VD221D 2 MP, H.264, (IK10+, Smoked Cover) Vandal Proof IP GV-VD222D Dome (IK7, Transparent Cover) GV-VD223D Auto Iris, f:3 ~ 9 Varifocal (IK7, Smoked Cover) mm, F/1.3, 1/2.7” ø...

  • Page 226: Packing List

    14.1 Packing List • Vandal Proof IP Dome • Silica Gel Bag x 2 • Screw Anchor x 4 • Torx Wrench • Ceiling Screw x 4 • Blue Screw x 3 • T-Cap Screw x 3 • Small Screw Cap x 3 •...

  • Page 227: Features

    Vandal Proof IP Dome (Part I) 14.2 Features • Image sensor Camera Model Image Sensor GV-VD120D / 121D / 122D / 1/3" progressive scan low lux 123D CMOS 1/3’’ progressive scan super low GV-VD1500 lux CMOS 1/2.8’’ progressive scan super GV-VD2500 low lux CMOS GV-VD2400 / 3400...
  • Page 228 • 3-axis mechanism (pan / tilt / roll) • Micro SD card slot (SD/SDHC) for local storage • One sensor input and alarm output • TV-out support • Two-way audio • 3D noise reduction (for GV-VD1500 / 2500) • 2D noise reduction (except for GV-VD1500 / 2500) •...

  • Page 229: Overview

    Vandal Proof IP Dome (Part I) 14.3 Overview Figure 14-1 Name Description Turns on (green) when the power is on and Power LED turns off when there is no power supply. Turns on (green) when the system operates Status LED normally and turns off when system error occurs.
  • Page 230 Name Description Rotational Screw Loosens to adjust the camera angle. Zoom Screw Adjusts the zoom of the camera. Focus Screw Adjusts the focus of the camera. Silica Gel Bag Absorbs moisture in the camera body.

  • Page 231: Installation

    Vandal Proof IP Dome (Part I) 14.4 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, there are two ways to install the Vandal Proof IP Dome: hard- ceiling mount and in-ceiling mount . Note: You can also install the camera: •...

  • Page 232: Hard-Ceiling Mount

    14.4.1 Hard-Ceiling Mount Figure 14-2 Unpack the camera package and take out the camera body. Unscrew the housing cover Unscrew thread lock...
  • Page 233 Vandal Proof IP Dome (Part I) Unscrew the inner housing Take out the camera body...
  • Page 234 Mark the position of four screw holes on the desired installation location, and drill holes in the marked locations. Drill the ellipse part if you wish to put the wires through it. Figure 14-3 Insert the screw anchors to the 4 holes on the ceiling. Secure the back cover to the ceiling with 4 ceiling screws.
  • Page 235 Vandal Proof IP Dome (Part I) Connect the network, power and other cables to the camera. See 14.5 Connecting the Camera. Access the live view. See 19.1 Accessing the Live View. Based on the live view, adjust the camera to a desired angle as illustrated below.
  • Page 236 Rotational Adjustment Figure 14-7 10. Adjust image clarity using the GV-IP Device Utility program. For details, see 19.2 Adjusting Image Clarity. 11. Screw on the thread lock as shown in step 1. 12. Replace the silica gel bag on the camera body within 2 minutes of opening the silica gel bag package.

  • Page 237: In-Ceiling Mount

    Vandal Proof IP Dome (Part I) 14.4.2 In-Ceiling Mount Figure 14-8 Follow step 1 in 14.4.1 Hard-Ceiling Mount section to remove the housing cover, thread lock and back cover, and take out the camera body. Cut out a circle with a diameter of 142 mm on the ceiling. Insert a blue screw to the indicated holes on the camera body.
  • Page 238 Screw in a plastic clip to the blue screw, hold it with one hand and use a screw driver to rotate the blue screw until the plastic clip moves half way down. Plastic Clip Figure 14-10 Secure a T-cap on top of the blue screw with a small screw cap and a T-cap screw.
  • Page 239 Vandal Proof IP Dome (Part I) Insert the camera to the ceiling with the plastic screws moved inward. Figure 14-12 Move the blue screws out and rotate the blue screw with a screw driver until the plastic clip and the bottom of the camera body clamps the ceiling tightly.

  • Page 240: Connecting The Camera

    14.5 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other cables needed. 14.5.1 Wire Definition The cables of Vandal Proof IP Dome are illustrated and defined below. Shielding ground DC 12V- / AC 24V- DC 12V+ / AC 24V+ Digital in (oragne) Digital out (brown) Ground (yellow)

  • Page 241: Power Connection

    Vandal Proof IP Dome (Part I) 14.5.2 Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. •...

  • Page 242: Voltage Load Expansion (Optional)

    14.5.3 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC . To expand the maximum voltage load to 10A 250V AC , 10A 125V AC or 5A 100V DC , connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 243: Chapter 15 Vandal Proof Ip Dome (Part Ii)

    Chapter 15 Vandal Proof IP Dome (Part II) This chapter describes the features, physical overview and installation of GV-VD1530 / 2430 / 2530 / 3430, GV-VD1540 / 2440 / 2540 / 3440 / 5340 and GV-VD2540-E / 5340-E. These Vandal Proof IP Domes are outdoor cameras designed with IK10+ vandal resistance and IP67 ingress protection.
  • Page 244 Model No. Specification Description 1.3 MP Super Low Lux / 2 MP WDR GV-VD1530 Pro / 2 MP Super GV-VD2430 Varifocal Low Lux / 3 MP GV-VD2530 lens WDR Pro, H.264, GV-VD3430 Vandal Proof IP Dome 1.3 MP Super Low Auto Iris, Lux / 2 MP WDR GV-VD1540...

  • Page 245: Packing List

    Vandal Proof IP Dome (Part II) 15.1 Packing List • Vandal Proof IP Dome • Torx Wrench • 3-Pin Terminal Block • Audio wires • Power Adapter • TV out wire • RJ-45 Connector x 2 • Back Plate • Focus Adjustment Cap (for GV-VD1530 / 2430 / 2530 / 3430 only)
  • Page 246 • Installation sticker • Screw Anchor x 4 Ceiling mount template • Long Screw x 4 • Flat Screw • Silica Gel Bag x 2 • Short Screw x 2 • Sticker (for Silica Gel Bag) • Ruler • Conduit Converter •...
  • Page 247 Vandal Proof IP Dome (Part II) Note: You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter and plastic PG21 conduit connector with a self-prepared 1/2’’ conduit pipe to the camera.

  • Page 248: Features

    15.2 Features • Image sensor Camera Model Image Sensor GV-VD1530 / 1540 1/3" progressive scan super low lux CMOS GV-VD2430 / 2440 1/3.2" progressive scan CMOS GV-VD3430 / 3440 GV-VD2530 / 2540 1/2.8’’ progressive scan super low lux CMOS GV-VD2540-E GV-VD5340 1/2.5’’...
  • Page 249 Vandal Proof IP Dome (Part II) • Ingress protection (IP67 rating) • Wide temperature tolerance: -40°C ~ 50°C / -40°F ~ 122°F (for GV-VD2540-E / 5340-E) • 3-axis mechanism (pan / tilt / roll) • Micro SD card slot (SD/SDHC) for local storage •...

  • Page 250: Overview

    15.3 Overview Figure 15-1...
  • Page 251 Vandal Proof IP Dome (Part II) Name Description The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED (bottom) LED Indicators turns on (green) when the system operates normally and turns off when system error occurs.

  • Page 252: Installation

    15.4 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: You can also install the camera: • on a power box (of the 4" square and double gang type) using the standard package •...
  • Page 253 Vandal Proof IP Dome (Part II) B. Unplug the conduit connector inside the housing and disintegrate the connector. You should have 4 parts: Figure 15-3 C. Remove the terminal block from the power adapter. D. Thread the audio wires (optional), TV out wire (optional), adapter wires and I/O wires (optional) through the conduit entry and then through part 1, 2, 3 and 4 of the conduit connector.
  • Page 254 2.6 mm: Audio, BNC 2 mm: DC12V / AC24V 1.8 mm: DIDO Figure 15-5 IMPORTANT: 1. Use the supplied ruler and leave about 10 cm of power and I/O wires between their connectors and the cable seal; leave at least 11 cm of audio/TV-out wires between their connectors and the cable seal.
  • Page 255 Vandal Proof IP Dome (Part II) Install the Ethernet cable. A. Rotate to remove the indicated cap and the plug inside. Figure 15-6 B. Thread an Ethernet cable (the end with no RJ-45 connector) from the back panel through the cable seal Figure 15-7 IMPORTANT: Use the supplied ruler and leave about 11 cm of the Ethernet cable between the connector and the cable seal.
  • Page 256 Connect the wires to the camera. Install the terminal blocks to the power adapter and I/O devices. See 15.5.1 Power Connection and 15.5.2 I/O Device Connections. Install the supplied RJ-45 connector to the Ethernet cable. Plug all the connectors to the camera panel. Tip: Unscrew the indicated screws and lift the camera to help you connect the wires.
  • Page 257 Vandal Proof IP Dome (Part II) Sort out the wires at the back. You can have the wires come out from position A, B or both. The instructions here describe sorting wires for position A. Figure 15-8 From the back of the camera housing, unscrew and rotate the plate to one side, sort out the wires and secure the plate back.
  • Page 258 Secure the back plate to the ceiling. A. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces. Ceiling mount template Figure 15-10 B. Drill 3 holes for screws. The recommended ones are indicated as ‘1’.
  • Page 259 Vandal Proof IP Dome (Part II) Secure the camera to the ceiling. Secure the safety lock to the camera using a short screw. Use flat screw for number 1 and small screw for number 2. Figure 15-11 Thread all the wires into the ceiling and connect them. Note: To use the TV out function, connect the black BNC connector to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface.
  • Page 260 Secure the camera using the torx wrench Figure 15-12 Access the live view. See 19.1 Accessing the Live View. Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment Figure 15-13...
  • Page 261 Vandal Proof IP Dome (Part II) Tilt Adjustment Figure 15-14 Rotational Adjustment Figure 15-15...
  • Page 262 10. Replace the silica gel bag and secure the camera cover using the torx wrench. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air.

  • Page 263: Connecting The Camera

    Vandal Proof IP Dome (Part II) 15.5 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other wires needed. 15.5.1 Power Connection There are two ways to supply power to the camera: • Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 264: Voltage Load Expansion (Optional)

    15.5.3 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC . To expand the maximum voltage load to 10A 250V AC , 10A 125V AC or 5A 100V DC , connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 265: Chapter 16 Fixed Ip Dome

    Chapter 16 Fixed IP Dome The Fixed IP Dome is a series of indoor camera designed with 3-axis mechanism for easy and flexible installation. The Fixed IP Dome features IR LED for infrared illumination for night surveillance. The WDR Pro models can produce clear image for scenes containing contrasting intensity of lights (see 2.2.1 Wide Dynamic Range Pro for details).
  • Page 266 Model No. Specification Description 1.3 MP Low Lux, H.264, D/N, 3x GV-FD1210 Optical Zoom, Fixed IP Dome 1.3 MP / 2 MP Super Motorized Auto Iris, f: 3 ~ 9 Low Lux, H.264, mm, F/1.2, 1/2.7’’ varifocal GV-FD1510 D/N, 3x Optical Lens ø...

  • Page 267: Packing List

    Fixed IP Dome 16.1 Packing List 16.1.1 Packing List for Hard-Ceiling Mount • Fixed IP Dome • Torx Wrench • Mounting Plate • Short Screw Anchor x 3 • Ceiling Screw x 3 • Plate Screw x 3 • TV-out Wire •...

  • Page 268: Packing List For In-Ceiling Mount

    16.1.2 Packing List for In-Ceiling Mount • In-Ceiling Housing Cover • Mounting Plate • Mounting Bracket x 3 • Copper Pillar x 3 • Copper Pillar Screw x 6 • Bracket Screw x 3 • Thread Lock Screw • Housing Cover Thread •...

  • Page 269: Features

    Fixed IP Dome 16.2 Features • Image sensor Camera Model Image Sensor GV-FD1200 / 1210 1/3’’ progressive scan low lux CMOS GV-FD1500 / 1510 1/3’’ progressive scan super low lux CMOS 1/2.8’’ progressive scan super low lux GV-FD2500 / 2510 CMOS GV-FD2400 / 2410 1/3.2’’...
  • Page 270 • 3-axis mechanism (pan / tilt / roll) • Built-in IR LED • Micro SD card slot (SD/SDHC) for local storage • One sensor input and alarm output • TV-out support • Two-way audio • 3D noise reduction (for GV-FD1500 / 1510 / 2500 / 2510) •...

  • Page 271: Overview

    Fixed IP Dome 16.3 Overview 10 11 12 13 14 15 Figure 16-1 Name Description Focus Screw Adjusts the focus of the camera. Zoom Screw Adjusts the zoom of the camera. Rotational Screw Loosens to adjust the camera angle. Tilt Screw Loosens the screw to tilt the camera.
  • Page 272 Name Description Audio In Connects a microphone for audio input. Audio Out Connects a speaker for audio output. LAN / PoE Connects to a 10/100 Ethernet or PoE. Connects I/O devices. For details, see I/O Terminal Block 13.6 I/O Terminal Block. DC 12V Port Connects to power.

  • Page 273: Installation

    Fixed IP Dome 16.4 Installation The Fixed IP Dome is designed for indoors. With the standard packing, there are three ways to install the Fixed IP Dome: hard-ceiling mount, in- ceiling mount and wall-surface mount. Note: You may also install the camera to ceilings, wall corners (concave or convex), and poles with optional mounting kits.
  • Page 274 Unpack the camera package and take out the camera body. Use the torx wrench to loosen the housing cover at the front and the back. Figure 16-3 Take out the camera body Figure 16-4 Secure the camera body to the mounting plate with three ceiling screws.
  • Page 275 Fixed IP Dome Connect the network, power and other cables to the camera. See 16.5 Connecting the Camera. Access the live view. See 19.1 Accessing the Live View. Based on the live view, adjust the camera to a desired angle as illustrated below.
  • Page 276 Rotational Adjustment Figure 16-8 Adjust image clarity using the GV-IP Device Utility program. For details, see 19.2 Adjusting Image Clarity. Secure the housing cover as shown in step 2. Remove the indicated part when necessary. Figure 16-9 Note: Adjust the black mask inside the housing cover to make sure the camera view is not obscured.

  • Page 277: In-Ceiling Mount

    Fixed IP Dome 16.4.2 In-Ceiling Mount Figure 16-10 Follow step 2 in the 16.4.1 Hard-Ceiling Mount to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the ceiling and cut a circle on the ceiling along the edge of the sticker. On the mounting plate, locate the 3 holes labeled as 1 and insert the 3 copper pillars from the back side.
  • Page 278 From the side with the numbering, secure the copper pillars with 3 copper pillar screws. Figure 16-12 Place the 3 mounting brackets at the indent next to the copper pillars (labeled as 2 on the mounting plate) and secure them using the 3 bracket screws.
  • Page 279 Fixed IP Dome Place the mounting plate on the camera body with the copper pillars inserted in the locations indicated below. The arrow on the mounting plate should be pointing toward the front of the camera. Figure 16-14 From the bottom of the camera, secure the copper pillars using the 3 copper pillars screws.
  • Page 280 14. Use the housing cover thread and the thread lock screw to attach the housing cover to the camera body. Figure 16-16 15. Place the housing cover on the camera body with the GeoVision logo pointing toward the front of the camera. Figure 16-17...

  • Page 281: Wall-Surface Mount

    Fixed IP Dome 16.4.3 Wall-Surface Mount Figure 16-18 Follow step 2 in 16.4.1 Hard-Ceiling Mount section to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the wall. Drill the three red dots, and the ellipse mark only if you wish to run the wires into the wall.
  • Page 282 Access the live view. See 19.1 Accessing the Live View. Follow steps 6 and 7 in 16.4.1 Hard-Ceiling Mount section to adjust the angle, focus and zoom of the camera. Follow step 8 in 16.4.1 Hard-Ceiling Mount section to secure the housing cover.

  • Page 283: Connecting The Camera

    Fixed IP Dome 16.5 Connecting the Camera Figure 16-20 Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface.

  • Page 284: I/O Terminal Block

    16.6 I/O Terminal Block The terminal block, located on the back panel of the Fixed IP Dome, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 285: Voltage Load Expansion (Optional)

    Fixed IP Dome 16.6.2 Voltage Load Expansion (Optional) The camera on its own can only drive a maximum load of 200mA 5V DC. To expand the maximum voltage load to 10A 250V AC / 10A 125V AC / 5A 100V DC), connect the camera to a GV-Relay V2 module (optional product).

  • Page 286: Chapter 17 Cube Camera

    Chapter 17 Cube Camera The Cube Camera is a light weighted wired / wireless network camera designed for indoor usage. Its simple design allows for fast and easy installation and fixed-spot surveillance once installed. Four models are available: Model No. Specification Description 1.3 MP, H.264, Cube...

  • Page 287: Packing List

    Cube Camera 17.1 Packing List • Cube Camera • Supporting Rack • Screw x 3 • Screw Anchor x 3 • GV-IPCAM H.264 Quick • Power Adapter Start Guide • GV-IPCAM H.264 Software • GV-NVR Quick Start Guide • GV-NVR Software DVD Note: The power adapter can be excluded upon request.

  • Page 288: Features

    17.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 or MJPEG • Frame rate Camera Model Frame Rate GV-CB120 30 fps at 1280 x 1024 GV-CB220 30 fps at 1920 x 1080 • Day and night function (electronic) •...

  • Page 289: Overview

    Cube Camera 17.3 Overview Figure 17-1 Name Description Microphone Receives sounds. Speaker Plays sounds. Connects to a 10/100 Ethernet. Turns red when the system powers on. Status LED Turns orange when the system is ready. Turns green when the camera is connected LAN LED to the Internet through wires.

  • Page 290: Installation

    17.4 Installation Follow the steps below to install, connect to and adjust your Cube Camera and Wireless Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Figure 17-2 Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws.
  • Page 291 Cube Camera Connect the network and power cables to the camera. See 17.5 Connecting the Camera. Access the live view. See 19.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw. Figure 17-4...

  • Page 292: Connecting The Camera

    For detail, see Options in the manual. The status LED of the camera will be orange. IMPORTANT: Be sure to use the GeoVision power adapter to power up the camera. To use your own power cable, make sure you look up the...

  • Page 293: Chapter 18 Advanced Cube Camera

    Chapter 18 Advanced Cube Camera The Advanced Cube Camera integrates the passive infrared (PIR) sensor and the alarm LED to illuminate the scene automatically when the motion is detected. It also offers wireless connection to the network for flexible installation. It is small, light, and easy-to-use for indoor security. We provide four models: Model No.

  • Page 294: Packing List

    18.1 Packing List • Advanced Cube Camera • Supporting Rack • Screw x 3 • Screw Anchor x 3 • GV-IPCAM H.264 Quick • Power Adapter Start Guide • GV-IPCAM H.264 Software • GV-NVR Quick Start Guide • GV-NVR Software DVD •...

  • Page 295: Features

    Advanced Cube Camera 18.2 Features • 1/2.5’’ progressive scan CMOS • Dual streams from H.264 or MJPEG • Frame rate Camera Model Frame Rate GV-CA120 / CAW120 30 fps at 1280 x 1024 GV-CA220 / CAW220 30 fps at 1920 x 1080 •...

  • Page 296: Overview

    18.3 Overview 2 3 4 5 6 7 Figure 18-1 Name Description Plays sounds for tampering and motion alarm, and listens to the audio around the Speaker camera. To set up alarm sound, see 21.3.9 Speaker. PIR sensor Passive infrared sensor. Microphone Receives sounds.
  • Page 297 Advanced Cube Camera Name Description Reflects system status of the camera. See Ready LED the below table. Reflects LAN status of the camera. See the LAN LED below table. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store recording data.

  • Page 298: Installation

    18.4 Installation Follow the steps below to install, connect to and adjust your Advanced Cube Camera and Wireless Advanced Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Figure 18-2 Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws.
  • Page 299 Advanced Cube Camera Connect the network and power cables to the camera. See 18.5 Connecting the Camera. Access the live view. See 19.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 300: Connecting The Camera

    18.5 Connecting the Camera Figure 18-5 Use a standard network cable to connect the camera to your network. Connect power using one of the following methods: • plugging the power adapter to the power port. The power adapter is an optional device. For detail, see Options in the manual. •...

