Quick Start Guide
GV-IP Camera H.264
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
ICH264-QG-AL-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-MFD320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GeoVision GV-MFD320

  • Page 1 Quick Start Guide GV-IP Camera H.264 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. ICH264-QG-AL-EN...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3: Safety Notice

    Safety Notice UL Certification for GV-MFD120 / 130 / 320 The GV-IPCAM H.264 uses a 3.0V CR2032 Lithium battery as the power supply for its internal real-time clock (RTC). The battery should not be replaced unless required! If the battery does need replacing, please observe the following: ...
  • Page 4: Table Of Contents

    Contents Safety Notice .................i Contents ..................ii Introduction ................viii Options ..................xxii Note for Connecting to GV-System / GV-VMS ......xxiv Note for Recording..............xxv Note for GV-BX2600 ..............xxvi Note for Adjusting Focus and Zoom ........xxvii Note for Installing Camera Outdoor ........xxviii Note for Closing the Bullet Camera Cover......xxx Note for Bullet Camera Waterproof ........xxxi Note for USB Storage and WiFi Adapter ......xxxii 1.
  • Page 5 2.3 Installation ................15 2.4 Connecting the Camera............17 3. Target Box Camera ..............18 3.1 Packing List................18 3.2 Overview .................19 3.3 Installation ................20 3.4 Connecting the Camera............22 4. IR Arctic Box Camera ............23 4.1 Packing List................23 4.2 Overview .................25 4.3 Installation ................27 4.4 Connecting the Camera............32 5.
  • Page 6 7. Target Mini Fixed Rugged Dome ..........59 7.1 Packing List................59 7.2 Overview .................61 7.3 Installation ................62 7.4 Connecting the Camera............68 8. Bullet Camera (Part I).............69 8.1 Packing List................69 8.2 Overview .................70 8.3 Installation ................71 8.3.1 Adjusting the Angles ..........73 8.3.2 Adjusting Lens and Inserting a Memory Card .....76 8.3.3 Inserting the Sun-Shield Cover........79 8.4 Connecting the Camera............80 8.4.1 Wire Definition............80...
  • Page 7 11.3 Installation ................109 11.4 Connecting the Camera............112 11.4.1 Wire Definition............112 11.4.2 Power Connection..........113 12. Vandal Proof IP Dome (Part I) ...........114 12.1 Packing List .................114 12.2 Overview ................116 12.3 Installation ................118 12.3.1 Hard-Ceiling Mount ..........119 12.3.2 In-Ceiling Mount .............124 12.4 Connecting the Camera............127 12.4.1 Wire Definition............127 12.4.2 Connecting the Power Cable........129 13.
  • Page 8 15.3.1 Hard-Ceiling Mount ..........167 15.3.2 In-Ceiling Mount .............171 15.3.3 Wall-Surface Mount..........175 15.4 Connecting the Camera............177 16. Target Fixed IP Dome ............178 16.1 Packing List .................178 16.2 Overview ................179 16.3 Installation ................181 16.4 Connecting the Camera............183 17. Cube Camera..............184 17.1 Packing List .................184 17.2 Overview ................185 17.3 Installation ................186 17.4 Connecting the Camera............188...
  • Page 9 20.4 Connecting the Camera............213 21. Accessing the Camera............214 21.1 System Requirement ............214 21.2 Accessing the Live View ............215 21.2.1 Checking the Dynamic IP Address ......216 21.2.2 Configuring the IP Address........218 21.2.3 Configuring the Wireless Connection......220 21.3 Adjusting Image Clarity............224 21.3.1 Using Focus Adjustment Cap .........227 22.
  • Page 10 Pinhole Camera ..............247 viii...
  • Page 11: Introduction

