2.5 Connecting the Camera
2.5.1 Wire Definition
The supplied audio and I/O extended cable allows you to connect one
sensor input and alarm output, and one microphone and speaker.
NO.
Wire Color
1.
Red
2.
Yellow
3.
Black
4.
Red RCA
5.
Green RCA
For details on how to enable an installed I/O device, see 4.2 I/O Settings,
GV-IPCam Firmware Manual.
36
Definition
Digital In
Digital Out
Ground
Audio in
Audio out
Figure 2-6