  • Page 301: Chapter 19 Getting Started

    Chapter 19 Getting Started This section provides the initial a nd basic configurations of the GV-IPCAM H.264. 19.1 Ac cessing the Live View Access or configur e your camera according to the camera type and its firmware version: Camera Type & Default Connection Type Firmware Versio •...
  • Page 302 • GV-PTZ010D camera is connec ted to the network. To avoid IP conflict with other GeoVision IP devices, it is advisable to re-assign a different IP address. See 19.1.2 Configuring the IP Address for more detail.

  • Page 303: Checking The Dynamic Ip Address

    Getting Started 19.1.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Install the GV-IP Device Utility program incl uded on the GV-IPCAM H.264 Software DVD. Note: The P C installed w ith GV-IP Device Utility m ust be under the...
  • Page 304 Find the camera with its Mac Address, click on its IP address and select Web Page. Figure 19-2 The login page appears. Figure 19-3 Type the default ID and password admin and click Apply to log in.

  • Page 305: Configuring The Ip Address

    Getting Started 19.1.2 Configuring the IP Address Follow the steps below to configure the IP addres pen your web browser, and type the default IP address http://192.168.0.10. In both Login and Password fields, type the default value admin. Click Apply. In the left menu, select Network and then LAN to begin the network settings.
  • Page 306 IMPORTANT: If Dynamic IP Address or PPPoE is enab led, you need to know which IP address the camera will get from D HCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP addres s.

  • Page 307: Configuring The Wireless Connection

    Getting Started 19.1.3 Configuring the Wireless Conn ection You may create wireless connection to the Internet for: • Box Camera: GV-BX1200 series / 1300 serie s / 1500 series / 2400 series / 2500 s eries / 3400 series / 5300 series •...
  • Page 308 B. Type the Network Name (SSID) or click the Access Point Survey button to search and select for the avai lable Access Points/wireless stations. C. S elect Ad-Hoc or Infrastructure for the Network type. D. Select the Authentication Type using the drop-dow n list.
  • Page 309 Getting Started Enable wireless LAN. A. On the Web interface, select Network and LAN. This page appears. Figure 19-6 B. Select Wireless for Optional Network Type. C. To use a dynamic IP address assigned by the DHCP server, select Dynamic IP address. To use a fixed IP address, select Static IP address and type the IP address information.
  • Page 310 Click Apply. The Camera will start creating a wireless connection to the access point. Note: For GV-CAW12 0/220, the LAN LED (No. 5, Figure 17-1; No.11, Figure 18-1) turns blue when the connection is established. Unplug the Ethernet cable.

  • Page 311: Adjusting Image Clarity

    Getting Started 19.2 Adjusting Image Clarity Note the procedures described in this section only a pply to Box Camera, IR Arctic Box Camera, Bullet Camera, PT Camer a, Vandal Proof IP Dome, Mini Fixed Dome, Mini Fixed Rugged Do me, Target Mini Fixed Dome, Target Mini Fixed Rugged Dome, and Fixed IP Dome.
  • Page 312 Select Focus Value. The Login dialog box appears. Figure 19-8 Type the user name and password of the camera selected. The default is admin for both user name and password. This window appears. Figure 19-9 For IK10+ models (GV-VD120D / 121D / 220D / 221D / 320D / 321D / 1500 / 2400 / 2500 / 3400 / 1530 / 2430 / 2530 / 3430), hold the supplied Focus Adjustment Cap over the camera view.
  • Page 313 Getting Started For Target Mini Fixed Dome and Target Mini Fixed Rugged Dome, hold the camera cover close to the lens and use the supplied focus adjustment tool for precise focus adjustment. For Mini Fixed Dome and Mini Fixed Rugged Dome, hold the camera cover close to the lens for precise focus adjustment.

  • Page 314: Using Focus Adjustment Cap

    19.2.1 Using Focus Adjustment Cap The Focus Adjustment Cap is only supplied for IK10+ models (GV-VD120D / 121D / 220D / 221D / 320 D / 321D / 1500 / 2400 / 2500 / 3400 / 1530 / 2430 / 2530 / 3430). Hold the Focus Adjustment Cap on top of the camera view and keep it close to the camera.

  • Page 315: Locations Of Adjustment Screws

    Getting Started 19.2.2 Locations of Adjustment Screws Models Adjustment Screws Zoom Screw Focus Screw Box Camera Zoom Screw Focus Screw Bullet Camera Focus Screw Zoom Screw Vandal Proof IP Dome Focus Screw Zoom Screw Fixed IP Dome...
  • Page 316 Models Adjustment Screws Lens Screw Focus Ring GV-MFD120 / 130 / 320 Focus Ring GV-MFD1501 / 2401 / 3401 / 5301 Focus Ring Lens Screw GV-MDR220 / 320 GV-MDR1500 / 3400 / Focus Ring 5300...
  • Page 317 Getting Started Note: The adjustment screws of Box Camera ma y vary for different models. To focus GV-MFD and GV-MDR, loosen the lens screw first and slowly adjust the focus ring. Some models may need a T6 screw driver to loosen the camera lens. If you have a problem of obtaining this type of screw driver, please contact our overseas offices for further assistance.

  • Page 318: Configuring The Basics

    19.3 Configuring the Basics Once the camera is properly installed, the following important features can be configured using the browser-based configurat ion page and are discussed in the following sections in this man ual: • Date and time adjustment: see 21.8.1 Date & Tim e Settings.

  • Page 319: Chapter 20 Accessing The Camera

    Chapter 20 Accessin g the Camera Two types of users are allowed to log on to the GV-IPCAM H.264: Administrator and Guest. The Administrator has full access to all system configurations, while the Guest can only access the live view (except the Camera Adjustment settings) and network status.

  • Page 320: Accessing Your Surveillance Images

    Click Apply. A video image, similar to the example on Figure 20-2, is now displayed in your browser. Note: To enable the updating of images in Internet Explorer, you must set your browser to allow ActiveX Controls and perform a once-only installation of GeoVision’s ActiveX component onto your computer.

  • Page 321: Functions Featured On The Main Page

    Accessing the Camera 20.2 Functions Featured on the Main Page This section introduces the features of the Live View window and Network Status on the main pag e. The two features are accessible by both Administrator and Guest. ain Pag e of Guest Mode ▼...

  • Page 322: The Live View Window

    20.2.1 The Live View Window Inte rnet Explorer When accessing the live view using Internet Explorer, the following window appears. Figure 20-3A...
  • Page 323 Accessing the Camera 12 13 Figure 20-3B...
  • Page 324 No. Name Function 1 Play Plays live video. 2 Stop Stops playing video. Broadcasts to the survei llance site from a remote PC. Note this function is n ot available for Ultra Bullet Camera and Target S eries. For Cube Camera and Advanced Cube Camera, you can 3 Micropho...
  • Page 325 Accessing the Camera No. Name Function Brings up these f unctions: Alarm Notify, Video and Audio Configu ration, Remote Config, Show Camera Name and I mage Enhance. Show Sy stem --- See 20.2. 6 Alarm Notification, Menu 20.2.7 Video and Audi o Configuration, 20.2.8 Remote Config uration,...
  • Page 326 Non-IE Browsers When accessing the live view using Google Chrome, Firefox or Safari, this window appears. Note the following functions are not supported on non-IE browsers: Motion Detection, Tampering Alarm, Visual Automation, Text Overlay and Two-Way Audio. Figure 20-4...

  • Page 327: The Control Panel Of The Live View Window

    Accessing the Camera 20.2.2 The Control Panel of the Live View Window To open the control panel of the Live View window, click the arrow button on top of the window. You can access the following functions by using the right and left arrow buttons on the control panel.
  • Page 328 [Information] Displays the version of the camera, time of the local computer, time of the camera (host time), the nu mber of users logging in the camera and the OCX registration path. [Video] Displays the current video codec, resolu tion and data rate. [Audio] Displays the audio data rates when the micr ophone and speaker devices are enabled.
  • Page 329 Accessing the Camera Image Orientation: Changes the image orient ation on the Live View window. Slowest Shutter Speed: Shutter speed controls t he amount of the lights enters the image sensor and directly impa cts the quality of image presentation. A slow shutte r speed allows higher light exposure that creates a brighter overall image by blurring moving obj ects and bringing...
  • Page 330 Zoom: Click the Zoom In and Zoom Out buttons to adjust the apparent distance of the scene. After zooming the c amera, re-focus the camera manually or automatically. For details, s ee Focus Change and cus Mode below. Focus Change: Click the Focus In and Focus Out buttons to adjust the focus.
  • Page 331 Accessing the Camera Figure 20-6B Figure 20-6C Figure 20-6A...
  • Page 332 Note: GV-PTZ010D only contains the Gamma feature. Saturation is not available for GV-PTZ010D Slowest Shutter Speed and Defog is no t available for GV- BX140DW. D/N, Slowest Shutter Speed and Defog are not available for GV- PTZ010D. D/N sensitivity adjustment is not availabl e for GV-BX140DW which automatically detects light with its bu ilt-in light sensor.

  • Page 333: Snapshot Of Live Video

    Accessing the Camera 20.2.3 Snapshot of Live Video To take a snapshot of live video, follow these steps Click the Snapshot button (No. 5, Figure 20- 3). The Save As dialog box appears. Specify Save in, type the File name, and select JPEG or BMP as Save as Type.

  • Page 334: Picture-In-Picture And Picture-And-Picture View

    20.2.5 Picture-in-Picture and Picture-an d-Picture View The full screen mode provides two types of close-up views: Picture-in- Picture (PIP) and Pi cture-and Picture (PAP). The two views are useful to provide clear and detailed images of the surveilla nce area. Picture-in-Picture View With the Picture in Picture (PIP) view, you can crop the video to get a close-up view or zoom in on the video.
  • Page 335 Accessing the Camera Picture-and-Picture View With the Picture and Picture (PAP) view, you can create a split video effect with multiple close-up views on the image. A total of 7 close-up views can be defined. Figure 20-8 Right-click the live view and select PAP. A row of three inset windows appears at the bottom.
  • Page 336 To delete a navigation box, right-click the desired box, select Focus Area of PAP Mode and click Delete. To exit the PAP view, right-click the image and click PAP again.

  • Page 337: Alarm Notification

    Accessing the Camera 20.2.6 Alarm Notification After input triggers and motion detection, you can be alerted by a pop-up live video and view up to four captured images. Pop-up live Captured video images video Figure 20-9 To configure this function, click the Show System Menu button (No. 8, Figure 20-3), and select Alarm Notify.
  • Page 338 I/O Alarm Notify: Once the input device is tri ggered, the captured images are displayed on th e control panel of the Live View window. For this function to work, the Administrator needs to install the input device properly. See 21.2.1 Input Setting. Alert Sound: Activates the computer alarm on motion and input- triggered detection.

  • Page 339: Video And Audio Configuration

    Accessing the Camera 20.2.7 Video and Audio Configur ation You can enable the microphone and speaker for two-way audio communication and adjust the audio volume. To change audio configuration, click the Show System Menu bu tton (No. 8, Figure 20-3), and select Video and Audio Configuration.
  • Page 340 Audio Configure: You can enable the microphone and speaker, and adjust the audio volume Figure 20-12...

  • Page 341: Remote Configuration

    Accessing the Camera 20.2.8 Remote Configuration You can upgrade firmware over the network. Click the Show System Menu button (No. 8, Figure 20-3), and select Rem ote Config. The Remote Config dialog box will appear. [Firmware Upgrade] In th is tab, you can upgrade the firmware over the Internet.

  • Page 342: Visual Ptz

    20.2.11 Visual PTZ Note this feature is only available in PTZ Camera and PT Camera. The Visual PTZ prov ides two types of PTZ control panels on live images for easy and direct TZ operation. Activating Visual PTZ Click the PTZ Control button (No.
  • Page 343 Accessing the Camera Figure 20-15 T e Visual P TZ P anel provides the following features: Name Description Shortens the apparen t distance between the Zoom In camera and the view. Lengthens the apparent di stance between the Zoom era and the view. Focus In Adjust s the sharpness of the camera view.
  • Page 344 Setting Visual PTZ Panel Click the .button on the top left corner and select Visual PTZ, the following options will appear. PTZ Control Type: Two types of visual PTZ co ntrol panels are available. Type 1: Appears only when a movement of the cursor is detected and disappears when it is static.

  • Page 345: Digital Ptz

    Accessing the Camera 20.2.12 Digital PTZ Note this function is only supported by firmware V2.06. This function allows non-PTZ cameras to simula te PTZ movements on live view. Right-click the live view and select Digital PTZ. The live view is labeled with “DPTZ”...
  • Page 346 To pan and tilt the view, zoom the image first and then click and hold the arrow on the imag e. The arrow appears when you place the cursor in one of the eight directions, i.e. up, down, left, right, left up, left down, right up and right down.

  • Page 347: I/O Control

    Accessing the Camera 20.2.13 I/O Control Note this function is only supported by cameras wi th I/O function. The I/O Control window provides a real-time graphic display of camera status, I/O status, and alarm events. Additionally, you can remotely force output to be triggered.

  • Page 348: Visual Automation

    20.2.14 Visual Automation Note this function is only supported by cameras with I/O function. The Visual Automation allows you to change the current state of the electronic device by simply clicking on its image, e.g. turning the light ON. This feature is only available when the Visual Automation is set ahead by the Administrator.

  • Page 349: Network Status

    Accessing the Camera 20.2.15 Network Status To view the network status, in the left menu, click Network and select Status. Figure 20-21...

  • Page 350: Chapter 21 Administrator Mode

    Chapter 21 Administra tor Mode The Administrator can access the system configurati on through the network. Eight categories of configurations are involved in the system configuration: Video and Motion, I/O Control or Digital I/O and PTZ, Events and Alerts, Monitoring, Recording Schedule, Remote ViewLog, Network and Management.
  • Page 351 Administrator Mode List of Menu Options Find the topic of int erest by referring to the section number prefixed to each option. The availabl e options vary among camera models. 21.1.1 Video Settings 21.1.1 M otion Detection 21.1.3 Privacy Mask 21.1 Video and M otion 21.1...
  • Page 352 21.8.1 Date and Time Settings 8.2 Storage Settings 8.3 User Account 21.8 Management 21.8.4 Log Information 21.8.5 Tools 21.8.6 Language...

  • Page 353: Video And Motion

    Administrator Mode 21.1 Video and Motion The GV-IPCAM H.264 can simultaneously process one vi deo source in two different codec and resolutions. The dual-stream d esign benefits for lower bandwidth environment, allowing Streaming 2 t o be set with lower resolution and codec for live streaming , and Streaming 1 set with highest resolution and c...

  • Page 354: Video Settings

    21.1.1 Video Settings Figure 21-2A...
  • Page 355 Administrator Mode Figure 21-2B...
  • Page 356 Figure 21-2C [Name] Rename the video stream. To display the name of video stream on the Live View window, see 20.2.9 Camera Name Display. [Connection Template] Select the type of your network connection. Unless you select Customized, this option will automatically bring up the recommended video resolution, frame rate, bandwidth and GOP size.
  • Page 357 Administrator Mode Note that for all the cameras (except GV-PTZ010D ), the resolution options available for sub stream vary with the resolution sel ected for its main stream. For example, if a 4:3 resolution is selected for the main stream in GV-BX320D-0, two options, 640 x 480 and 320 x 2 40 will be available for its sub stream.
  • Page 358 CBR (Constant Bitrate): CBR is used to achieve a specific bitrate by varying the quality of the H.264 stream. Select one of the bitrates from the drop-down list. [Region of Interest] Note this function is not s upported for Target Series. Sets ROI (clarity) and privacy masks to specified regions on the live view for standalone GV-IP Cameras, GV-IP Cameras connecting to GV-System...
  • Page 359 Administrator Mode To set up a region with enhanced clarity, select ROI, select High, Medium or Low using the drop-down list and then drag on the image to outline a region. To set a Privacy Mask, select Privacy Mask, optionally change the color using the drop-down list and then drag on the image to outline a region.
  • Page 360 Web interface or any other applications. [Text Overlay Settings] Displays camera name, date, and/or time on the live view and recorded videos when viewing through GeoVision software. Camera Name: Type the camera name. Overlay with: Select one or more of the options below to be overlaid on the live view and recorded videos.
  • Page 361 I/O function. [Text Overlay Settings (OSD)] Displays camera name, date, and/or time on the live view and recorded videos when viewing through GeoVision software and third-party software through ONVIF an d RTSP. Name: Typ e the camera name.
  • Page 362 [TV Out] Note this function is only available for Box Camera, IR Arctic Box Camera, Vandal Proof IP Dome and Fixed IP Dome. Select the signal format of the Video Output on the camera as either NTSC or PAL. Note: For smooth display of Box Camera, IR Arctic Box Camera, Fixed IP Dome and Vandal Proof IP Dome on TV m onitor, the video resolution must be 1280 x 1024 or lower.
  • Page 363 Administrator Mode [Special View Setting] D/N: Sets the sensitivity of day-night mode switch. The higher the sensitivity value, the more sensitive the switc h is from day mode to night mode. The default value is 5. Auto: Select Auto for the camera to det ect the amount of light present and automatically switch to monochrome in a poorly-lit...
  • Page 364 Iris Type: Note this function is not supported for GV-IP Cameras with fixed lens or fixed iris. This field shows the iri s type (DC-Iris or P-Iris) of your GV-IP Camera. to Iris: The option is designed for auto iris lens (DC-Iris or P- Iris).

  • Page 365: Motion Detection

    Administrator Mode 21.1.2 Motion Detection Note for firmware V1.07 or later and the Target Series (except GV- PTZ010D), motion detection is disabled by default; f or GV-PTZ010D, motion detection is enabled by default. Motion detection is used to generate an alarm whenever movement occurs in the video image.
  • Page 366 Select the desired sensitivity by moving the slider. There are ten values. The higher the value, the more sens itive the camera is to motion. ag an area on the image. Click Add when you are prompted to confirm the setting. To create several areas with different sensi tivity values, repeat steps 1 and 2.

  • Page 367: Privacy Mask

    The Privacy Mask function is used to block out se nsitive areas on live view recorded clips for cameras connecting to GeoVision software. This feature is ideal for locations with displays, keyboard sequences (e.g. passwords), and for anywhere else you don’t want sensitive information visible.

  • Page 368: Text Overlay

    21.1.4 Text Overlay The Text Overlay allows you to overlay any text in any place on the camera view. Up to 16 text messages can be created on one camera view. The overlaid text will be saved in the recordings. Figure 21-6 Select th e font, font style and font size in a pop-up window.
  • Page 369 Administrator Mode Click Set Font to modify the font settings. Click Save to apply the settings, or click Loa d (Undo) to revert to the last saved setti Click Preview to see how the text will appear on the image. Click Close to end the preview.

  • Page 370: Tampering Alarm

    21.1.5 Tampering Alarm Note this function is not available for PTZ Camera and PT Camera. Tampering Alarm i s used to detect whether a camera is being physically tampered. An alarm can be generated when the camera is moved, covered up, or out of focus.
  • Page 371 Administrator Mode Figure 21-8 To configure the tampering alarm: Select the Enable option. If you want the camera to ignore any movement or scene change in certain areas, click the button to drag areas on the camera view. Select the desired detection sensitivity by moving the slider. The higher the value, the more sensitive the camera is to scene changes.
  • Page 372 To trigger an alarm when the scene turns dark, e.g. when the lens of camera is covered, ma ke sure the Alarm for Dark Images option is enabled. By default, this function is enabled Click Apply to save all the settings. Start monitoring to enable the function.

  • Page 373: Visual Automation

    Administrator Mode 21.1.6 Visual Automation Note this function is only supported by cameras with I/O function. This intuitive feature helps you automate any electronic device by triggering the connected output device. When you click on the image of the electronic device, you can simply change its current state, e.g. light ON. Figure 21-9 Select th Enable option.
  • Page 374 Assign the connected module and output device. In the Note field, type a note to help you manage the device. Cli ck OK to save the settings. To change the frame color of the set area, click the Set Color button. To emboss the set area, select Float Up;...