    Introduction Welcome to the GV-IPCam H.264 Quick Start Guide. In this quick guide, you will find information on the installation and basic configurations of the GV-IPCam H.264 series. Camera Model No. Lens Description GV-BX120D Varifocal 1.3 MP, Low Lux, Auto Iris GV-BX130D-0 Varifocal 1.3 MP, Auto Iris...
  • Page 12 Camera Model No. Lens Description GV-BX320D-0 3 MP, Auto Iris GV-BX320D-1 Varifocal GV-BX520D 5 MP, Manual Iris GV-BX1200-0F 1.3 MP Low Lux / 1.3 MP, D/N, Fixed Iris GV-BX1300-0F GV-BX1200-1F 1.3 MP Low Lux / 1.3 MP / GV-BX1300-1F 1.3 MP Super Low Lux / 2 MP WDR Pro / 2 MP Super GV-BX1500-1F Fixed...
  • Page 13 Camera Model No. Lens Description GV-BX2400-2F 2 MP / 3 MP, WDR Pro, Fixed Iris GV-BX3400-2F GV-BX1200-3V 1.3 MP Low Lux / 1.3 MP / GV-BX1300-3V 1.3 MP Super Low Lux / 2 MP Super Low Lux, Auto GV-BX1500-3V Varifocal Iris GV-BX2500-3V 2 MP, Super Low Lux,...
  • Page 14 Camera Model No. Lens Description 1.3 MP, Low Lux, Fixed GV-EBX1100-0F Iris Target Fixed Camera 1.3 MP, Low Lux, Fixed GV-EBX1100-2F Iris GV-UBX1301-0F GV-UBX1301-1F 1.3 MP, Fixed Iris GV-UBX1301-2F GV-UBX2301-0F Ultra Box Fixed GV-UBX2301-1F 2 MP, Fixed Iris Camera GV-UBX2301-2F GV-UBX3301-0F GV-UBX3301-1F 3 MP, D/N, Fixed Iris...
  • Page 15 Camera Model No. Lens Description 1.3 MP, Low Lux, Auto GV-BX120D-E Iris Varifocal GV-BX220D-E 2 MP, Auto Iris GV-BX320D-E 3 MP, Auto Iris GV-BX520D-E 5 MP, Manual Iris IR Arctic 1.3 MP, Super Low Lux, GV-BX1500-E Auto Iris Camera GV-BX2400-E 2 MP / 3 MP, WDR Pro, Auto Iris GV-BX3400-E...
  • Page 16 Fixed Iris GV-MDR5300-2F 1.3 MP Low Lux, Color, Fixed GV-MFD120 Iris GV-MFD130 1.3 MP / 3 MP, Color, Fixed Iris GV-MFD320 GV-MFD1501-0F Mini 1.3 MP Super Low Lux / 2 MP GV-MFD2401-0F Fixed WDR Pro / 2 MP Super Low Fixed...
  • Page 17 Camera Model No. Lens Description GV-MFD1501-2F 1.3 MP Super Low Lux / 2 GV-MFD2401-2F MP WDR Pro / 2 MP Super GV-MFD2501-2F Low Lux / 3 MP WDR Pro / 5 GV-MFD3401-2F MP, Color, Fixed Iris GV-MFD5301-2F GV-MFD1501-3F 1.3 MP Super Low Lux / 2 GV-MFD2401-3F MP WDR Pro / 2 MP Super GV-MFD2501-3F...
  • Page 18 Camera Model No. Lens Description Target GV-EDR1100-0F 1.3 MP Low Lux / 2 MP Mini Low Lux, Fixed Iris GV-EDR2100-0F Fixed Fixed GV-EDR1100-2F 1.3 MP Low Lux / 2 MP Rugged Low Lux, Fixed Iris GV-EDR2100-2F Dome GV-BL120D GV-BL130D 1.3 MP Low Lux / 1.3 MP / 2 MP / 3 MP, Auto Iris GV-BL220D GV-BL320D...
  • Page 19 Camera Model No. Lens Description Motorized 5 MP, D/N, Auto Iris, 2X GV-BL5310 Varifocal Optical Zoom GV-BL1501 1.3 MP Super Low Lux / 2 Varifocal MP Super Low Lux / 3 MP GV-BL2501 WDR Pro, P-Iris GV-BL3401 Bullet 1.3 MP Super Low Lux / 2 GV-BL1511 Camera MP Super Low Lux / 3 MP...
  • Page 20 Camera Model No. Lens Description GV-EBL1100-1F 1.3 MP / 2 MP, Low Lux, Target Fixed Iris GV-EBL2100-1F Bullet Fixed GV-EBL1100-2F Camera 1.3 MP Low Lux, Fixed Iris GV-EBL2100-2F GV-UBL1211 1.3 MP Low Lux / 1.3 MP GV-UBL1511 Super Low Lux / 2 MP Motorized GV-UBL2411 WDR Pro / 2 MP Super...
  • Page 21 Camera Model No. Lens Description 3 MP, Fixed Iris, WDR GV-UBL3401-0F Ultra Bullet Fixed GV-UBL3401-1F 3 MP, Fixed Iris, WDR Camera GV-UBL3401-2F GV-UBL3401-3F GV-FD220D 2 MP / 3 MP, Auto Iris GV-FD320D GV-FD1200 1.3 MP Low Lux / 2 MP WDR Pro, Auto Iris GV-FD2400 Varifocal...
  • Page 22 Camera Model No. Lens Description 1.3 MP Super Low Lux / 2 GV-FD1510 MP Super Low Lux / 3 MP Fixed IP Motorized GV-FD2510 Dome Varifocal WDR Pro, Auto Iris, 3x GV-FD3410 Optical Zoom GV-FD1500 1.3 MP Super Low Lux / 2 GV-FD2500 Varifocal MP Super Low Lux / 3 MP...
  • Page 23 Camera Model No. Lens Description GV-VD120D (IK10+, Transparent Cover) GV-VD121D 1.3 MP, Low Lux, (IK10+, Smoked Cover) Auto Iris GV-VD122D (IK7, Transparent Cover) GV-VD123D (IK7, Smoked Cover) GV-VD220D (IK10+, Transparent Cover) GV-VD221D (IK10+, Smoked Cover) 2 MP, Auto Iris GV-VD222D (IK7, Transparent Cover) GV-VD223D Vandal...
  • Page 24 Camera Model No. Lens Description GV-VD1530 1.3 MP Super Low Lux / 2 High Power IR GV-VD2430 MP WDR Pro / 2 MP LEDs, Super Low Lux / 3 MP GV-VD2530 Varifocal WDR Pro, Auto Iris GV-VD3430 1.3 MP Super Low Lux / 2 GV-VD1540 MP WDR Pro / 2 MP GV-VD2440...
  • Page 25: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Accessory Description The power adapter is available for all GV-IP Camera (except for IR Arctic Cameras, Mini Fixed Rugged Power Adapter Dome and GV-BL2510-E / 5310-E). Contact your sales representative for the countries and areas supported.
  • Page 26 Accessory Description The GV-WiFi Adapter is a plug-and-play device designed to connect GV-BX1200 Series / 1300 series / 1500 series / 2400 series / 2500 series / 3400 series / 5300 series and GV-MFD1501 series / GV-WiFi Adapter 2401 series / 2501 series / 3401 series / 5301 series to wireless network.
  • Page 27: Note For Connecting To Gv-System / Gv-Vms