  • Page 375: I/O Settings

    Administrator Mode 21.2 I/O Settings Note the I/O settings are only available for Box Camera, Bullet Camera, Ultra Bullet Camera, PTZ Camera, PT Camera, Vanda l Proof IP Dome and Fixed IP Dome. After ins talling t he I/O device, you need to enable the I/O settings on the camera.

  • Page 376: Input Settings

    21.2.1 Input Settings To activate the sensor input, select Enable. Figure 21-11 Normal State: You can set the input state to trigger actions by selecting Open Circuit (N/O) or Grounded Circuit (N/C). Latch Mode: Enable this option to have a momentary output alarm. Trigger digital output relay: When this option is enabled, the output will be triggered once the input is activated.
  • Page 377 Administrator Mode PTZ Settings: Note this function is only availab le for PTZ Camera and PT Came Input On: Select a preset point to which the c amera turns when an input is triggered. Input Off: Select a preset point to which the c amera returns when the input triggering is off.

  • Page 378: Output Settings

    21.2.2 Output Settings Select Enable to start the output device. Choose t he output signal that mostly suits the device you are using: N/O (Ope n Circuit), N/C (Grounded Circuit), N/O Toggle, N/C Toggle, N/O Pulse or N/C P ulse. For Toggle output type, the output continues to be triggered unti l a new input trigger ends the output.

  • Page 379: Ptz Settings

    Administrator Mode 21.2.3 PTZ Settings Note this function is only available in PTZ Camera and PT Camera. You can change the i mage settings, configure sequences, and access settings including autopan speed, motor reset, digital zoom and system default loading. For details, see Accessing the VISCA OSD Configuration in 12.8.3 PTZ Camera Settings.

  • Page 380: Events And Alerts

    21.3 Events and Alerts For the events of motion detection or I /O trigger, the Administrator can set up two trigger actions: 1. Send a captured still image by E-mail or FTP. 2. Notify Center Monitoring Station, Center V2 or Vital Sign Monitor, by video or text alerts.

  • Page 381: E-Mail

    Administrator Mode 21.3.1 E-mail After a trigger event, the camera can send the e-mail to a remote user containing a captured still image. Figure 21-14 [Enable] Select to enable the e-mail function. Sever URL/IP Address: Type the URL address or IP address of the SMTP Server.
  • Page 382 Alerts Interval Time: Specify the interval be tween e-mail alerts. The interval is between 0 and 60 minutes. The option is useful for the frequent event occurrence, by which any even t triggers during the inte rval period will be ignored. [Need authentication to login] If the SMTP Serve r needs authentication, enable this option and type a valid username and pass...

  • Page 383: Ftp

    Administrator Mode 21.3.2 FTP You can also send the captured images to a remote FTP server as alerts. Figure 21-15...
  • Page 384 [Upload to an FTP Server] Enable: Select to enable the FTP function and then select Active Mode or Passive Mode, depending on the se tting of your FTP server. Server U RL/IP Address: Type the URL address or IP address of the FTP Server.
  • Page 385 Administrator Mode Interval: Use the drop-down list to specify how frequent the images are se nt to the FTP server. Enable Recycling: Select this option to re cycle the FTP storage at the specified Keep Day. Keep Days: Specify how frequent the images saved at the FTP server are recycled.

  • Page 386: Center V2

    21.3.3 Center V2 After a motion or an I/O triggered event, the central monitoring station Center V2 can be notified by live videos and text alerts. For the live monitoring through Center V2, you must already have a subscriber account on Center V2.
  • Page 387 Administrator Mode To enable the Center V2 connection: Activate Link: Enable the monitoring through Center V2. Host Name or IP Address: Type the host name or IP address of Center V2. Port Number: match the port to the P ort 2 value on Center V2 or keep the default value 5551.

  • Page 388: Vital Sign Monitor

    21.3.4 Vital Sign Monitor After a motion or an I/O triggered event, the central monitoring station Vital Sign Monitor can get notified by text alerts. For the monitoring through Vital Sign Monitor, you must already have a subscriber account on Vital Sign Monitor.
  • Page 389 Administrator Mode To enable the Vital Sign Monitor connection: Activate Link: Enable the monitoring through Vital Sign Monitor. Host Name or IP A ddress: Type the host name or IP address of Vital Sign Monitor. Port Number: Match the port to the Port 2 value on Vital Sign Monitor.

  • Page 390: Backup Center

    21.3.5 Backup Center For the supported version of different models, see Appendix D. Note that Backup Center is not supported for Target Series. The connection to the GV-Backup Center allows yo u to back up another copy of recordings and system log to the GV-Backup Center on an offsite location while the camera is saving these data to the memory card.
  • Page 391 Administrator Mode To enable connection to GV-Backup Center: Activate Link: Enable the connection to the GV-Backup Center. Host Name or IP Addres s: Type the host name or IP address of the GV-Backup Center. Port Number: Match the communication port on the GV-Backup Center or keep the default value 30000.
  • Page 392 Host Name or IP Address: Type the host na me or IP address of the failover GV-Backup Center. Port Number: Match the communication port on the failover GV- Backup Center or keep the default value 30000 User Nam e: Type a valid user name to log into the failover GV- Back up Center.

  • Page 393: Video Gateway / Recording Server

    Administrator Mode 21.3.6 Video Gateway / Recording Server For the supported version of different models, see A ppendix D. The GV-Video Gateway / GV-Recording Server is a video streaming server designed for large-scale video surveillance de ployments. The GV-Video Gateway / GV-Recording Server (with recordi ng capability) can receive up to 128 channels from various IP video devices, and distribute up to 300 channels to its clients.
  • Page 394 The supported GV-IPCAM H.264 can connect up to two GV-Video Gateway / GV-Recording Server. To send the video images to the GV- Video Gateway or GV-Recording Server, follow the steps below. Activate Link: Enable the c onnection to the GV-Video Gateway / GV- Recording Server.

  • Page 395: Viewlog Server

    Administrator Mode 21.3.7 ViewLog Server Note that ViewLog Server is not supported for Targ et Series. The ViewLog Server is designed for remote playback function. This server allows you to remotely access the recorded files saved at the GV-IPCAM H.264 and play back video with the ViewLog player.

  • Page 396: Rtsp/Onvif

    21.3.8 RTSP/ONVIF The RTSP enables video and audio streaming to your 3G-enabled mobile phone. The RTSP streaming is enabled by default. Figure 21-21 [RTSP] Activate Link: Enable the RTSP service. RTSP/TCP Port: Keep the default value 8554, or modify it if necessary.
  • Page 397 Administrator Mode Enable Audio: Note this function is not availab le for Target Bullet Camera, Target Mini Fixed Rugged Dome and Ultra Bullet Camera. Turns audio streaming on or off. For the support ed firmware versions, see Appendix D. Disable Authentication: By def ault, when accessing live view through RTSP command, the ID and password of the camera are...

  • Page 398: Speaker

    21.3.9 Speaker Note this function is only available for Advanced C ube Camera. The A dvanced Cube camera is equipped with an alarm. With the Speaker settings, your camera can sound the speaker (No. 1, Figure 18-1) when it is being tampered or when motions are detected. This function is disabled by default.

  • Page 399: Monitoring

    Administrator Mode 21.4 Monitoring Recording function is not supported in Target Series. Refer to 21.4.1 Monitoring Settings for Target Series for the c orresponding page. You can start mon itoring manually, by schedule or by input trigger. Note: See Note for Connecting to GV-System / GV-VMS at the beginning of the manual.

  • Page 400: Monitoring Settings For Target Series

    Input: Note this function is only supported by cameras with I/O function. Manually starts I/O monitoring. W hen the sensor input is triggered, its associated camera and out put will be activated for recording and alerting. For this setting, see 2 1.2.1 Input Setting.

  • Page 401: Recording Schedule

    Administrator Mode 21.5 Recording Schedule Note this function is not available for Target Seri The schedule is provided to activa te recording and I/O monitoring on a specific time each day. 21.5.1 Recording Schedule Settings You can set the schedule for recording. Figure 21-25 Span 1- Span 3: Set a different recording mode for each time frame during the day.

  • Page 402: I/O Monitoring Settings

    21.5.2 I/O Monitoring Settings Note this function is only supported by c ameras with I/O function. You can set the schedule for I/O monitoring to start. Figure 21-26 Span 1- Span 3: Set different time frame s during the day to enable I/O monitoring.

  • Page 403: Remote Viewlog

    Administrator Mode 21.6 Remote ViewLog Note this function is not available for Target Series With the Remote ViewLog player, you can play ba ck the files recorded at the GV-IPCAM H.264 over TCP/IP network. For the first-time user, you need to install the Remo te ViewLog program from the Software DVD.

  • Page 404: Network

    21.7 Network The Network section includes some basic but important network configurations that enabl e the camera to be connected to a TCP/IP network. 21.7.1 LAN Configuration According to your network environment, select among Static IP, DHCP and PPPoE. Figure 21-27...
  • Page 405 Administrator Mode [Optional Network Type] Note the Wireless Settings are only available in GV-B X1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series, GV-CAW120 / 220 and GV-MFD1501 Serie s / 2401 Series / 2501 Series / 3401 S eries / 5301 Series.

  • Page 406: Wireless Client Mode

    21.7.2 Wireless Client Mode Note this function is only supported in GV-BX1200 S eries / 1300 Series / 1500 Series / 2400 Series / 2500 Se ries / 3400 Series / 5300, GV- CAW120 / 220 and GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series and when GV-WiFi Adapter is installed.
  • Page 407 Administrator Mode Network name (SSID): The SSID (Service Set Identify) is a unique name that identifies a particular wireless netw ork. Type SSID of the Wireless LAN group or Access Point you are going to connect to. ch all the available Access Point Survey: Click this button to sear Access Points (Infrastructure mode) and wirel ess stations (AD-Hoc...

  • Page 408: Advanced Tcp/Ip

    21.7.3 Advanced TCP/IP This section provides the advanced TCP/IP settings, including DDNS Server, HTTP port, HTTPS, streaming port, UPnP, QoS and network connection check. Figure 21-29A...
  • Page 409 DHCP Server or ISP (in xDSL connection) has changed. Before enabling the following DDNS function, the Administrator should have applied for a Host Name from the DDNS service provider’s website. There are 3 providers listed in the camera: GeoVision GVDIP, GeoVision DDNS Server and DynDNS.org.
  • Page 410 Host Name: Type the host name used to link to the camera. For the users of GeoVision DDNS Server, it is unnece ssary to fill the field because the ho st name will be detected and brought up automatically.
  • Page 411 Administrator Mode Plug and Play Forum. It means that they are listed in the network devices table for the operating system (such as Window s XP) supported by this function. Enabling this function means you can c onnect to the camera ork devices table.

  • Page 412: Umts Settings

    21.7.4 UMTS Settings UMTS stands for Universal Mobile Telephone Sys tem. UMTS is a third- generation (3G) broadband, packet-bas ed transmission of text, digitized voice, video, and multimedia at data rates up to 2 megabits per second. UMTS offers a consistent set of services to mobile c omputer and phone users, no matter where they are located in the wo rld.
  • Page 413 Administrator Mode Figure 21-30 PIN number: Type the PIN number that is provided by your network operator. Access Point Name (APN): Type Access Point Name that is provided by your network operator. Username: Type a valid username to enable the UMTS service from your network operator.
  • Page 414 Password: Type a valid password to enable the UMTS service from your network operator. Maximum Transmission Unit: Type the Ma ximum Transfer Unit (MTU). The default value is 1500. Retain UMTS Connection: Select this opt ion to check the UMTS connection status and use the drop-down list to specify the desired time length for check frequency.

  • Page 415: Ip Filter Settings

    Administrator Mode 21.7.5 IP Filter Settings The Administrator can set IP filtering to restrict access to the camera. Figure 21-31 To enable the IP Filter function: Enable IP Filtering: Enable the IP Filter function. Filtered IP: Type one IP address or a range of IP addresses you want to restrict the access.

  • Page 416: Snmp Settings

    21.7.6 SNMP Settings The Simple Network Management Protocol (SNMP) allows you to monitor the status of the camera through SNMP network management software. Figure 21-32...
  • Page 417 Administrator Mode Select Enable SNMPv1 SNMPv2c to enable the function. To enable access to Read/Write community , type a community string. This will serve as a password to allow read and write access to the camera from the SNMP software. To enable Read only community, type a community string to allow read-only...

  • Page 418: Management

    21.8 Management The Management section includes the settings of data and time and user account. You can also view the firmware version and execute certain system operations. 21.8.1 Date & Time Settings The date and time settings are used for date and time stamps on the image. Figure 21-33...
  • Page 419 Administrator Mode [Date & Time on GV-IP Camera] Displays the current date and time on the camera. [Time Zone] Sets the time zone for local settings . Select Enable Daylight Saving Time to automatically adjust the camera fo r daylight saving time. Type the Start Time and End Time to enable the daylight saving function.

  • Page 420: Storage Settings

    21.8.2 Storage Settings Based on Linux file system, the GV-IPCAM H.264 supports memory cards for video and audio recordings. You need to format the storage device by using the following Storage Settings. After being formatted, the storage device will be ready to use by Linux OS of the camera. Figure 21-34...
  • Page 421 Administrator Mode Note: The Target Series does not support memory cards. You can store recordings to a connected NAS server instead. Refer to Network Neighborh ood Settings below. [Storage Settings] Enable recycling: If Enable recycling is sele cted, when the space of the storage device is lower than the specifie d space, the system will overwrite the oldest recorded files.
  • Page 422 Note: Make sure your camera’ s video se ttings adhere to the following: VBR is set to Go Maximal Bit Ra is set to the fo llowing: Camera Type Max. Bit Rate 1.3 M 6 Mbit or lower 2 MP / 3 MP / 4 MP / 5 MP 8 Mbit or lower For optimal performance and compatibility, it is highly recommended to use a GV-NAS System.
  • Page 423 Administrator Mode Type the username and password, and click S lect. Figure 21-36 Note: Depending on the models of GV-NAS System, up to 16 default user accounts (username: Cam01 – Cam16; password: 12345678) are available. The storage limitation and recycle is applied on a user basis. It is recommended to use one user account exclusively for recording of one GV-IP Camera to avoid uneven data recycle.
  • Page 424 Tip: Instead of searching for available NAS servers, you can also type the storage path directly. Type the Server URL/ IP Address in this for mat: \\NAS IP Address\Storage Folder. For example, \\19 2.168.0.1\IP_Camera This GV-IP Camera will be recorded to a default shared folder named “IP_Camera”...
  • Page 425 Administrator Mode [Partition Information] Note this function is not supported for Target Series. This section shows the partition details of the attac hed storage device. To add a storage device: Insert the storage device to the camera. Click the Form at button.
  • Page 426 Note: 1. If Enable Recycle is selected, the available space of the storage device must be higher than the space you s pecified at the Stop recordin g or recycle disk when free space of disk is smaller than x option. Otherwise no video will be recoded. 2.

  • Page 427: User Account

    Administrator Mode 21.8.3 User Account You can change the login name and password of A dministrator and Guest. The default Administrator login name and passwor d are admin; the default Guest login name and password are guest. To allow a Guest user log in without entering name and password, select Disable authentication for guest account.

  • Page 428: Log Information

    21.8.4 Log Information The log information contains dump data that is used by service personnel for analyzing problems. The logs available may vary depending on the camera model. Figure 21-41-1...
  • Page 429 Administrator Mode Figure 21-41-2...

  • Page 430: System Log

    21.8.5 System Log Note this function is only available for firmware V2.12 or earlier and is not available for Target Series. For the supported ver sions, see Appendix F. The System Log records the events in the four ty pes of logs: System Event Monitoring Event I/O Event Login/Lo gout Event.
  • Page 431 Administrator Mode Click Query. The filtering results may look like the figure below. Figure 21-43...

  • Page 432: Tools

    21.8.6 Tools You can execute certain system operations and view the firmware version. Figure 21-44...
  • Page 433 Administrator Mode [Host Settings] Enter a descriptive name for the camera. [Auto Reboot Setup] Select Enable to ac tivate automatic reboot and specify the time for reboot in the sub fields. Day Interval: Type the day interval between each reboot. Reboot Time: Use the drop-down lists to speci fy the time for automatic reboot.

  • Page 434: Language

    21.8.7 Language Note this function is not available in GV-PTZ010D. You can select the language for the Web interface. Figure 21-45 Use the Language drop-down list to select a language for the Web interface. By default, the language on the Web interface will be the same with the one used for the operating system.

  • Page 435: Chapter 22 Recording And Playback

    Chapter 22 Recording and Playback Note that Recording and Playback function is not av ailable for Target Series. The GV-IPCAM H.264 can record video and a udio directly to the memory card. You can play back the recorded files on the GV-System / GV-VMS or over the TCP/IP ne twork.

  • Page 436: Playback

    22.2 Playback These methods are available to play back the video files recorded at the GV-IPCAM H.264: • Playback from the memory card by connecti ng it directly to the GV-System / GV-VMS through a card reader • Playback by using the Remote ViewLog function over the TCP/IP network •...
  • Page 437 Recording and Playback Install the Ext2Fsd from the Software DVD. Note: If you are using Windows 8 or Windo ws Server 2012, change its compat ibility before installing the Ext2Fsd program: Right-click the Ext2Fsd program and select Properties. This dialog box appears. Figure 22-1 Select the Compatibility tab.
  • Page 438 On Your desktop, click Start, select Programs, locate the Ext2Fsd folder and select Ext2 Volume Manager. All the connected drives are shown. Figure 22-2...
  • Page 439 Recording and Playback For the first-installation, execute the Ext2Fsd Service. A. From the Ext2 Volume Manager window, select Tools and select Service Management. This dialog box appears. Figure 22-3 B. Click Apply.
  • Page 440 Mount the storage drive to your computer. A. From the Ext2Fsd Volume Manager window, right-click the storage drive and select Ext2 Management. This dialog box appears. Figure 22-4 B. Under the Mount point & driver letter section, select Automatically mount via Ext2Mgr, specify a disk drive using the drop-down list and click Apply.
  • Page 441 Recording and Playback C. On the Ext2 Volume Manager window, the storage drive is successfully mounted to your computer when it is indicated with the disk drive you specified. Figure 22-5 Access the recording files from the specified drive of your computer.

  • Page 442: Playback Over Network

    22.2.2 Playback over Network With the Remote ViewLog function, you can play back the files recorded at the GV-IPCAM H.264 over TCP/IP network. The camera needs to allow the remote access w ith ViewLog Server activated. See 21.3.7 ViewLog Server. For the first-time user, run the Remote ViewLog program from the Software DVD.

  • Page 443: Access To The Recorded Files Through Ftp Server

    [Act as FTP Server], 21.3.2 FTP. Note: To play back videos, ensure you have installed Geovision codec on the computer. The codec is available on the Software DVD. If you have installed the Remote Playback player on the computer, it is not...

  • Page 444: Playback Of Daylight Saving Time Events

    22.2.4 Playback of Daylight Saving Time Events On GV-System, you can retrieve the events recorded during the Daylight Saving Time (DST) period from the GV-IPCAM H.264 f or playback. You can also connect the memory card to GV-System fo r playback. The following instruct ions describe how to retrieve the recorded files from the GV-IPCAM H.264 over network.
  • Page 445 Recording and Playback On the Video Event list, select desired events, and click the Play button to start. Note: The playback function is only compatible with the GV-System of version 8.3 and later. The AVI file recorded during the DST period is named with the prefix “GvDST”, e.g.

  • Page 446: Chapter 23 Advanced Applications

    This chapter introduces more advanced applications. 23.1 Upgrading System Firmware GeoVision periodically releases updated firmware on the website. Simply download the new firmware into the GV-IPCAM H.264 using the Web interface or IP Device Utility included in the Software DVD.
  • Page 447 In this case, please contact your sales representative and send your device back to GeoVision for repair. Do not turn the power off within 10 minutes after the firmware is updated.

  • Page 448: Using The Web Configuration Interface

    23.1.1 Using the Web Configuration Interface In the Live View window, click the Show System Menu button (No. 8, Figure 20-3) and select Remote Config. This dialog box appears. Figure 23-2 Click the Browse button to locate the firmware file (.img) saved at your local computer.

  • Page 449: Using The Ip Device Utility

    GV-IPCAM H.264. Note the computer used to upgrade firmware must be under the same network of the camera. Insert the Software DVD, select GeoVision IP Device Utility, and follow the onscreen instructions to install the program. Double-click the IP Device Utility icon created on your desktop. This dialog box appears.
  • Page 450 Double-click one camera in the list. This dialog box appears. Figure 23-4...
  • Page 451 Advanced Applications 5. Click the Firmware Upgrade tab. This dialog box appears. Figure 23-5 Click the Browse button to locate the firmware file (.img) saved at your local computer. If you like to upgrade all the cameras in the list, select Upgrade all devices.

  • Page 452: Backing Up And Restoring Settings

    23.2 Backing Up and Restoring Settings With the IP Device Utility included in the Software DVD, you can back up the configurations in the GV-IPCAM H.264, and restore the backup data to the current camera or import it to another camera. To back up the settings: Run IP Device Utility and locate the desired camera.
  • Page 453 Advanced Applications Type Password, and click the Export settings button to save the backup file. To restore the settings: In Figure 23-4, click the Import Settings tab. This dialog box appears. Figure 23-7 Click the Browse button to locate the backup file (.dat). Select Upgrade all devices to import the settings into devices of the same type in the same LAN.

  • Page 454: Restoring To Factory Default Settings

    23.3 Restoring to Factory Default Settings Please refer to the corresponding section of your camera type and follow the steps to restore factory default settings. Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera.
  • Page 455 Advanced Applications Ultra Box Camera and Target Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Figure 23-10 Release the default button when the status LED blinks.
  • Page 456 GV-BX2510-E / 5310-E Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button. Status LED Default button Figure 23-12 Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.
  • Page 457 Advanced Applications Mini Fixed Dome Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button. Default button Status LED Figure 23-12 (GV-MFD120 / 130 / 320) Default button Figure 23-13 (GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series) Release the default button when the status LED blinks.
  • Page 458 Mini Fixed Rugged Dome Keep the PoE cable connected to the camera. Press and hold the default button. Status LED Default button Figure 23-14 Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.
  • Page 459 Advanced Applications Target Mini Fixed Dome and Target Mini Fixed Rugged Dome Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button for about 8 seconds. Default button Figure 23-15 Release the default button when the status LED blinks. Status LED Status LED Figure 23-15...
  • Page 460 Bullet Camera Keep the power and network cables connected to the camera. Loosen the camera’s cover and remove the Silica Gel Bag. Press and hold the default button for 8 seconds. Default Button Figure 23-16 Release the default button. When the process of loading default settings is completed, the camera reboots automatically.
  • Page 461 Advanced Applications Release the defau lt button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. arget Bullet Camera Keep the power an d network cables (or PoE) connected to the camera.
  • Page 462 PTZ Camera There are two types of default settings: camera default settings and system default settings. Camera default settings include all settings on Iris, White Balance, Image Reverse and Other in the VISCA OSD Configuration dialog box (Figure 12-19). System default settings refer to all the settings except the camera settings.
  • Page 463 Advanced Applications Hold the default button until the two network LEDs fade. This will take about 25 seconds. Network LEDs Figure 23-20 When default loading is completed, the camera will pan and tilt to its full range and return to the home point. PT Camera Keep the power and network cables connected to the camera.
  • Page 464 Vandal Proof IP Dome Keep the power and network cables (or PoE) connected to the camera. Use a pin to press and hold the default button on the inner housing. Default button Status LED Status LED Default Figure 23-22 Release the default button when the status LED blinks. This shall take about 8 seconds.
  • Page 465 Advanced Applications Fixed IP Dome Keep the power and network cables (or PoE) connected to the camera. Use a pin to press and hold the default button on the panel. Status LED Default button Figure 23-23 Release the default button when the status LED blinks. This shall take about 8 seconds.
  • Page 466 Cube Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the panel. Default button Status LED Figure 23-24 elease the def ault button when the status LED blinks. This shall take about 8 seconds.
  • Page 467 Advanced Applications elease the de fault button when the status LED blinks. This shall take about 8 seconds. When the status LED turns green, the process of loading default settings is completed and t he camera is ready for use.

  • Page 468: Changing Password

    23.4 Changing Password You change the login password of your GV-IP Camera using GV-IP Device Utility. Make sure you have installed and executed GV-IP Device Utility. For details, see steps 1 to 3 in 24.1.2 Using the GV-IP Device Utility. This page appears.
  • Page 469 Advanced Applications Double-click one camera in the list. This window appears. Figure 23-27 Type Password, click , select Other Settings and then select Change Password. This dialog box appears. Figure 23-28...
  • Page 470 Type the new password in both fields. To change devices of the same type to the same password, select Sync all devices. Click OK to apply the change.

  • Page 471: Verifying Watermark

    Advanced Applications 23.5 Verifying Watermark The watermark is an encrypted and digital signature embedded in the video stream during the compression stage, protecting the video from the moment of creation. Watermarking ensures that an image is not edited or damaged after it is recorded. To enable the watermark function, see [Watermark Setting], 21.1.1 Video Settings.

  • Page 472: Running Watermark Proof

    23.5.2 Running Watermark Proof Install Watermark Proof from the Software DVD. After installation, a WMProof icon is created on your desktop. Double-click the created icon. The Water Mark Proof window appears. Click File from the menu bar, select Open and locate the recording (.avi).

  • Page 473: The Watermark Proof Window

    Advanced Applications 23.5.3 The Watermark Proof Window Figure 23-29 The controls in the window: No. Name Description Open File Opens the recording. First Frame Goes to the first frame of the file. Play Plays the file. Previous Frame Goes to the previous frame of the file. Next Frame Goes to the next frame of the file.

  • Page 474: Downloading Videos From The Micro Sd Card

    23.6 Downloading Videos from the Micro SD Card When connections of GV-IP Cameras to the GV-System are lost, recordings are automatically saved to the memory cards inserted in the GV-IP Cameras. To automatically synchronize and download recordings from the micro SD cards to a local folder, install and execute the GV-SDCardSync Utility program.

  • Page 475: Installing The Gv-Sdcardsync Utility

    Advanced Applications 23.6.1 Installing the GV-SDCardSync Utility Download the GV-SD Card Sync Utility program from http://ftp.geovision.tw/FTP/neo/Utility/GvSDCardSync_Setup.zip Note: The GV-SD Card Sync Utility must be installed on the computer installed with GV-System V8.5.4 or later. Execute the GV-SDCard Sync Utility program. The main window and the Setting window appear.
  • Page 476 To configure synchronization, network and startup settings, see the steps below. Figure 23-31 [Synchronization] Synchronize automatically at an interval: Automatically synchronize videos from micro SD cards to a local folder at the specified interval. Synchronize automatically at: Automatically synchronize videos from micro SD cards to a local folder at the specified time.
  • Page 477 Advanced Applications [Network] Max. download speed of each device (Kb/sec): To make sure the bandwidth is not completely taken up while downloading files from the memory card, specify a maximum download speed. If you do not want to set a bandwidth limit, type 0. [General] Start up automatically at Windows login: GV-SDSync Utility launches automatically when Windows starts up.
  • Page 478 [Recycle] Recycle when the storage space is less than (GB): Specify a minimum free space of your local storage for file recycling. Keep the downloaded files for (Days): Specify the number of days to keep the download files at the local hard drive. [Storage Location] To configure the storage path, click the button next to the location field and specify a storage location.

  • Page 479: The Gv-Sdcardsync Utility Window

    Advanced Applications 23.6.2 The GV-SDCardSync Utility Window After you have installed the GV-SDCardSync Utility, point to Start, select Programs, select GV-SDCardSync and select to launch the program. This window appears. Figure 23-33 No. Name Description Plays downloaded recordings of the selected GV-IP Cameras using the ViewLog player.
  • Page 480 No. Name Description Displays up to 100 event entries of the GV- Log Tab SDCardSync Utility. Once the entries are full, recycling will start from the oldest file. Shows the storage space of the designated hard Storage Space drive. Note: 1.

  • Page 481: Chapter 24 Dvr Configurations

    Chapter 24 DVR Configurations The GV-System / GV-VMS provides the complete video management, such as video viewing, recording, playback, alert settings and almost every feature of the system. Following is the integration specifications: • GV-System version 8.5.5.0 or later or GV-VMS version 14.10 is required.
  • Page 482 • The compatible version of GV-System for each camera model: Compatible version Camera Models of GV-System GV-BX120D GV-BX220D Series V8.4 or later GV-BX320D Series GV-BX130D Series GV-BX140DW V8.5 or later GV-BX520D GV-BX1200-0F ~ 2F GV-BX1200-3V GV-BX1300-0F ~ 2F GV-BX1300-3V GV-BX2400-0F ~ 2F V8.5.5 or later...
  • Page 483 DVR Configurations Compatible version Camera Models of GV-System GV-BX120D-E GV-BX220D-E V8.4 or later GV-BX320D-E GV-BX520D-E GV-BX1500-E V8.5.8 or later IR Arctic Camera GV-BX2400-E GV-BX3400-E V8.5.7 or later GV-BX5300-E GV-BX2510-E V8.5.9 (with patch files) GV-BX5310-E GV-MFD120 GV-MFD130 V8.5 or later GV-MFD320 GV-MFD1501 Series V8.5.7 or later...
  • Page 484 Compatible version of Camera Models GV-System GV-EFD1100 Series Target Mini V8.5.9 or later Fixed Dome GV-EFD2100 Series Target Mini GV-EDR1100 Series Fixed Rugged V8.5.9 or later GV-EDR2100 Series Dome GV-BL120D V8.4 (with patch files) GV-BL220D or later GV-BL320D GV-BL130D V8.5 or later GV-BL2400 GV-BL3400 GV-BL1210...
  • Page 485 DVR Configurations Compatible version of Camera Models GV-System GV-UBL1211 GV-UBL2411 GV-UBL3411 V8.5.6 or later GV-UBL1301 Series Ultra Bullet GV-UBL2401 Series Camera GV-UBL3401 Series GV-UBL1511 V8.5.8 or later GV-UBL2511 V8.5.9 or later GV-EBL1100 Series Target Bullet V8.5.9 or later Camera GV-EBL2100 Series PTZ Camera GV-PTZ010D V8.4 or later...
  • Page 486 Compatible version Camera Models of GV-System GV-FD220D V8.4.3 (with patch files) or later GV-FD320D GV-FD1200 GV-FD2400 GV-FD3400 GV-FD5300 V8.5.7 or later GV-FD1210 Fixed IP Dome GV-FD2410 GV-FD3410 GV-FD1500 V8.5.8 or later GV-FD1510 GV-FD2500 V8.5.9 or later GV-FD2510 GV-CB120 V8.4.3 (with patch Cube Camera GV-CB220 files) or later...
  • Page 487 DVR Configurations • The maximum number of streams which the GV-IPCAM H.264 allows varies according to its resolution: Camera Models Max. No. of Streams GV-PTZ010D 1.3 M models except GV-PTZ010D 2 M models 3 M models 5 M models • When a GV-IPCAM H.264 is connected to IE browser or any other applications, it takes up 1 stream;...

  • Page 488: Setting Up An Ip Camera On Gv-System

    24.1 Setting up an IP Camera on GV-System To set up the GV-IPCAM H.264 on the GV-System, follow these steps: On the main screen, click the Configure button, select System Configure, select Camera Install and click IP Camera Install. This dialog box appears.
  • Page 489 DVR Configurations Click Add Camera. The dialog box appears. Figure 24-3 Type the IP address, username and password of the IP camera. Select the camera brand and device from the drop-down lists. This dialog box appears. Figure 24-4 The GV-System will automatically query for the IP camera, and the status will be indicated as “Standby”.
  • Page 490 The options in the setup dialog box may vary depending on the camera model. Dual Stream: Click this button to set the codec type to H.264 in the main stream and to MJPEG in the sub stream, and each stream with a different resolution. For details on supported versions and resolutions in different cameras, see Appendix G.

  • Page 491: Customizing Ip Camera Settings On Gv-System

    DVR Configurations 24.1.1 Customizing IP Camera Settings on GV-System After the IP camera is connected and assigned with a display position, you can configure the camera’s settings such as frame rate, codec type and resolution. Right-click the desired camera to see the following list of options: Figure 24-6 Change Resolution: Changes the display ratio, live view resolution and record resolution...
  • Page 492 Recording Codec Format: Specifies whether to record in standard or GeoVision type of JPEG or H.264 codec. GIS Setting: Records the video with the GPS data. To record the GPS data, remember to also enable the GIS function of the GV- System (Configure button <...

  • Page 493: Setting Up Ip Cameras On Gv-Vms

    DVR Configurations 24.2 Setting Up IP Cameras on GV-VMS Follow the steps below to manually connect your GV-IP Camera to GV- VMS. Note: The following instructions are based on V14.10 software and user interfaces. 1. To access the IP Device Setup page, click Home , select Toolbar , click Configure and select Camera Install.
  • Page 494 3. Type the IP address, username and password of the GV-IP Camera. Modify the default HTTP port 80 if necessary. 4. Select GeoVision and model name from the Brand drop-down list and select the GV-IP Camera from the Device drop-down lists. This dialog box appears.
  • Page 495 DVR Configurations 5. In the dialog box , configure the options which may vary depending on camera brands. Dual Stream s: It is set to dual streams by default. Select this option to apply the dual-streaming settings (lower resolution for live view and higher resolution for recording) if the camera supports dual streams.

  • Page 496: Remote Monitoring With Multi View

    24.3 Remote Monitoring with Multi View You can use the Multi View to monitor and manage the GV-IPCAM H.264. Note: Multi View is not supported by GV-VMS. 24.3.1 Connecting to the IP Camera On the Multi View window, click the Edit Host button. The Edit Host window appears.
  • Page 497 DVR Configurations For details on the Multi View functions, see “Multi View Viewer”, Remote Viewing, DVR User’s Manual on the Surveillance System Software DVD.

  • Page 498: Remote Monitoring With E-Map

    24.4 Remote Monitoring with E-Map You can use the Remote E-Map to monitor and manage the GV-IPCAM H.264. 24.4.1 Creating an E-Map for the IP Camera With the E-Map Editor, you can create an E-Map for the GV-IPCAM H.264. The E-Map Editor is available in the two applications: Main System and E- Map Server.
  • Page 499 DVR Configurations Click OK to save the settings. Expand the created host folder. Drag and drop the icons of camera and I/O devices onto the imported E-Map. Close the E-Map Editor. Click Yes when you are promoted to save the file. For details on creating an E-Map file on the E-Map Server, see “E-Map Server”, E-Map Application, DVR User’s Manual on the Surveillance System Software DVD.

  • Page 500: Connecting To The Ip Camera

    24.4.2 Connecting to the IP Camera Depending on where you save the created E-Map file (DVR, E-Map Server or Control Center), the steps to open the Remote E-Map window for monitoring may vary slightly. The following is the connection example when you store the E-Map file on the DVR.

  • Page 501: Chapter 25 Cms Configurations

    CMS Configurations Chapter 25 CMS Configurations This section introduces the related settings to enable connecting to the GV- IPCAM H.264 in the central monitoring stations Center V2, Vital Sign Monitor and Dispatch Server. 25.1 Center V2 The Center V2 can monitor and manage the camera and I/O devices connected to the GV-IPCAM H.264.
  • Page 502 • To set the appropriate port for IP camera connection, click the Preference Settings button, select System Configure, click the Network tab, and select Accept connections from GV-Compact DVR, Video Server & IP Cam. Keep default port 5551, or modify it to match the Center V2 port on the IP camera.
  • Page 503 CMS Configurations Manual close channel: Closes the triggered camera view manually. Close the camera view when motion stopped: Closes the triggered camera view automatically when motion stops. Post Motion: Specify the duration of the camera view remaining on the monitoring window after a motion stops. Camera send by I/O trigger will monitor: Specify the duration of the camera view remaining on the monitoring window when an I/O device is triggered.

  • Page 504: Vital Sign Monitor

    25.2 Vital Sign Monitor The Vital Sign Monitor is designed to monitor and manage the camera and I/O devices connected to the GV-IPCAM H.264 under low bandwidth network. TCP/ IP IP Camera Text Data IP Camera Figure 25-4 • To set the appropriate port connecting to the IP camera, click Configure on the window menu, and select System Configure to display this dialog box.

  • Page 505: Dispatch Server

    CMS Configurations For further information on how to mange the video received from the IP camera, see GV-CMS Series User’s Manual. 25.3 Dispatch Server The Dispatch Server minimizes overloading of Center V2 Servers by re- distributing GV-IPCAM H.264 subscribers to the least busy Center V2 Server.
  • Page 506 • To set the appropriate port connecting to the IP camera, click the Server Setting button on the toolbar, and select Allow GV IP devices to login as subscriber from port. Keep the default port as 5551, or modify it to match the Center V2 port on the IP camera. Figure 25-7 For further information on how to mange the video received from the IP camera, see GV-CMS Series User’s Manual.

  • Page 507: Chapter 26 Smart Device Connection

    Touch are supported. For details on system requirements, installation and setup, visit our website: http://www.geovision.com.tw/english/5_4_iview.asp Note: To receive the live video from the camera, enter the TCP/IP port on your mobile phone. To play video back, enable ViewLog Server on...

  • Page 508: Appendix

    Appendix A. Settings for Internet Explorer 8 If you use Internet Explorer 8, it is required to complete the following setting. Set the Security to Medium-high (default). Enable Allow previously unused ActiveX controls to run without prompt. Disable Only allow approved domains to use ActiveX without prompt.

  • Page 509: Supported Lenses For Box Camera

    Appendix B. Supported Lenses for Box Camera Provider Model No. RV0409D.IR Fujian Forecam Optics RV0515D.IR RV0820D.IR EVD03618F-IR EVD04218F-IR EVD06018F-IR EVETAR EVD08018F-IR EVD12018F-IR EVD16018F-IR Pentax TS3VP213ED-M...

  • Page 510: Resolution And Frame Rate

    Ratio Resolution Rate GV-BL120D 1280 x 960 GV-BL130D Main GV-BL1210 16:9 1280 x 720 GV-BL1500 1280 x 1024 GV-BL1510 GV-BX120D GV-BX130D Series GV-BX1200 Series 640 x 480 GV-BX1300 Series 320 x 240 GV-BX1500 Series GV-BX120D-E GV-BX1500-E 30 fps GV-CA120 GV-CAW120...
  • Page 511 Appendix Max. Frame GV-IP Camera Stream Ratio Resolution Rate 1280 x 960 GV-UBL1301 Series GV-UBL1511 16:9 1280 x 720 Main GV-UBX1301 Series 1280 x 1024 GV-VD120D GV-VD121D 640 x 480 30 fps GV-VD122D 320 x 240 GV-VD123D 640 x 360 16:9 GV-VD1500 448 x 252...
  • Page 512 Max. Frame GV-IP Camera Stream Ratio Resolution Rate GV-BL220D 1600 x 1200 GV-BL2400 1280 x 960 GV-BL2410 Main 1920 x 1080 16:9 GV-BL2500 1280 x 720 GV-BL2510 1280 x 1024 GV-BL2510-E 640 x 480 GV-BX220D Series 320 x 240 GV-BX2400 Series 640 x 360 GV-BX2500 Series 16:9...
  • Page 513 Appendix Max. Frame GV-IP Camera Stream Ratio Resolution Rate 1280 x 960 640 x 480 320 x 240 1920 x 1080 1280 x 720 Main 16:9 640 x 360 448 x 252 GV-EBL2100 Series 1280 x 1024 GV-EFD2100 Series 30 fps 640 x 512 GV-EDR2100 Series 320 x 256...
  • Page 514 Max. Frame GV-IP Camera Stream Ratio Resolution Rate GV-BL320D 2048 x 1536 20 fps GV-BL3400 1600 x 1200 GV-BL3410 Main 1280 x 960 GV-BX320D Series 1920 x 1080 GV-BX3400 Series 16:9 1280 x 720 GV-BX320D-E 1280 x 1024 GV-BX3400-E GV-FD320D 640 x 480 GV-FD3400 320 x 240...
  • Page 515 Appendix Max. Frame GV-IP Camera Stream Ratio Resolution Rate 2560 x 1920 10 fps GV-BL5310 2048 x 1536 20 fps GV-BL5310-E 1600 x 1200 GV-BX520D Main 1280 x 960 GV-BX5300 Series 1920 x 1080 16:9 GV-BX520D-E 1280 x 720 GV-BX5300-E 1280 x 1024 GV-FD5300 30 fps...