    Note for Connecting to GV-System / GV-VMS The GV-IPCAM H.264 is designed to work with GV-System / GV-VMS, a hybrid or digital video management system. Note the following when GV-IPCAM H.264 is connected to GV-System / GV-VMS: By default, the images are recorded to the memory card inserted to the GV-IP Camera H.264 (except GV-IR Arctic Camera and Target Series, which are not equipped with a memory card slot).
  • Page 28: Note For Recording

    Note for Recording By default, the images are recorded to the memory card inserted to the GV-IP Camera H.264 (except GV-IR Arctic Camera and Target Series, which are not equipped with a memory card slot). Make sure the Write recording data into local storage option is enabled. If this option is disabled, the camera will stop recording to the memory card while the live view is accessed through Web browsers or other applications.
  • Page 29: Note For Gv-Bx2600

    For the users of Microsoft Internet Explorer, version 11 or later is required to perform the GV-IPCAM H.264 operations through Web browser. Recording When GV-BX2600 uses Micro SD card or USB HDD for recording, the camera must not have more than one connection to GeoVision or third-party software. xxvii...
  • Page 30: Note For Adjusting Focus And Zoom

    Note for Adjusting Focus and Zoom When adjusting the Focus and Zoom Screws (on Box Camera, IR Arctic Box Camera, Mini Fixed Dome, Bullet Camera, Vandal Proof IP Dome and Fixed IP Dome), please do not over tighten the Focus and Zoom screws. The screws only need to be as tight as your finger can do it;...
  • Page 31: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera, Bullet Camera, Ultra Bullet Camera, Target Bullet Camera, Vandal Proof IP Dome, Mini Fixed Rugged Dome or Target Mini Fixed Rugged Dome outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables.
  • Page 32 After opening the camera cover, ensure the screws are tightened and the cover is in place. The silica gel bag loses it effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.
  • Page 33: Note For Closing The Bullet Camera Cover

    Note for Closing the Bullet Camera Cover To ensure that the camera performs its full capacity against water and dust, tightly close and lock the camera cover as indicated below. xxxi...
  • Page 34: Note For Bullet Camera Waterproof

    Note for Bullet Camera Waterproof To avoid waterproofing failures, do not open the screw on the camera body. The screw on Ultra Bullet Camera The screw on Target Bullet Camera xxxii...
  • Page 35: Note For Usb Storage And Wifi Adapter

    Note for USB Storage and WiFi Adapter Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter: The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above. The USB hard drive’s storage capacity must not exceed 2TB. USB flash drives and USB hubs are not supported.
  • Page 36: Box Camera