  • Page 516: Support Lists

    D. Support Lists • Support List for GV-Backup Center, GV-Video Gateway and GV- Recording Server GV-IP Camera Model Supported Version GV-BX120D V1.03 or later GV-BX220D Series GV-BX320D Series GV-BX130D Series V1.04 or later GV-BX520D V1.05 or later Box Camera GV-BX1200 Series GV-BX1300 Series V1.15 or later...
  • Page 517 Appendix GV-IP Camera Model Supported Version GV-BL120D GV-BL220D V1.03 or later Bullet Camera GV-BL320D GV-BL130D V1.04 or later PTZ Camera GV-PTZ010D V1.08 or later GV-VD120D Series Vandal Proof IP V1.03 or later GV-VD220D Series Dome GV-VD320D Series GV-FD220D Fixed IP Dome V1.03 or later GV-FD320D GV-CB120...
  • Page 518 • Support List for Transmit Audio GV-IP Camera Model Supported Version GV-BX120D GV-BX220D Series V1.05 or later GV-BX320D Series GV-BX130D Series V1.04 or later GV-BX520D V1.05 or later Box Camera GV-BX1200 Series GV-BX1300 Series GV-BX2400 Series V1.15 or later GV-BX3400 Series...
  • Page 519 Appendix GV-IP Camera Model Supported Version GV-BL120D GV-BL220D V1.05 or later Bullet Camera GV-BL320D GV-BL130D V1.04 or later PTZ Camera GV-PTZ010D V1.08 or later GV-VD120D Series Vandal Proof IP Dome V1.05 or later GV-VD220D Series GV-VD320D Series GV-FD220D Fixed IP Dome V1.05 or later GV-FD320D GV-CB120...
  • Page 520 • Support List for System Log GV-IP Camera Model Supported Version GV-BX120D GV-BX220D Series GV-BX320D Series V1.11 or later GV-BX130D Series GV-BX520D Box Camera GV-BX1200 Series GV-BX1300 Series GV-BX2400 Series V1.15 or later GV-BX3400 Series GV-BX5300 Series GV-BX120D-E GV-BX220D-E V1.11 or later...
  • Page 521 Appendix GV-IP Camera Model Supported Version GV-BL120D GV-BL130D Bullet Camera V1.11 or later GV-BL220D GV-BL320D PTZ Camera GV-PTZ010D V1.08 or later GV-VD120D Series Vandal Proof IP Dome V1.11 or later GV-VD220D Series GV-VD320D Series GV-FD220D Fixed IP Dome V1.11 or later GV-FD320D GV-CB120 Cube Camera...

  • Page 522: Rtsp Protocol Command

    E. RTSP Protocol Command The GV-IPCAM H.264 can support RTSP protocol for both audio and video streaming. If you use the QuickTime player, enter: rtsp://<IP of the GV-IPCAM H.264:8554/<CH No.>.sdp For example, rtsp://192.168.3.111:8554/CH001.sdp If you use the VLC, and if authentication is required, enter: rtsp://username:password@<IP of the GV-IPCAM H.264:8554/<CH No.>.sdp For example, rtsp://admin:admin@192.168.3.111:8554/CH001.sdp...

  • Page 523: The Cgi Command

    Please note the supported version of the CGI command in different models: GV-IP Camera Supported Version GV-PTZ010D V1.07 or later GV-BX120D V1.00 or later GV-BX220D-2 / 223D-3 GV-BX320D-0 / 320D-1 GV-BL120D / 220D / 320D GV-VD120D / 121D / 122D / 123D V1.02 or later...
  • Page 524 GV-IP Camera Supported Version GV-BX1200 Series GV-BX1300 Series GV-BX2400 Series V1.15 or later GV-BX3400 Series GV-BX5300 Series GV-CA120 / 220 GV-CAW120 / 220 You can use the CGI command to obtain a snapshot of the live view or access the User Account Web interface. For a GV-IPCAM H.264 with the following details: IP address: 192.168.2.11 Username: admin...

  • Page 525: Dual Stream Support List

    GV-System. Resolution Supported GV-IP Camera Firmware Main Stream Sub Stream Version (H.264) (MJPEG) GV-BX120D V1.00 or later GV-BX1200 Series V1.15 or later GV-MFD120 V1.05 or later GV-BX120D-E V1.07 or later GV-BL120D 1280 x 1024...
  • Page 526 Resolution Supported Firmware GV-IP Camera Main Stream Sub Stream Version (H.264) (MJPEG) GV-BL130D V1.04 or later GV-BX130D Series 1280 x 1024 320 x 256 GV-MFD130 GV-BX1300 Series V1.15 or later GV-BX140DW V1.10 or later 1280 x 720 640 x 360 GV-BX220D Series V1.00 or later GV-BX2400 Series...
  • Page 527 Appendix Resolution Supported Firmware GV-IP Camera Main Stream Sub Stream Version (H.264) (MJPEG) GV-BX320D Series V1.00 or later GV-BX3400 Series V1.15 or later GV-MFD320 V1.05 or later GV-BX320D-E V1.07 or later GV-MDR320 2048 x 1536 320 x 240 GV-BL320D GV-VD320D V1.02 or later GV-VD321D GV-VD322D...

  • Page 528: Power Supply Support List

    The supported power type is indicated with a tick ( ) and the unsupported power type with a cross ( ). GV-IP Camera DC Power AC Power Box Camera Ultra Box Camera Target Box Camera GV-BX120D-E GV-BX220D-E GV-BX320D-E GV-BX520D-E GV-BX1500-E IR Arctic Box Camera GV-BX2400-E...
  • Page 529 Appendix GV-IP Camera DC Power AC Power All except GV-BL2510-E GV-BL5310-E Bullet Camera GV-BL2510-E GV-BL5310-E Ultra Bullet Camera Target Bullet Camera PTZ Camera PT Camera Vandal Proof IP Dome Fixed IP Dome Cube Camera GV-CA120/220 Advanced Cube Camera GV-CAW120/220...

  • Page 530: Supported Firmware For Flash Memory

    I. Supported Firmware for Flash Memory The 128 MB flash memory is supported in V1.09 or later in all models of GV-IPCam H.264 Series except GV-PTZ010D. To look up if the camera contains a 128 MB type flash memory, access the web interface or the GV IP Device Utility: Web Interface Click Management and click Tools.

  • Page 531: Supported Umts Protocol (3G Modem)

    Appendix J. Supported UMTS Protocol (3G Modem) Brand Model Huawei E220, E392 E169, E1692, E156, EC189, E1752, E1756, E1756C, E169C Novatel MC998D USB760, USB727, MC950D ONDA MSA523HS MF100...

  • Page 532: Specifications: Box Camera (Part 1)

    Specifications: Box Camera (Part 1) This section details the specifications on GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D. Camera 1/3" progressive scan low lux GV-BX120D CMOS GV-BX140DW 1/3" progressive scan CMOS Image GV-BX130D Series...
  • Page 533 Illumination Color 0.15 lux GV-BX220D Series GV-BX320D Series 0.10 Lux GV-BX520D IR On 0 Lux GV-BX140DW Automatic GV-BX120D Shutter GV-BX130D Series Automatic, Manual (1/5 ~ 1/8000 Speed GV-BX220D Series sec) GV-BX320D Series GV-BX520D Automatic, Manual (2800K ~ White Balance 8500K)
  • Page 534 GV-BX140DW Up to 100 dB GV-BX120D Dynamic GV-BX130D Series Range GV-BX220D Series Up to 72 dB GV-BX320D Series GV-BX520D Fixed Focal Lens (GV-BX130D-1 only) Megapixel Day/Night Yes (with removable IR-cut filter) Focal Length 4.0 mm Maximum Aperture F/1.5 Mount Image Format 1/3”...
  • Page 535 Specifications: Box Camera (Part 1) GV-BX120D GV-BX130D-0 2.8 ~ 12 mm GV-BX140DW GV-BX220D-3 Focal GV-BX320D-0 3.1 ~ 8 mm Length GV-BX220D-2 2.8 ~ 6 mm GV-BX320D-1 GV-BX520D 4.5 ~ 10 mm GV-BX120D GV-BX130D-0 F/1.4 GV-BX140DW GV-BX220D-3 Maximum Aperture GV-BX320D-0 F/1.2 GV-BX220D-2 F/1.3...
  • Page 536 Focus Manual (w/lock) Zoom Manual (w/lock) GV-BX120D GV-BX130D-0 Operation DC drive GV-BX220D Series Iris GV-BX320D Series GV-BX140DW Fixed GV-BX520D Manual (w/lock) Max. Torque 0.049 N.m (Focus/ Zoom Screws) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG...

  • Page 537: Video Resolution

    1280 x 960, 640 x 480, 320 x 240 Main 16:9 1280 x 720, 640 x 360, 448 x 252 Stream 1280 x 1024, 640 x 512, 320 x 256 GV-BX120D GV-BX130D Series 640 x 480, 320 x 240 Stream 16:9 640 x 360, 448 x 252...
  • Page 538 Stream 16:9 640 x 360, 448 x 252 640 x 512, 320 x 256 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 16:9 Stream 640 x 360, 448 x 252 GV-BX320D Series 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240...
  • Page 539 Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14’’) GV-BX130D-1 GV-BX140DW Not functional GV-BX520D Connectors Auto Iris GV-BX120D GV-BX130D-0 GV-BX220D Series GV-BX320D Series Micro SD card slot Local Storage (SD/SDHC, version 2.0 only, Class 10) TV-Out BNC connector (640 x 480 resolution) Digital I/O 3-pin terminal block, pitch 2.5 mm / 0.1”...

  • Page 540: Power Over Ethernet

    General Environment Temperature 0°C ~ 50°C (32°F ~ 122°F) Humidity 10% to 90% (no condensation) Power Source 12V DC, PoE Max. Power Consumption 7 W 75.5 x75 x 54 mm (2.97’’ x 2.95’’ x 2.13’’) Dimensions (L X W X H) (without lens) Weight 321 g (0.71 lb)
  • Page 541 Specifications: Box Camera (Part 1) Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Language Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish...

  • Page 542: Specifications: Box Camera (Part 2)

    Specifications: Box Camera (Part 2) This section details the specifications on GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 3400 Series / 5300 Series. Camera 1/3" progressive scan low lux GV-BX1200 Series CMOS 1/3’’...
  • Page 543 Specifications: Box Camera (Part 2) Color 0.15 Lux GV-BX1300 Series 0.10 Lux GV-BX5300 Series IR ON 0 Lux Color 0.01 Lux GV-BX1500 Series IR ON 0 Lux Minimum Illumination Color 0.02 Lux GV-BX2500 Series 0.02 Lux IR On 0 Lux Color 0.08 Lux GV-BX2400 Series...
  • Page 544 GV-BX1200 Series GV-BX1300 Series GV-BX1500 Series Up to 72 dB Dynamic GV-BX2500 Series Range GV-BX5300 Series GV-BX2400 Series Up to 100 dB GV-BX3400 Series Fixed Focal Lens (GV-BX1200-0F~2F / BX1300-0F~2F / BX1500-0F~2F / BX2400-0F~2F / BX2500-0F~2F / BX3400-0F~2F / BX1500-8F / BX2400-8F / BX2500-8F / BX3400-8F / BX5300-8F) Megapixel Day/Night...
  • Page 545 Specifications: Box Camera (Part 2) GV-BX1200-2F GV-BX1300-2F GV-BX1500-2F 12 mm GV-BX2400-2F GV-BX2500-2F GV-BX3400-2F Focal Length GV-BX1500-8F GV-BX2400-8F 2.8 mm GV-BX2500-8F GV-BX3400-8F GV-BX5300-8F GV-BX1200-0F GV-BX1300-0F GV-BX1500-0F F/1.5 GV-BX2400-0F GV-BX2500-0F GV-BX3400-0F GV-BX1200-1F GV-BX1200-2F GV-BX1300-1F Maximum Aperture GV-BX1300-2F GV-BX1500-1F GV-BX1500-2F F/1.6 GV-BX2400-1F GV-BX2400-2F GV-BX2500-1F GV-BX2500-2F GV-BX3400-1F...
  • Page 546 GV-BX1500-8F GV-BX2400-8F Maximum Aperture GV-BX2500-8F F/1.8 GV-BX3400-8F GV-BX5300-8F Mount GV-BX1200-0F GV-BX1300-0F GV-BX1500-0F 1/3” GV-BX2400-0F GV-BX2500-0F GV-BX3400-0F GV-BX1200-1F GV-BX1200-2F GV-BX1300-1F GV-BX1300-2F GV-BX1500-1F Image Format GV-BX1500-2F GV-BX2400-1F GV-BX2400-2F GV-BX2500-1F 1/2.5” GV-BX2500-2F GV-BX3400-1F GV-BX3400-2F GV-BX1500-8F GV-BX2400-8F GV-BX2500-8F GV-BX3400-8F GV-BX5300-8F...
  • Page 547 Specifications: Box Camera (Part 2) GV-BX1200-0F 63° GV-BX1300-0F 49° GV-BX1500-0F 63° GV-BX2400-0F 58° GV-BX2500-0F 72° GV-BX3400-0F 61° GV-BX1200-1F 36° GV-BX1300-1F 26° GV-BX1500-1F 36° GV-BX2400-1F 32° GV-BX2500-1F 40° Horizontal FOV GV-BX3400-1F 35° GV-BX1200-2F 23° GV-BX1300-2F 17° GV-BX1500-2F 23° GV-BX2400-2F 21° GV-BX2500-2F 25°...
  • Page 548 Torque (Focus Screw) 0.049 N.m Varifocal Lens with DC Iris (GV-BX1200-3V / BX1300-3V / BX1500-3V / BX2400-3V / BX2400-4V / BX2500-3V / BX3400-4V / BX3400-5V / BX5300-6V) Megapixel Day/Night Yes (with removable IR-cut filter) GV-BX1200-3V GV-BX1300-3V 2.8 ~ 12 mm GV-BX1500-3V GV-BX2400-3V GV-BX2500-3V...
  • Page 549 Specifications: Box Camera (Part 2) GV-BX1200-3V GV-BX1300-3V GV-BX1500-3V 1/2.7’’ GV-BX2400-3V Image Format GV-BX2500-3V GV-BX2400-4V GV-BX3400-4V GV-BX3400-5V 1/3’’ GV-BX5300-6V 1/2’’ GV-BX1200-3V 87° ~ 31° GV-BX1300-3V 64° ~ 23° GV-BX1500-3V 86° ~ 31° GV-BX2400-3V 77° ~ 28° Horizontal FOV GV-BX2500-3V 105° ~ 36° GV-BX2400-4V 73°...
  • Page 550 Torque 0.049 N.m (Focus / Zoom screws) Varifocal Lens with P-Iris (Coming) (GV-BX1500-3V / GV-BX1500-4V / BX2400-3V / BX2400-4V / BX2500-3V / BX2500-4V / BX3400-3V / BX3400-4V / BX5300-6V) Megapixel Day/Night Yes (with removable IR-cut filter) GV-BX1500-3V GV-BX2400-3V 3 ~ 10.5 mm GV-BX2500-3V GV-BX3400-3V Focal Length...
  • Page 551 Specifications: Box Camera (Part 2) GV-BX5300-6V 1/2.5’’ GV-BX1500-3V 81° ~ 29° GV-BX1500-4V 35° ~ 16° GV-BX2400-3V 73° ~ 27° GV-BX2400-4V 32° ~ 14° Horizontal FOV GV-BX2500-3V 96° ~ 34° GV-BX2500-4V 40° ~ 19° GV-BX3400-3V 78° ~ 28° GV-BX3400-4V 35° ~ 15° GV-BX5300-6V 84°...
  • Page 552 Compensation, WDR, Defog, Super Low Lux, Denoise, Metering Audio Compression G.711, AAC (Optional) Audio Support Two-Way Audio Sensor Input 1 input (Dry Contact) Alarm Output 1 Digital Output (200mA 5V DC) Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes).
  • Page 553 Specifications: Box Camera (Part 2) 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 16:9 Stream 640 x 360, 448 x 252 GV-BX3400 Series 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 554 Mechanical Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Using the built-in microphone or externally connecting a microphone) Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14”) GV-BX1200 Series GV-BX1300 Series GV-BX1500 Series Yes (with varifocal lens) GV-BX2400 Series Auto Iris...
  • Page 555 Specifications: Box Camera (Part 2) USB flash drives and USB hubs are not supported • External power supply is required for the USB hard drive • To connect a GV-WiFi Adapter, make sure it is connected before the • camera is powered on. General Environment Temperature 0°C ~ 50°C (32°F ~ 122°F)
  • Page 556 GV-BX1500 Series CE, FCC, RCM, RoHS compliant GV-BX2500 Series Power over Ethernet PoE (IEEE 802.3af Class 3 Power PoE Standard over Ethernet / PD) PoE Power Supply Type End-Span Per Port 48V DC, 350mA. Max. PoE Power Output 15.4 watts Web Interface Installation Management Web-based configuration...
  • Page 557 Specifications: Box Camera (Part 2) Application GV-Backup Center, GV-NVR, Network Storage GV-Recording Server, GV-System, GV-VMS GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV-Vital CMS Server support Sign Monitor All specifications are subject to change without notice.

  • Page 558: Specifications: Ultra Box Camera

    Specifications: Ultra Box Camera Camera 1/2.5’’ progressive scan Image Sensor CMOS GV-UBX1301 Series 1280 (H) x 1024 (V) Picture GV-UBX2301 Series 1920 (H) x 1080 (V) Elements GV-UBX3301 Series 2048 (H) x 1536 (V) Color 0.15 Lux Minimum 0.10 Lux Illumination IR ON 0 Lux...
  • Page 559 Specifications: Ultra Box Camera GV-UBX1301-1F GV-UBX2301-1F 4 mm GV-UBX3301-1F Focal Length GV-UBX1301-2F GV-UBX2301-2F 8 mm GV-UBX3301-2F GV-UBX1301-0F F/2.0 GV-UBX2301-0F GV-UBX3301-0F GV-UBX1301-1F Maximum GV-UBX2301-1F Aperture GV-UBX3301-1F F/1.6 GV-UBX1301-2F GV-UBX2301-2F GV-UBX3301-2F Mount M12, Pitch 0.5 mm Image Format 1/3” GV-UBX1301-0F 69° 49° GV-UBX1301-1F 25°...
  • Page 560 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H. 264 or MJPEG GV-UBX1301 Series 30 fps at 1280 x 1024 Frame Rate GV-UBX2301 Series 30 fps at 1920 x 1080 GV-UBX3301 Series 20 fps at 2048 x 1536 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation,...
  • Page 561 Specifications: Ultra Box Camera 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 640 x Stream 16:9 360, 448 x 252 GV-UBX2301 Series 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 562 Mechanical Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Using the built-in microphone) Connectors Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14”) Micro SD card slot Local Storage (SD/SDHC, version 2.0 only, Class 10) LED Indicator 2 LEDs: Power, Status Note: SDXC and UHS-I card types are note supported.
  • Page 563 Specifications: Ultra Box Camera Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording, change video quality, bandwidth control, image Access from Web Browser snapshot, audio, Picture in Picture, Picture and Picture, Privacy Mask, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German /...

  • Page 564: Specifications: Target Box Camera

    Specifications: Target Box Camera Camera Image Sensor 1/3’’ progressive scan low lux CMOS Picture Elements 1280 (H) x 1024 (V) Color 0.05 Lux Minimum Illumination 0.03 Lux IR ON 0 Lux Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic...

  • Page 565: Video Compression

    Specifications: Target Box Camera Operation (Focus / Zoom / Fixed Iris) IR LED Quantity 8 IR LEDs Max. IR Distance 15 m (50 ft) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H. 264 or MJPEG Frame Rate 30 fps at 1280 x 1024 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance,...
  • Page 566 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical Power 2-pin terminal block, PoE Connectors Ethernet Ethernet (10/100 Base-T), RJ-45 cable Audio 1 In (built-in microphone) LED Indicator 2 LEDs: Power, Status General...

  • Page 567: Network Storage

    Specifications: Target Box Camera Web Interface Installation Management Web-based configuration Maintenance Firmware upgrade through Web Browser or Utility Camera live view, video recording, change video Access from Web quality, bandwidth control, image snapshot, audio, Browser Picture in Picture, Picture and Picture, Privacy Mask, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew /...

  • Page 568: Specifications: Ir Arctic Box Camera

    Specifications: IR Arctic Box Camera Camera GV-BX120D-E 1/3" progressive scan low lux CMOS GV-BX1500-E 1/3" progressive scan super low lux CMOS 1/2.8" progressive scan super low lux GV-BX2510-E CMOS GV-BX2400-E 1/3.2" progressive scan CMOS Image GV-BX3400-E Sensor 1/2.5" progressive scan super low lux...
  • Page 569 Specifications: IR Arctic Box Camera Color 0.05 Lux GV-BX120D-E 0.03 Lux IR ON 0 Lux Color 0.01 Lux 0.01 Lux GV-BX1500-E IR ON 0 Lux IR ON 0 Lux Color 0.08 Lux GV-BX2400-E Minimum 0.05 Lux GV-BX3400-E Illumination IR ON...
  • Page 570 GV-BX5300-E GV-BX5310-E GV-BX2400-E WDR Pro GV-BX3400-E GV-BX120D-E GV-BX1500-E GV-BX220D-E GV-BX2510-E Up to 72 dB GV-BX320D-E Dynamic GV-BX520D-E Range GV-BX5300-E GV-BX5310-E GV-BX2400-E Up to 100 dB GV-BX3400-E Lens Megapixel Day/Night Yes (with removable IR-cut filter) GV-BX120D-E GV-BX1500-E GV-BX220D-E GV-BX320D-E Varifocal Lens...
  • Page 571 GV-BX320D-E GV-BX1500-E GV-BX2400-E 3 ~ 10.5 mm Focal GV-BX3400-E Length GV-BX2510-E 3.7 ~ 9 mm GV-BX520D-E 4.5 ~ 10 mm GV-BX5300-E GV-BX5310-E 4.5 ~ 9 mm GV-BX120D-E GV-BX1500-E F/1.4 GV-BX2400-E GV-BX3400-E GV-BX220D-E Maximum F/1.3 Aperture GV-BX320D-E GV-BX520D-E F/1.6 GV-BX5300-E GV-BX2510-E F/1.2...
  • Page 572 81° ~ 29° GV-BX2400-E 73° ~ 27° GV-BX2510-E 85° ~ 36° Horizontal 78° ~ 28° GV-BX3400-E GV-BX5300-E 70° ~ 34° GV-BX5310-E 70° ~ 39° GV-BX120D-E Focus Manual (w/lock) GV-BX1500-E Zoom Manual (w/lock) GV-BX220D-E GV-BX2400-E Iris DC drive GV-BX320D-E GV-BX3400-E Focus...
  • Page 573 Specifications: IR Arctic Box Camera GV-BX120D-E GV-BX1500-E GV-BX220D-E GV-BX2400-E 15 m (50 ft) GV-BX320D-E Max. IR GV-BX3400-E Distance GV-BX520D-E GV-BX5300-E GV-BX2510-E 70 m (230 ft) GV-BX5310-E 50 m (164 ft) Max. Torque 0.049 N.m (Focus/Zoom screws) Note: The maximum torque value is not applicable for GV-BX2510-E / 5310-E which do not contain focus or zoom screws for manual adjustment.
  • Page 574 1280 x 960, 640 x 480, 320 x 240 Main 16:9 1280 x 720, 640 x 360, 448 x 252 Stream 1280 x 1024, 640 x 512, 320 x 256 GV-BX120D-E 640 x 480, 320 x 240 GV-BX1500-E 16:9 640 x 360, 448 x 252 Stream...
  • Page 575 Specifications: IR Arctic Box Camera 640 x 480, 320 x 240 GV-BX220D-E GV-BX2400-E 16:9 640 x 360, 448 x 252 Stream GV-BX2510-E 640 x 512, 320 x 256 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, Stream...
  • Page 576 Mechanical (for GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E) 0° ~ 330° Camera Angle Adjustment Tilt 0° ~ 90° Temperature Detector Power Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (externally connecting a microphone) Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14”)
  • Page 577 Specifications: IR Arctic Box Camera Mechanical (for GV-BX2510-E / 5310-E) 0° ~ 270° Camera Angle Adjustment Tilt 0° ~ 90° Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (stereo phone jack, 3.5 mm / 0.14”) Audio 1 Out (Stereo phone jack, 3.5 mm / 0.14”) Digital I/O I/O wires...
  • Page 578 GV-BX120D-E GV-BX220D-E GV-BX320D-E GV-BX520D-E PoE+ (IEEE 802.3at) GV-BX1500-E Power Source GV-BX2400-E GV-BX3400-E GV-BX5300-E GV-BX2510-E AC 24V, DC 48V, PoE++ (50W) GV-BX5310-E GV-BX120D-E GV-BX220D-E 24 W GV-BX320D-E GV-BX520D-E GV-BX1500-E 20 W Max. Power GV-BX2400-E Consumption 23 W GV-BX3400-E GV-BX5300-E 21.6 W...
  • Page 579 Specifications: IR Arctic Box Camera 406 x 145 x 109 mm Camera Body GV-BX2510-E (16” x 5.7” x 4.3”) Dimensions GV-BX5310-E Cable Length 1 m (39.4”) GV-BX120D-E GV-BX220D-E GV-BX320D-E GV-BX520D-E 3.2 kg (7.11 lb) GV-BX1500-E Weight GV-BX2400-E GV-BX3400-E GV-BX5300-E GV-BX2510-E 3.32 kg (7.32 lb)
  • Page 580 Power over Ethernet (for GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E) PoE+ (IEEE 802.3at Power over PoE Standard Ethernet / PD) PoE Power Supply Type End-Span Per Port 48V DC, 600mA. Max. 34.2...
  • Page 581 Specifications: IR Arctic Box Camera Power Input AC 100V ~ 240V, 2.5A Operating Temperature -10°C ~ 50°C (14°F ~ 122°F) Dimensions 69 x 43 x 40 (2.72 x 1.69 x 1.57”) Weight 130 g (0.29 lb) Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance...
  • Page 582 Application GV-Backup Center, GV-NVR, Network Storage GV-Recording Server, GV-System, GV-VMS GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV-Vital CMS Server support Sign Monitor All specifications are subject to change without notice.

  • Page 583: Specifications: Mini Fixed Dome (Part 1)

    Specifications: Mini Fixed Dome (Part 1) Specifications: Mini Fixed Dome (Part 1) This section details the specifications on GV-MFD120 / 130 / 220 / 320 / 520. Camera GV-MFD120 1/3" progressive scan low lux CMOS Image GV-MFD130 Sensor 1/2.5’’ progressive scan CMOS GV-MFD320 GV-MFD120 1280 (H) x 1024 (V)
  • Page 584 Lens Megapixel Day/Night Yes (electronic) Lens Type Fixed GV-MFD120 4.05 mm Focal GV-MFD130 Length 2.54 mm GV-MFD320 GV-MFD120 F/1.5 Maximum GV-MFD130 Aperture F/2.8 GV-MFD320 M12, Pitch 0.5 mm Mount GV-MFD120 1/3’’ Image GV-MFD130 Format 1/2.5’’ GV-MFD320 GV-MFD120 67° Horizontal GV-MFD130 85°...
  • Page 585 Specifications: Mini Fixed Dome (Part 1) GV-MFD120 30 fps at 1280 x 1024 Frame GV-MFD130 Rate GV-MFD320 20 fps at 2048 x 1536 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less 50/60 Hz, Image Orientation, Image Setting Shutter Speed, Backlight Compensation, D/N sensitivity, WDR, Defog, Denoise, Metering Audio Compression...
  • Page 586 640 x 480, 320 x 240 GV-MFD320 Sub Stream 16:9 640 x 360, 448 x 252 640 x 512, 320 x 256 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile Protocol S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical Camera...
  • Page 587 Specifications: Mini Fixed Dome (Part 1) General Environment Temperature 0°C ~ 50°C (32°F ~ 122°F) Humidity 10% - 90% (no condensation) GV-MFD120 Power GV-MFD130 PoE, DC 12V Source GV-MFD320 GV-MFD120 4.5 W Max. Power GV-MFD130 Consumption 5.5 W GV-MFD320 Camera Body ø106 x 55.6 mm (4.2’’...
  • Page 588 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Maintenance Browser or Utility Camera live view, video recording, change video quality, bandwidth Access from Web Browser control, image snapshot, audio, Picture in Picture, Picture and Picture, Privacy Mask, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian /...

  • Page 589: Specifications: Mini Fixed Dome (Part 2)

    Specifications: Mini Fixed Dome (Part 2) Specifications: Mini Fixed Dome (Part 2) This section details the specifications on GV-MFD1501 series / 2401 series / 2501 series / 3401 series / 5301 series. Camera 1/3’’ progressive scan super low GV-MFD1501 Series lux CMOS 1/2.8’’...
  • Page 590 Automatic, Manual (1/5 ~ Shutter Speed 1/8000 sec) Automatic, Manual (2800K ~ White Balance 8500K) Gain Control Automatic GV-MFD1501 Series GV-MFD2401 Series 55 dB GV-MFD3401 Series S/N Ratio GV-MFD5301 Series 52 dB GV-MFD2501 Series GV-MFD2401 Series WDR Pro GV-MFD3401 Series GV-MFD1501 Series Up to 72 dB GV-MFD2501 Series...
  • Page 591 Specifications: Mini Fixed Dome (Part 2) GV-MFD1501-1F 4 mm GV-MFD2501-1F GV-MFD1501-2F GV-MFD2401-2F 8 mm GV-MFD2501-2F GV-MFD3401-2F GV-MFD5301-2F GV-MFD1501-3F GV-MFD2401-3F 12 mm GV-MFD2501-3F Focal GV-MFD3401-3F Length GV-MFD5301-3F GV-MFD1501-4F GV-MFD2401-4F 2.1 mm GV-MFD2501-4F GV-MFD3401-4F GV-MFD1501-5F GV-MFD2401-5F 3.8 mm GV-MFD2501-5F GV-MFD3401-5F GV-MFD5301-5F GV-MFD1501-0F GV-MFD2401-0F F/2.0 GV-MFD2501-0F...
  • Page 592 GV-MFD1501-2F GV-MFD1501-3F GV-MFD2401-2F GV-MFD2401-3F GV-MFD2501-2F F/1.6 GV-MFD2501-3F GV-MFD3401-2F GV-MFD3401-3F GV-MFD5301-2F Maximum GV-MFD5301-3F Aperture GV-MFD1501-4F GV-MFD2401-4F GV-MFD2501-4F GV-MFD3401-4F F/1.8 GV-MFD1501-5F GV-MFD2401-5F GV-MFD2501-5F GV-MFD3401-5F GV-MFD5301-5F M12, Pitch 0.5 mm Mount Image Format 1/3’’ 87° 67° Horizontal 35° GV-MFD1501 22° 124° 64°...
  • Page 593 Specifications: Mini Fixed Dome (Part 2) 79° 31° GV-MFD2401 20° 112° 60° 99° 72° 38° GV-MFD2501 25° Horizontal 150° 72° 80° 33° GV-MFD3401 21° 120° 63° 103° 41° GV-MFD5301 26° 76° Operation Fixed (Focus / Zoom / Iris) Note: The day/night function is only supported by V1.07 or later.
  • Page 594 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG 30 fps at 1280 x 1024 GV-MFD1501 Series GV-MFD2401 Series 30 fps at 1920 x 1080 Frame GV-MFD2501 Series Rate GV-MFD3401 Series 20 fps at 2048 x 1536 10 fps at 2560 x 1920 GV-MFD5301 Series Brightness, Contrast, Saturation,...
  • Page 595 Specifications: Mini Fixed Dome (Part 2) Video Resolution 1280 x 960, 640 x 480, 320 x 240 16:9 1280 x 720, 640 x 360, 448 x 252 Main Stream 1280 x 1024, 640 x 512, GV-MFD1501 320 x 256 Series 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 596 640 x 480, 320 x 240 GV-MFD5301 Sub Stream 16:9 640 x 360, 448 x 252 Series 640 x 512, 320 x 256 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical -45°...
  • Page 597 Specifications: Mini Fixed Dome (Part 2) the camera is powered on. SDXC and UHS-I card types are not supported. General Camera Housing black, white Environment Temperature 0°C ~ 50°C (32°F ~ 122°F) Humidity 10% - 90% (no condensation) Power Source PoE, DC 5V Max.
  • Page 598 Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Language Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish...

  • Page 599: Specifications: Mini Fixed Rugged Dome

    Specifications: Mini Fixed Rugged Dome Specifications: Mini Fixed Rugged Dome Camera 1/3" progressive scan super low lux GV-MDR1500 Series CMOS GV-MDR220 Image GV-MDR320 1/2.5’’ progressive scan CMOS Sensor GV-MDR520 GV-MDR5300 Series GV-MDR3400 Series 1/3.2’’ progressive scan CMOS GV-MDR1500 Series 1280 (H) x 1024 (V) GV-MDR220 1920 (H) x 1080 (V) Picture...
  • Page 600 Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic GV-MDR220 GV-MDR320 45 dB GV-MDR520 S/N Ratio GV-MDR5300 Series GV-MDR1500 Series 55 dB GV-MDR3400 Series 47 dB WDR Pro GV-MDR3400 Series Yes (with WDR sensor) GV-MDR1500 Series GV-MDR220 GV-MDR320...
  • Page 601 Specifications: Mini Fixed Rugged Dome GV-MDR220 2.54 mm GV-MDR320 GV-MDR520 GV-MDR1500-1F 2.8 mm Focal Length GV-MDR3400-1F GV-MDR5300-1F GV-MDR1500-2F 3.8 mm GV-MDR3400-2F GV-MDR5300-2F GV-MDR220 F/2.8 GV-MDR320 GV-MDR520 GV-MDR1500-2F Maximum F/1.8 GV-MDR3400-2F Aperture GV-MDR5300-2F GV-MDR1500-1F F/2.0 GV-MDR3400-1F GV-MDR5300-1F M12, Pitch 0.5 mm Mount GV-MDR1500 Series GV-MDR3400 Series...
  • Page 602 GV-MDR220 101° GV-MDR320 110° GV-MDR520 138° 88° GV-MDR1500 Horizontal 64° 85° GV-MDR3400 63° 104° GV-MDR5300 76° Operation (Focus / Zoom / Iris) Fixed Operation Video Compression H.264, MJPEG Dual streams from H.264 or Video Stream MJPEG GV-MDR1500 Series 30 fps at 1280 x 1024 Frame Rate GV-MDR220 30 fps at 1920 x 1080...
  • Page 603 Specifications: Mini Fixed Rugged Dome Audio Support One-Way Audio Sensor Input Alarm Output Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). The super low lux setting is only available in GV-MDR1500 series Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream...
  • Page 604 2560 x 1920, 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x Main Stream 1920 x 1080, 1280 x 720, 640 x 360, 16:9 448 x 252 GV-MDR520 GV-MDR5300 Series 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 605 Specifications: Mini Fixed Rugged Dome General Environment Temperature -30°C ~ 50°C (-22°F ~ 122°F) Humidity 10% - 90% (no condensation) Power Source GV-MDR220 3.4 W GV-MDR320 GV-MDR520 3.6 W Max. Power Consumption GV-MDR1500 Series 3.47 W GV-MDR3400 Series 4.28 W GV-MDR5300 Series 3.81 W Camera Body...
  • Page 606 Power over Ethernet PoE (IEEE 802.3af Power over Ethernet / PoE Standard GV-MDR220 End-Span and Mid-Span GV-MDR320 GV-MDR520 PoE Power Supply Type GV-MDR1500 Series End-Span GV-MDR3400 Series GV-MDR5300 Series Per Port 48V DC, 350 mA. Max. 15.4 watts PoE Power Output Web Interface Installation Management Web-based configuration...
  • Page 607 Specifications: Mini Fixed Rugged Dome Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV-Vital Sign CMS Server support Monitor All specifications are subject to change without notice.

  • Page 608: Specifications: Target Mini Fixed Dome

    Specifications: Target Mini Fixed Dome Camera GV-EFD1100 Series 1/3’’ progressive scan low lux CMOS Image Sensor GV-EFD2100 Series 1/2.8’’ progressive scan low lux CMOS GV-EFD1100 Series 1280 (H) x 1024 (V) Picture Elements GV-EFD2100 Series 1920 (H) x 1080 (V) Color 0.05 Lux GV-EFD1100...
  • Page 609 Specifications: Target Mini Fixed Dome Lens Megapixel Day/Night Yes (with removable IR-cut filter) Lens Type Fixed GV-EFD1100-0F 2.8 mm GV-EFD2100-0F Focal Length GV-EFD1100-2F 3.8 mm GV-EFD2100-2F GV-EFD1100-0F F/2.0 GV-EFD2100-0F Maximum Aperture GV-EFD1100-2F F/1.8 GV-EFD2100-2F Mount M12, Pitch 0.5 mm Image Format 1/2.7”...
  • Page 610 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Image Setting Flicker-less, Image Orientation, Shutter Speed, D/N Sensitivity, Backlight Compensation, WDR, Defog Audio Compression G.711, AAC (Optional) Audio Support One-Way Audio Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes).
  • Page 611 Specifications: Target Mini Fixed Dome Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile S), Protocol QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical -45° ~ 45° Camera Angle Adjustment Tilt 0° ~ 63° Power 2-pin terminal block, PoE Connectors Ethernet...
  • Page 612 Power over Ethernet PoE Standard PoE (IEEE 802.3af Power over Ethernet / PD) PoE Power Supply End-Span Type PoE Power Output Per Port 48V DC, 350 mA. Max. 15.4 watts Web Interface Installation Web-based configuration Management Maintenance Firmware upgrade through Web Browser or Utility Camera Live View, Video Recording, Change Access from Web Video Quality, Bandwidth Control, Image Snapshot,...

  • Page 613: Specifications: Target Mini Fixed Rugged Dome

    Specifications: Target Mini Fixed Rugged Dome Specifications: Target Mini Fixed Rugged Dome Camera GV-EDR1100 Series 1/3’’ progressive scan low lux CMOS Image Sensor GV-EDR100 Series 1/2.8’’ progressive scan low lux CMOS GV-EDR1100 Series 1280 (H) x 1024 (V) Picture Elements GV-EDR2100 Series 1920 (H) x 1080 (V) Color...
  • Page 614 Lens Megapixel Day/Night Yes (with removable IR-cut filter) Lens Type Fixed GV-EDR1100-0F 2.8 mm GV-EDR2100-0F Focal Length GV-EDR1100-2F 3.8 mm GV-EDR2100-2F GV-EDR1100-0F F/2.0 GV-EDR2100-0F Maximum Aperture GV-EDR1100-2F F/1.8 GV-EDR2100-2F Mount M12, Pitch 0.5 mm Image Format 1/2.7” 93° GV-EDR1100-0F 64° GV-EDR1100-2F Horizontal 99°...
  • Page 615 Specifications: Target Mini Fixed Rugged Dome Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Image Setting Flicker-less, Image Orientation, Shutter Speed, D/N Sensitivity, Backlight Compensation, WDR, Defog Audio Support Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes).
  • Page 616 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF (Profile S), Protocol QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical -45° ~ 45° Camera Angle Adjustment Tilt 0° ~ 63° Power 2-pin terminal block, PoE Connectors Ethernet Ethernet (10/100 Base-T), RJ-45 cable LED Indicator...
  • Page 617 Specifications: Target Mini Fixed Rugged Dome Power over Ethernet PoE Standard PoE (IEEE 802.3af Power over Ethernet / PD) PoE Power Supply End-Span Type PoE Power Output Per Port 48V DC, 350 mA. Max. 15.4 watts Web Interface Installation Web-based configuration Management Maintenance Firmware upgrade through Web Browser or Utility...

  • Page 618: Specifications: Bullet Camera (Part 1)

    Specifications: Bullet Camera (Part 1) This section details the specifications on GV-BL120D / 130D / 220D / 320D and GV-BL1500 / 2400 / 2500 / 3400. Camera GV-BL120D 1/3" progressive scan low lux CMOS GV-BL130D GV-BL220D 1/2.5’’ progressive scan CMOS GV-BL320D 1/3’’...
  • Page 619 Specifications: Bullet Camera (Part 1) GV-BL320D Picture 2048 (H) x 1536 (V) Elements GV-BL3400 Color 0.05 Lux GV-BL120D 0.03 Lux IR ON 0 Lux Color 0.15 Lux GV-BL130D GV-BL220D 0.10 Lux GV-BL320D IR On 0 Lux Color 0.01 Lux Minimum GV-BL1500 0.01 Lux Illumination...
  • Page 620 GV-BL130D 45 dB GV-BL220D GV-BL320D GV-BL1500 55 dB S/N Ratio GV-BL2500 52 dB GV-BL2400 47 dB GV-BL3400 GV-BL2400 WDR Pro Yes (with WDR sensor) GV-BL3400 GV-BL120D GV-BL130D GV-BL1500 Up to 72 dB GV-BL220D Dynamic GV-BL2500 Range GV-BL320D GV-BL2400 Up to 100 dB GV-BL3400 Lens Megapixel...
  • Page 621 Specifications: Bullet Camera (Part 1) Focal Length 3 ~ 9 mm Maximum Aperture F/1.2 Mount ø 14 mm Image Format 1/2.7’’ GV-BL1500 90° ~ 32° GV-BL2400 82° ~ 30° Horizontal GV-BL2500 103° ~ 36° GV-BL3400 86° ~ 31° Focus Manual (w/lock) Zoom Manual (w/lock) GV-BL120D...
  • Page 622 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-BL120D GV-BL130D 30 fps at 1280 x 1024 GV-BL1500 Frame Rate GV-BL220D 30 fps at 1920 x 1080 GV-BL2400 GV-BL2500 GV-BL320D 20 fps at 2048 x 1536 GV-BL3400 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance,...
  • Page 623 Specifications: Bullet Camera (Part 1) Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 GV-BL120D 1280 x 1024, 640 x 512, 320 x 256 GV-BL130D 640 x 480, 320 x 240 GV-BL1500 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 624 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA Mechanical 0° ~ 360° Camera Angle Tilt 90° ~ 180° Adjustment Rotate 0° ~ 360° Temperature Detector Power 2-pin terminal block, PoE Ethernet...
  • Page 625 Specifications: Bullet Camera (Part 1) GV-BL1500 GV-BL2400 -30°C ~ 50°C (-22°F ~ 122°F) GV-BL2500 GV-BL3400 Humidity 10% to 90% (no condensation) Power Source 12V DC, 24V AC, PoE GV-BL120D GV-BL130D 12 W GV-BL220D GV-BL320D Max. Power Consumption GV-BL1500 7.68 W GV-BL2500 GV-BL2400 7.2 W...
  • Page 626 GV-BL120D GV-BL130D IP66 GV-BL220D GV-BL320D Ingress Protection GV-BL1500 GV-BL2400 IP67 GV-BL2500 GV-BL3400 GV-BL1500 GV-BL2400 Vandal IK10 for metal casing Resistance GV-BL2500 GV-BL3400 GV-BL120D GV-BL130D GV-BL220D CE, FCC, C-Tick, RoHS GV-BL320D compliant GV-BL1500 Regulatory GV-BL2400 GV-BL3400 GV-BL1500 CE, FCC, RCM, RoHS compliant GV-BL2500 Power over Ethernet PoE (IEEE 802.3af Power over Ethernet /...
  • Page 627 Specifications: Bullet Camera (Part 1) Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Picture Access from Web Browser in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ...

  • Page 628: Specifications: Bullet Camera (Part 2)

    Specifications: Bullet Camera (Part 2) This section details the specifications on GV-BL1210 / 1510 / 2410 / 2510 / 2510-E / 3410 / 5310 / 5310-E. Camera GV-BL1210 1/3" progressive scan low lux CMOS GV-BL1510 1/3" progressive scan super low lux CMOS GV-BL2510 1/2.8"...
  • Page 629 Specifications: Bullet Camera (Part 2) Color 0.05 Lux GV-BL1210 0.03 Lux IR ON 0 Lux Color 0.01 Lux GV-BL1510 0.01 Lux IR ON 0 Lux Color 0.02 Lux Minimum GV-BL2510 0.02 Lux Illumination GV-BL2510-E IR ON 0 Lux Color 0.08 Lux GV-BL2410 0.05 Lux GV-BL3410...
  • Page 630 GV-BL2410 WDR Pro Yes (with WDR sensor) GV-BL3410 GV-BL1210 GV-BL1510 GV-BL2510 Up to 72 dB GV-BL2510-E Dynamic Range GV-BL5310 GV-BL5310-E GV-BL2410 Up to 100 dB GV-BL3410 Lens Megapixel Day / Night Yes (with removable IR-cut filter) Lens Type Motorized varifocal lens GV-BL1210 GV-BL1510 GV-BL2410...
  • Page 631 Specifications: Bullet Camera (Part 2) GV-BL1210 86° ~ 32° GV-BL1510 90° ~ 32° GV-BL2410 82° ~ 30° Horizontal GV-BL2510 103° ~ 36° GV-BL2510-E GV-BL3410 86° ~ 31° GV-BL5310 70° ~ 39° GV-BL5310-E Focus Auto Focus GV-BL1210 GV-BL1510 GV-BL2410 3x Optical Zoom GV-BL2510 Zoom GV-BL2510-E...
  • Page 632 GV-BL1210 40 m (131 ft) GV-BL5310 GV-BL5310-E GV-BL1510 70 m (230 ft) Max. IR Distance GV-BL2410 GV-BL2510 50 m (164 ft) GV-BL2510-E GV-BL3410 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-BL1210 30 fps at 1280 x 1024 GV-BL1510 GV-BL2410 GV-BL2510...
  • Page 633 Specifications: Bullet Camera (Part 2) Audio Compression G.711, AAC (Optional) Audio Support Two-Way Audio Sensor Input 1 Input (Dry Contact) Alarm Output 1 Output (200mA 5V DC) Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). The Super Low Lux adjustment (Image Settings) is only available for GV-BL1510 / 2510 / 2510-E.
  • Page 634 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 16:9 640 x 360, 448 x 252 GV-BL3410 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 Sub Stream 16:9...
  • Page 635 Specifications: Bullet Camera (Part 2) Mechanical 0° ~ 360° Camera Angle Tilt 90° ~ 180° Adjustment Rotate 0° ~ 360° Temperature Detector GV-BL1210 GV-BL1510 GV-BL2410 2-pin terminal block, PoE GV-BL2510 Power GV-BL3410 GV-BL5310 GV-BL2510-E 2-pin terminal block GV-BL5310-E Connectors Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Brown terminal block or RCA female for Audio...
  • Page 636 General GV-BL1210 GV-BL1510 GV-BL2410 -20°C ~ 50°C (-4°F ~ 122°F) GV-BL2510 Environment Temperature GV-BL3410 GV-BL5310 GV-BL2510-E -40°C ~ 50°C (-40°F ~ 122°F) GV-BL5310-E Humidity 10% to 90% (no condensation) GV-BL1210 GV-BL1510 GV-BL2410 12V DC / 24V AC / PoE GV-BL2510 Power Source GV-BL3410 GV-BL5310...
  • Page 637 Specifications: Bullet Camera (Part 2) 289.02 x 87.75 x 148.95 mm Camera Body (11.4” x 3.45” x 5.86’’) Cable Length 1 m (3.28 ft) Max. Cable Dimensions ø7.1 mm (0.28”) Diameter Max. ø25.2 mm (0.99”) Connector Diameter Weight 1.4 Kg (3.08 lb) GV-BL2510-E On: -40°C ~ 30°C (-40 °F ~ 86°F);...
  • Page 638 Power over Ethernet PoE Standard PoE (IEEE 802.3af Power over Ethernet / PD) PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Note: GV-BL2510-E / 5310-E do not support PoE. Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance...
  • Page 639 Specifications: Bullet Camera (Part 2) GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV-Vital CMS Server support Sign Monitor All specifications are subject to change without prior notice.

  • Page 640: Specifications: Ultra Bullet Camera

    Specifications: Ultra Bullet Camera Camera GV-UBL1211 1/3" progressive scan low lux CMOS GV-UBL1301 Series 1/2.5’’ progressive scan CMOS 1/3" progressive scan super low lux GV-UBL1511 CMOS Image 1/2.8" progressive scan super low lux Sensor GV-UBL2511 CMOS GV-UBL2411 GV-UBL3411 1/3.2’’ progressive scan CMOS GV-UBL2401 Series GV-UBL3401 Series GV-UBL1211...
  • Page 641 Specifications: Ultra Bullet Camera Color 0.01 Lux GV-UBL1511 0.01 Lux IR ON 0 Lux Color 0.02 Lux GV-UBL2511 0.02 Lux IR ON 0 Lux Color 0.08 Lux Minimum GV-UBL2411 0.05 Lux Illumination GV-UBL3411 IR ON 0 Lux Color 0.15 Lux GV-UBL1301 Series 0.10 Lux IR ON...
  • Page 642 GV-UBL1211 GV-UBL1301 Series Up to 72 dB GV-UBL1511 GV-UBL2511 Dynamic Range GV-UBL2411 GV-UBL3411 Up to 100 dB GV-UBL2401 Series GV-UBL3401 Series Lens Megapixel Day / Night Yes (with removable IR-cut filter) GV-UBL1211 GV-UBL1511 GV-UBL2411 Motorized varifocal Lens GV-UBL2511 Lens Type GV-UBL3411 GV-UBL1301 Series GV-UBL2401 Series...
  • Page 643 Specifications: Ultra Bullet Camera GV-UBL1301-1F GV-UBL2401-1F 4 mm GV-UBL3401-1F GV-UBL1301-2F Focal GV-UBL2401-2F 8 mm Length GV-UBL3401-2F GV-UBL1301-3F 12 mm GV-UBL2401-3F GV-UBL3401-3F GV-UBL1211 GV-UBL1511 GV-UBL2411 F/1.2 GV-UBL2511 GV-UBL3411 GV-UBL1301-0F GV-UBL2401-0F F/2.0 GV-UBL3401-0F Maximum GV-UBL1301-1F Aperture GV-UBL2401-1F F/1.5 GV-UBL3401-1F GV-UBL1301-2F GV-UBL2401-2F GV-UBL3401-2F F/1.6 GV-UBL1301-3F GV-UBL2401-3F...
  • Page 644 GV-UBL1211 GV-UBL1511 ø 14 mm GV-UBL2411 GV-UBL2511 Mount GV-UBL3411 GV-UBL1301 Series GV-UBL2401 Series GV-UBL3401 Series GV-UBL1211 GV-UBL1511 GV-UBL2411 1/2.7” GV-UBL2511 Image Format GV-UBL3411 GV-UBL1301 Series GV-UBL2401 Series 1/3” GV-UBL3401 Series GV-UBL1211 86° ~ 32° GV-UBL1511 90° ~ 32° GV-UBL2411 82° ~ 30° GV-UBL2511 103°...
  • Page 645 Specifications: Ultra Bullet Camera 16° GV-UBL1301-3F Horizontal 20° GV-UBL2401-3F GV-UBL3401-3F 21° GV-UBL1211 Focus Auto Focus GV-UBL1511 GV-UBL2411 Zoom 3x Optical Zoom GV-UBL2511 Operation Iris DC Drive GV-UBL3411 Focus GV-UBL1301 Series GV-UBL2401 Series Fixed Zoom GV-UBL3401 Series Iris IR LED Quantity 4 IR LEDs Max.
  • Page 646 Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Shutter Speed, D/N Image Setting Sensitivity, Backlight Compensation, WDR, Defog, Zoom, Focus Change, Super Low Lux, Denoise, Metering Audio Support Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes).
  • Page 647 Specifications: Ultra Bullet Camera 640 x 480, 320 x 240 GV-UBL2411 GV-UBL2401 Series 16:9 640 x 360, 448 x 252 Stream GV-UBL2511 640 x 512, 320 x 256 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720,...
  • Page 648 Digital I/O I/O Wire Connectors Local Micro SD card slot (SD/SDHC, Storage version 2.0 only, Class 10) Note: SDXC and UHS-I card types are not supported. General GV-UBL1211 GV-UBL1511 -10°C ~ 45°C (14°F ~ 113°F) GV-UBL2411 GV-UBL2511 GV-UBL3411 Environment GV-UBL2401 Series Temperature -20°C ~ 45°C (-4°F ~ 113°F) GV-UBL3401 Series...
  • Page 649 Specifications: Ultra Bullet Camera GV-UBL1301 Series Max. Power 5.52 W GV-UBL2401 Series Consumption GV-UBL3401 Series GV-UBL1211 GV-UBL1511 148.75 x 65 x 69 mm GV-UBL2411 (5.9” x 2.6” x 2.7”) GV-UBL2511 Dimensions GV-UBL3411 GV-UBL1301 Series 124 x 65 x 69 mm GV-UBL2401 Series (4.8”...
  • Page 650 GV-UBL1511 Regulatory CE, FCC, RCM, RoHS compliant GV-UBL2511 Power over Ethernet PoE (IEEE 802.3af Power over Ethernet / PoE Standard PoE Power Supply Type End-Span Per Port 48V DC, 350mA. Max. 15.4 PoE Power Output watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance...
  • Page 651 Specifications: Ultra Bullet Camera Application GV-Backup Center, GV-NVR, Network Storage GV-Recording Server, GV-System, GV-VMS GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV-Vital CMS Server support Sign Monitor All specifications are subject to change without prior notice...

  • Page 652: Specifications: Target Bullet Camera

    Specifications: Target Bullet Camera Camera GV-EBL1100 Series 1/3" progressive scan low lux CMOS Image Sensor GV-EBL2100 Series 1/2.8" progressive scan low lux CMOS GV-EBL1100 Series 1280 (H) x 1024 (V) Picture Elements GV-EBL2100 Series 1920 (H) x 1080 (V) Color 0.05 Lux GV-EBL1100 0.03 Lux...
  • Page 653 Specifications: Target Bullet Camera GV-EBL1100-1F 6 mm Focal GV-EBL2100-1F Length GV-EBL1100-2F 3.8 mm GV-EBL2100-2F Maximum Aperture F/1.8 Mount M12, Pitch 0.5 mm Image Format 1/2.7’’ GV-EBL1100-1F 44° GV-EBL1100-2F 64° Horizontal GV-EBL2100-1F 51° GV-EBL2100-2F 72° Operation (Focus / Zoom / Iris) Fixed IR LED Quantity 24 IR LEDs...
  • Page 654 Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-EBL1100 Series 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 655 Specifications: Target Bullet Camera General Start-up -20°C ~ 50°C (-4°F ~ 122°F) Environment Temperature Operation -30°C ~ 50°C (-22°F ~ 122°F) Humidity 10% to 90% (no condensation) Power Source 12V DC, PoE Max. Power Consumption 7.8 W Dimensions 115 x 76 x 73 mm (4.5” x 3.0” x 2.9”) Weight 547 g (1.20 lb) Ingress Protection...
  • Page 656 Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Persian / Language Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish...

  • Page 657: Specifications: Ptz Camera

    Specifications: PTZ Camera Camera Model Name GV-PTZ010D-N GV-PTZ010D-P Image Sensor 1/4" CCD image sensor Picture Elements 704 (H) x 480 (V) 704 (H) x 576 (V) Color 2.5 Lux at F/1.8 Minimum Illumination 0.07 Lux at F/1.8 Automatic, Automatic, Shutter Speed Manual (1/60 ~ Manual (1/50 ~ 1/120,000 sec)
  • Page 658 Operation Model Name GV-PTZ010D-N GV-PTZ010D-P Video Format NTSC Video Compression H.264, MPEG4, MJPEG Dual Streams from two of H.264, MPEG4 or Video Stream MJPEG 704 x 480 704 x 576 Main Stream 704 x 240 704 x 288 Video 352 x 240 352 x 288 Resolution 704 x 480...
  • Page 659 Specifications: PTZ Camera Mechanical -175° ~ 175° Camera Angle Adjustment Tilt -45° ~ 90° Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (Using a built-in or an externally connected microphone) Audio 1 Out (Stereo phone jack, 3.5 mm / Connectors 0.14”) 3-pin terminal block...
  • Page 660 Power over Ethernet PoE (IEEE 802.3af Power over PoE Standard Ethernet / PD) PoE Power Supply Type End-Span Per Port 48V DC, 350mA. Max. 15.4 PoE Power Output watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Maintenance Browser or Utility Camera live view, video recording, change video quality, bandwidth...
  • Page 661 Specifications: PTZ Camera Application GV-Backup Center, GV-NVR, Network Storage GV-Recording Server, GV-System, GV-VMS GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV- CMS Server support Vital Sign Monitor Note: GV-Backup Center and GV-Recording Server are only supported in V1.08 or later.

  • Page 662: Specifications: Pt Camera

    Specifications: PT Camera Camera Image Sensor 1/2.5" progressive scan CMOS GV-PT130D 1280 (H) x 1024 (V) Picture 1920 (H) x 1080 (V) GV-PT220D Elements GV-PT320D 2048 (H) x 1536 (V) Color 0.15 Lux Minimum 0.10 Lux Illumination IR ON 0 Lux Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance...
  • Page 663 Specifications: PT Camera GV-PT130D 49° Horizontal GV-PT220D 58° GV-PT320D 62° Focus Manual (w/lock) Zoom Fixed Operation Iris Fixed IR LED Quantity 10 IR LEDs Max. IR Distance 15 m (50 ft) Operation Video Compression H.264, MJPEG Video Stream Dual streams 1280 x 960, 640 x 480, 320 x 240 Main...
  • Page 664 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 16:9 Stream 640 x 360, 448 x 252 1280 x 1024, 640 x 512, GV-PT220D 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252 Stream 640 x 512, 320 x 256...
  • Page 665 Specifications: PT Camera Sensor Input 1 Input (Dry Contact) Alarm Output 1 Output (200mA 5V DC) Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, Protocol ONVIF (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA...
  • Page 666 General 0°C ~ 50°C (32°F ~ 122°F) Environment Temperature 10% to 90% (no condensation) Humidity 12V DC / 24V AC / PoE Power Source Max. Power Consumption 12.5 W (max. 1.25A at 12V DC) 167.75 x 166.78 x 135.2 mm With mounting base and cover (6.6”...
  • Page 667 Specifications: PT Camera Bulgarian / Czech / Danish / Dutch / English / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Language Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Thai / Traditional Chinese / Turkish...

  • Page 668: Specifications: Vandal Proof Ip Dome (Part 1)

    Specifications: Vandal Proof IP Dome (Part 1) This section details the specifications on GV-VD120D / 121D / 122D / 123D, GV-VD220D / 221D / 222D / 223D, GV-VD320D / 321D / 322D / 323D and GV-VD1500 / 2400 / 2500 / 3400. Camera GV-VD120D GV-VD121D...
  • Page 669 Specifications: Vandal Proof IP Dome (Part 1) GV-VD120D GV-VD121D GV-VD122D 1280 (H) x 1024 (V) GV-VD123D GV-VD1500 GV-VD220D GV-VD221D Picture GV-VD222D 1920 (H) x 1080 (V) Elements GV-VD223D GV-VD2400 GV-VD2500 GV-VD320D GV-VD321D GV-VD322D 2048 (H) x 1536 (V) GV-VD323D GV-VD3400 GV-VD120D Color 0.05 Lux...
  • Page 670 GV-VD220D Color 0.15 Lux GV-VD221D 0.10 Lux GV-VD222D GV-VD223D GV-VD320D IR ON 0 Lux Minimum GV-VD321D Illumination GV-VD322D GV-VD323D Color 0.08 Lux GV-VD2400 0.05 Lux GV-VD3400 IR ON 0 Lux Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic...
  • Page 671 Specifications: Vandal Proof IP Dome (Part 1) GV-VD2400 S/N Ratio 47 dB GV-VD3400 GV-VD2400 WDR Pro GV-VD3400 GV-VD120D GV-VD121D GV-VD122D GV-VD123D GV-VD1500 GV-VD220D GV-VD221D Up to 72 dB GV-VD222D Dynamic Range GV-VD223D GV-VD2500 GV-VD320D GV-VD321D GV-VD322D GV-VD323D GV-VD2400 Up to 100 dB GV-VD3400 Lens Megapixel...
  • Page 672 GV-VD120D GV-VD121D GV-VD122D GV-VD123D GV-VD220D GV-VD221D F/1.3 GV-VD222D GV-VD223D Maximum GV-VD320D Aperture GV-VD321D GV-VD322D GV-VD323D GV-VD1500 GV-VD2400 F/1.2 GV-VD2500 GV-VD3400 Mount ø 14 mm GV-VD120D GV-VD121D GV-VD122D GV-VD123D GV-VD1500 GV-VD220D Image GV-VD221D 1/3’’ Format GV-VD222D GV-VD223D GV-VD320D GV-VD321D GV-VD322D GV-VD323D...
  • Page 673 Specifications: Vandal Proof IP Dome (Part 1) GV-VD2400 Image GV-VD2500 1/2.7’’ Format GV-VD3400 GV-VD120D 86° ~ 32° GV-VD220D 82° ~ 30° GV-VD320D 86° ~ 31° Horizontal GV-VD1500 90° ~ 32° GV-VD2400 82° ~ 30° GV-VD2500 103° ~ 36° GV-VD3400 86° ~ 31° Focus Manual (w/lock) Operation...
  • Page 674 GV-VD1500 15 m (50 ft) GV-VD2400 GV-VD3400 Max. IR GV-VD1500 Distance GV-VD2400 30 m (98.4 ft) GV-VD2500 GV-VD3400 Max. Torque 0.049 N.m (Focus / Zoom Screws) Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-VD120D GV-VD121D GV-VD122D 30 fps at 1280 x 1024...
  • Page 675 Specifications: Vandal Proof IP Dome (Part 1) GV-VD320D GV-VD321D Frame GV-VD322D 20 fps at 2048 x 1536 Rate GV-VD323D GV-VD3400 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Backlight Image Setting Compensation, D/N Sensitivity, Shutter Speed, WDR, Defog, Super Low Lux, Denoise, Metering Audio Compression G.711, AAC (Optional)
  • Page 676 640 x 512, 320 x 256 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 GV-VD220D 1920 x 1080, 1280 x 720, Main Stream 16:9 GV-VD221D 640 x 360, 448 x 252 GV-VD222D 1280 x 1024, 640 x 512, GV-VD223D 320 x 256 GV-VD2400...
  • Page 677 Specifications: Vandal Proof IP Dome (Part 1) Mechanical 0° ~ 350° Camera Angle Tilt 10° ~ 90° Adjustment Rotate 0° ~ 340° Temperature Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable Connectors 1 In (RCA female for microphone) Audio 1 Out (RCA female for speaker) Digital I/O...
  • Page 678 Camera Body ø165 x 125 mm (6.49” x 4.92’’) Cable Length 1 m (3.28 ft) Dimensions Cable Diameter ø16.7 mm (0.66’’) Max. Connector ø16.7 mm (0.66’’) Diameter Weight 1.7 kg (3.75 lb) Ingress Protection IP67 GV-VD120D GV-VD121D GV-VD1500 GV-VD220D GV-VD221D IK10+ GV-VD320D GV-VD321D...
  • Page 679 Specifications: Vandal Proof IP Dome (Part 1) Power over Ethernet PoE (IEEE 802.3af Power over Ethernet PoE Standard / PD) PoE Power Supply Type End-Span Per Port 48V DC, 350mA. Max. 15.4 PoE Power Output watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Maintenance...
  • Page 680 Application GV-Backup Center, GV-NVR, Network Storage GV-Recording Server, GV-System, GV-VMS GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV- CMS Server support Vital Sign Monitor Note: GV-Backup Center, GV-Video Gateway and GV-Recording Server are only supported for V1.03 or later.

  • Page 681: Specifications: Vandal Proof Ip Dome (Part 2)

    Specifications: Vandal Proof IP Dome (Part 2) Specifications: Vandal Proof IP Dome (Part 2) This section details the specifications on GV-VD1530 / 1540 / 1540-E / 2430 / 2440 / 2440-E / 2530 / 2540 / 2540-E / 3430 / 3440 / 3440-E / 5340 / 5340-E.
  • Page 682 GV-VD2430 GV-VD2440 GV-VD2530 1920 (H) x 1080 (V) GV-VD2540 Picture GV-VD2540-E Elements GV-VD3430 2048 (H) x 1536 (V) GV-VD3440 GV-VD5340 2560 (H) x 1920 (V) GV-VD5340-E Color 0.01 Lux GV-VD1530 0.01 Lux GV-VD1540 IR ON 0 Lux Color 0.08 Lux GV-VD2430 0.05 Lux GV-VD2440...
  • Page 683 Specifications: Vandal Proof IP Dome (Part 2) White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic GV-VD1530 55 dB GV-VD1540 GV-VD2430 GV-VD2440 47 dB GV-VD3430 GV-VD3440 S/N Ratio GV-VD2530 GV-VD2540 52 dB GV-VD2540-E GV-VD5340 45 dB GV-VD5340-E GV-VD2430 GV-VD2440 WDR Pro Yes (with WDR sensor) GV-VD3430...
  • Page 684 GV-VD2430 GV-VD2440 Dynamic Up to 100 dB Range GV-VD3430 GV-VD3440 Lens Megapixel Day/Night Yes (with removable IR-cut filter) GV-VD1530 GV-VD2430 Varifocal lens GV-VD2530 GV-VD3430 GV-VD1540 Lens Type GV-VD2440 GV-VD2540 GV-VD2540-E Motorized varifocal lens GV-VD3440 GV-VD5340 GV-VD5340-E GV-VD1530 GV-VD2430 GV-VD2530 GV-VD3430 Focal GV-VD1540 3 ~ 9 mm...
  • Page 685 Specifications: Vandal Proof IP Dome (Part 2) GV-VD5340 3.3 ~ 9 mm GV-VD5340-E Maximum Aperture F/1.2 Mount ø 14 mm Image Format 1/2.7’’ GV-VD1530 90° ~ 32° GV-VD1540 GV-VD2430 82° ~ 30° GV-VD2440 GV-VD2530 Horizontal GV-VD2540 103° ~ 36° GV-VD2540-E GV-VD3430 86°...
  • Page 686 GV-VD1530 30 m (98.4 ft) GV-VD1540 GV-VD2430 GV-VD2440 GV-VD3430 20 m (65.6 ft) Max. IR Distance GV-VD3440 GV-VD5340 GV-VD5340-E GV-VD2530 GV-VD2540 25 m (82.0 ft) GV-VD2540-E GV-VD1530 Max. Torque GV-VD2430 0.049 N.m (Focus / Zoom GV-VD2530 Screws) GV-VD3430 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG...
  • Page 687 Specifications: Vandal Proof IP Dome (Part 2) GV-VD3430 20 fps at 2048 x 1536 GV-VD3440 Frame Rate GV-VD5340 10 fps at 2560 x 1920 GV-VD5340-E Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Backlight Image Setting Compensation, D/N Sensitivity, Shutter Speed, WDR, Defog, Super Low Lux, Zoom, Focus Change, Denoise, Metering Audio Compression...
  • Page 688 Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-VD1530 GV-VD1540 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 689 Specifications: Vandal Proof IP Dome (Part 2) 640 x 480, 320 x 240 GV-VD5340 Sub Stream 16:9 640 x 360, 448 x 252 GV-VD5340-E 640 x 512, 320 x 256 Network Interface 10/100 Ethernet DHCP, DynDNS, FTP, HTTP, HTTPS, NTP, ONVIF Protocol (Profile S), PSIA, QoS (DSCP), RTSP, SNMP, SMTP, TCP, UDP, UPnP, 3GPP/ISMA...
  • Page 690 Note: SDXC and UHS-I card types are not supported. The TV-Out function only works in 640 x 480 resolution. For TV-Out to work properly, you must set the video resolution to 1280 x 1024 or lower. If both streams are enabled, the Sub Stream must be set to 640 x 480.
  • Page 691 Specifications: Vandal Proof IP Dome (Part 2) GV-VD1530 GV-VD2430 15.4 W GV-VD2530 GV-VD3430 GV-VD1540 Max. Power Consumption GV-VD2440 GV-VD2540 22.48 W GV-VD3440 GV-VD5340 GV-VD5340-E 30 W Dimensions ø176.5 x 118 mm (6.9” x 4.6’’) GV-VD1530 GV-VD2430 1.76 kg (3.88 lb) GV-VD2530 GV-VD3430 GV-VD1540...
  • Page 692 Power over Ethernet PoE+ (IEEE 802.3at Power over Ethernet / PoE Standard PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 600 mA. Max. 30 watts Web Interface Installation Web-based configuration Management Maintenance Firmware upgrade through Web Browser or Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O Access from Web...
  • Page 693 Specifications: Vandal Proof IP Dome (Part 2) Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV- CMS Server support Vital Sign Monitor All specifications are subject to change without prior notice.

  • Page 694: Specifications: Fixed Ip Dome (Part 1)

    Specifications: Fixed IP Dome (Part 1) This section details the specifications on GV-FD220D / 320D. Camera Image Sensor 1/2.5’’ progressive scan CMOS GV-FD220D 1920 (H) x 1080 (V) Picture Elements GV-FD320D 2048 (H) x 1536 (V) Color 0.15 Lux Minimum GV-FD220D 0.10 Lux Illumination...
  • Page 695 Specifications: Fixed IP Dome (Part 1) Focal Length 3 ~ 9 mm Maximum Aperture F/1.3 ± 5% Mount ø 14 mm Image Format 1/3’’ GV-FD220D 82° ~ 30° Horizontal GV-FD320D 86° ~ 31° Focus Manual (w/lock) Operation Zoom Manual (w/lock) Iris DC drive IR LED Quantity...
  • Page 696 Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). Video Resolution 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 640 x 360, Stream 16:9 448 x 252...
  • Page 697 Specifications: Fixed IP Dome (Part 1) Mechanical 0° ~ 350° Camera Angle Tilt 10° ~ 90° Adjustment Rotate 0° ~ 340° Temperatire Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (microphone phone jack, 3.5 mm / 0.14”) Audio 1 Out (Stereo pohone jack, 3.5 mm / 0.14”) Connectors...
  • Page 698 Vandal Resistance Regulatory CE, FCC, C-Tick, RoHS compliant Power over Ethernet PoE (IEEE 802.3af Power over Ethernet / PoE Standard PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance...
  • Page 699 Specifications: Fixed IP Dome (Part 1) Application GV-Backup Center, GV-NVR, Network Storage GV-Recording Server, GV-System, GV-VMS GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV-Vital CMS Server support Sign Monitor Note: For the GV-Backup Center and GV-Recording Server supported firmware versions, please see Appendix D.

  • Page 700: Specifications: Fixed Ip Dome (Part 2)

    Specifications: Fixed IP Dome (Part 2) This section details the specifications on GV-FD1200 / 1210 / 1500 / 1510 / 2400 / 2410 / 2500 / 2510 / 3400 / 3410 / 5300. Camera GV-FD1200 1/3" progressive scan low lux CMOS GV-FD1210 GV-FD1500 1/3"...
  • Page 701 Specifications: Fixed IP Dome (Part 2) GV-FD3400 2048 (H) x 1536 (V) Picture GV-FD3410 Elements GV-FD5300 2560 (H) x 1920 (V) Color 0.05 GV-FD1200 0.03 Lux GV-FD1210 IR ON 0 Lux Color 0.01 Lux GV-FD1500 0.01 Lux GV-FD1510 IR ON 0 Lux Color 0.02 Lux...
  • Page 702 GV-FD2500 52 dB GV-FD2510 GV-FD2400 S/N Ratio GV-FD2410 47 dB GV-FD3400 GV-FD3410 GV-FD5300 45 dB GV-FD2400 GV-FD2410 WDR Pro GV-FD3400 GV-FD3410 GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 Up to 72 dB GV-FD2500 Dyanmic GV-FD2510 Range GV-FD5300 GV-FD2400 GV-FD2410 Up to 100 dB GV-FD3400 GV-FD3410 Lens...
  • Page 703 Specifications: Fixed IP Dome (Part 2) GV-FD1200 GV-FD1500 GV-FD2400 Varifocal GV-FD2500 GV-FD3400 GV-FD5300 Lens Type GV-FD1210 GV-FD1510 Motorized varifocal GV-FD2410 GV-FD2510 GV-FD3410 GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 3 ~ 9 mm Focal GV-FD2410 Length GV-FD2500 GV-FD2510 GV-FD3400 GV-FD3410 GV-FD5300 4.5 ~ 10 mm...
  • Page 704 GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 F/1.2 Maximum GV-FD2410 Aperture GV-FD2500 GV-FD2510 GV-FD3410 GV-FD3400 GV-FD5300 F/1.6 GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 ø 14 mm GV-FD2410 Mount GV-FD2500 GV-FD2510 GV-FD3400 GV-FD3410 GV-FD5300 CS Mount...
  • Page 705 Specifications: Fixed IP Dome (Part 2) GV-FD1200 GV-FD1210 GV-FD1500 GV-FD1510 GV-FD2400 1/2.7’’ Image GV-FD2410 Format GV-FD2500 GV-FD2510 GV-FD3400 GV-FD3410 GV-FD5300 1/2.5’’ GV-FD1200 86° ~ 32° GV-FD1210 GV-FD1500 90° ~ 32° GV-FD1510 GV-FD2400 82° ~ 30° Horizontal GV-FD2410 GV-FD2500 103° ~ 36° GV-FD2510 GV-FD3400 86°...
  • Page 706 Focus Manual (w/lock) GV-FD1500 Zoom Manual (w/lock) GV-FD2500 DC dirve GV-FD3400 Iris P-Iris (Coming) Focus Auto Focus GV-FD1210 Zoom 3X Optical Zoom GV-FD2410 Iris DC drive Operation Focus Auto Focus GV-FD1510 Zoom 3X Optical Zoom GV-FD2510 DC drive GV-FD3410 Iris P-Iris (Coming) Focus GV-FD5300...
  • Page 707 Specifications: Fixed IP Dome (Part 2) GV-FD1200 GV-FD1500 Max. Torque GV-FD2400 0.049 N.m (Focus / Zoom GV-FD2500 Screws) GV-FD3400 GV-FD5300 Operation Video Compression H.264, MJPEG Video Stream Dual streams from H.264 or MJPEG GV-FD1200 GV-FD1210 30 fps at 1280 x 1024 GV-FD1500 GV-FD1510 GV-FD2400...
  • Page 708 Sensor Input 1 Input (Dry Contact) Alarm Output 1 Output (200mA 5V DC) Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). The super low lux adjustment (Image Settings) is only available for GV-FD1500 / 1510 / 2500 / 2510.
  • Page 709 Specifications: Fixed IP Dome (Part 2) 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, Stream 16:9 640 x 360, 448 x 252 GV-FD3400 1280 x 1024, 640 x 512, 320 x 256 GV-FD3410 640 x 480, 320 x 240 16:9...
  • Page 710 Mechanical 0° ~ 350° Camera Angle Tilt 10° ~ 90° Adjustment Rotate 0° ~ 340° Temperatire Detector Power 2-pin terminal block, PoE Connectors Ethernet Ethernet (10/100 Base-T), RJ-45 cable 1 In (microphone phone jack, 3.5 mm / 0.14”) Audio 1 Out (Stereo pohone jack, 3.5 mm / 0.14”) Digital I/O 3-pin terminal block, pitch 2.5 mm / 0.1”...
  • Page 711 Specifications: Fixed IP Dome (Part 2) Weight 580 g (1.28 lb) Vandal Resistance GV-FD1200 GV-FD1210 GV-FD2400 CE, FCC, C-Tick, RoHS compliant GV-FD2410 GV-FD3400 Regulatory GV-FD3410 GV-FD1500 GV-FD1510 CE, FCC, RCM, RoHS compliant GV-FD2500 GV-FD2510 Power over Ethernet PoE (IEEE 802.3af Power over Ethernet / PoE Standard PoE Power Supply Type End-Span...
  • Page 712 Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian / Japanese / Lithuanian / Norwegian / Persian / Language Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian /...

  • Page 713: Specifications: Cube Camera

    Specifications: Cube Camera Specifications: Cube Camera Camera Image Sensor 1/2.5’’ progressive scan CMOS GV-CB120 1280 (H) x 1024 (V) Picture Elements GV-CB220 1920 (H) x 1080 (V) Color 0.15 Lux Minimum Illumination 0.10 Lux Automatic, Manual (1/5 ~ 1/8000 sec) Shutter Speed White Balance Automatic, Manual (2800 ~ 8500K)
  • Page 714 GV-CB120 67° Horizontal GV-CB220 77° Operation Fixed (Focus / Zoom / Iris) Operation H.264, MJPEG Video Compression Dual streams from H.264 or MJPEG Video Stream GV-CB120 30 fps at 1280 x 1024 Frame Rate GV-CB220 30 fps at 1920 x 1080 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Image Setting...
  • Page 715 Specifications: Cube Camera 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 16:9 640 x 360, 448 x 252 GV-CB220 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 Sub Stream 16:9...
  • Page 716 Regulatory CE, FCC, C-Tick, RoHS compliant IMPORTANT: Be sure to use the GeoVision power adapter to power up the camera. To use your own power cable, make sure you look up the power source value indicated at the camera’s back panel.
  • Page 717 Specifications: Cube Camera Application GV-Backup Center, GV-NVR, Network Storage GV-Recording Server, GV-System, GV-VMS GV-Eye for Android smartphone, tablet, Smart Device Access iPhone, iPod Touch and iPad Live Viewing IE, mobile phone GV-Center V2, GV-Control Center, GV-Vital CMS Server support Sign Monitor Note: GV-Backup Center, GV-Video Gateway and GV-Recording Server are only supported for V1.03 or later.

  • Page 718: Specifications: Advanced Cube Camera

    Specifications: Advanced Cube Camera Camera Image Sensor 1/2.5’’ progressive scan CMOS GV-CA120 1280 (H) x 1024 (V) GV-CAW120 Picture Elements GV-CA220 1920 (H) x 1080 (V) GV-CAW220 Color 0.15 Lux Minimum 0.10 Lux Illumination LED on 0 Lux Automatic, Manual (1/5 ~ 1/8000 sec) Shutter Speed White Balance Automatic, Manual (2800 ~ 8500K)
  • Page 719 Specifications: Advanced Cube Camera Image Format 1/3’’ GV-CA120 67° GV-CAW120 Horizontal GV-CA220 77° GV-CAW220 Operation Fixed (Focus / Zoom / Iris) Operation H.264, MJPEG Video Compression Dual streams from H.264 or MJPEG Video Stream GV-CA120 30 fps at 1280 x 1024 GV-CAW120 Frame Rate GV-CA220...
  • Page 720 Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-CA120 GV-CAW120 640 x 480, 320 x 240 Sub Stream 16:9 640 x 360, 448 x 252...
  • Page 721 Specifications: Advanced Cube Camera Mechanical Temperature Detector Power DC Jack, PoE (only for CA120/CA220) Ethernet Ethernet (10/100 Base-T), RJ-45 cable Connectors Audio Built-in speaker & microphone Micro SD card slot Local Storage (SD/SDHC, version 2.0 only, Class 10) LED Indicator 4 LEDs: Status x 3, LAN / Wi-Fi PIR Sensor Built-in...
  • Page 722 Power over Ethernet PoE (IEEE 802.3af Class 3 Power over PoE Standard Ethernet / PD) PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change...
  • Page 723 Specifications: Advanced Cube Camera GV-Center V2, GV-Control Center, GV-Vital CMS Server Support Sign Monitor All specifications are subject to change without prior notice...

This manual is also suitable for:

Gv-bx130d-1Gv-bx220d-3Gv-bx140dwGv-bx320d-0Gv-bx320d-1Gv-bx520d ... Show all

Table of Contents