    Box Camera 1. Box Camera 1.1 Packing List  Box Camera  Terminal Block  Fixed Focal or Varifocal Megapixel Lens  Six Lens Rings  One Lens Ring (for GV-BX140DW only)  Video Out Wire  Camera Holder  Power Adapter ...
  • Page 37: Overview

    1.2 Overview GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D 12 13 Note: The Auto Iris Connector (No. 7) is only functional in GV-BX120D, GV-BX130D-0, GV-BX220D and GV-BX320D. The Light Sensor (No. 11) is only available in GV-BX140DW. Keep the Light sensor unobscured for accurate light detection.
  • Page 38 Box Camera Name Description Connects I/O devices. For details, see I/O Terminal Block, Box Camera Chapter, I/O Terminal Block GV-IPCAM H.264 Hardware Manual on the Software DVD. Indicates the power is supplied. For detail, Power LED see the table below. Auto Iris Plug the iris control cable to the connector.
  • Page 39: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series / 12201

    GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series / 12201 GV-BX1200 Series / 1300 Series / GV-BX12201 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series...
  • Page 40 Box Camera Note: The Auto Iris Connector (No. 8) is only functional for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 2600 / 3400. The Iris Screw (No. 12) is only available for GV-BX5300-6V. The Zoom Screw (No. 13) is only available for varifocal models of GV-BX1200 / 1300 / 1500 / 2400 / 2500 / 2600 / 3400 / 5300 / 12201 Built-in microphone is not available for GV-BX2600.
  • Page 41 Name Description DC 12V Port Connects to power. LAN / PoE Connects to a 10/100 Ethernet or PoE. Resets all configurations of the GV-IPCAM H.264 to the default factory settings. See 24. Default Restoring to Default Settings later in the Quick Start Guide.
  • Page 42: Accessory Installation

    Box Camera 1.3 Accessory Installation 1.3.1 C-Mount Lenses When you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then attach the lens onto the camera body.
  • Page 43: Infrared Illuminators (Optional)

    1.3.2 Infrared Illuminators (Optional) Connect the infrared illuminator to the terminal block on the camera. See I/O Terminal Block, Box Camera Chapter, GV-IPCAM H.264 Hardware Manual on the Software DVD. Access the Web interface of the camera. Select Video and Motion, select Video Settings, select Streaming 1 and set the IR Check Function setting to Trigger by Input.
  • Page 44: Connecting The Camera

    Box Camera 1.4 Connecting the Camera The Box Camera is designed for indoor use. Please make sure the installing site is shielded from rain and moisture. GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 45 Optionally connect to input / output devices or an infrared illuminator. For details, see Infrared Illuminator and I/O Terminal Block, Box Camera Chapter, GV-IPCAM H.264 Hardware Manual on the Software DVD. Connect power using one of the following methods:  Plug the power adapter to the power port.
  • Page 46: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series/ 12201

    Box Camera GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series/ 12201 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 47 Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See TV Out setting, in the Video Settings section, Administrator Mode Chapter, GV-IPCAM H.264 Firmware Manual on the Software DVD.
  • Page 48: Ultra Box Camera

    Ultra Box Camera 2. Ultra Box Camera 2.1 Packing List  Ultra Box Camera  Supporting rack  Screw x 3  Screw anchor x 3  Power Adapter  GV-IPCAM H.264 Software DVD  GV-NVR Software DVD  Warranty Card Note: The power adapter can be excluded upon request.
  • Page 49: Overview

    2.2 Overview Name Description Audio Out Connects a speaker for audio output. Resets the camera to factory defaults. See 24 Default Restoring to Factory Default Settings in the Quick Start Guide. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds.
  • Page 50: Installation

    Ultra Box Camera 2.3 Installation You can stand the Ultra Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Ultra Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 51 Connect the network and power cables to the camera. See 2.4 Connecting the Camera in the Quick Start Guide. Access the live view. See 21.2 Accessing the Live View in the Quick Start Guide. Adjust the angle of the camera based on live view and fasten the indicated screw.
  • Page 52: Connecting The Camera

    Ultra Box Camera 2.4 Connecting the Camera Connect power using one of the following methods:  Plug the power adapter to the 5V terminal block.  Use the Power over Ethernet (PoE) function and the power will be provided over the network cable. The power and status LEDs shall turn on (green).
  • Page 53: Target Box Camera

    3. Target Box Camera 3.1 Packing List  Target Box Camera  Supporting Rack  Screw x 3  Screw Anchor x 3  GV-IPCAM H.264 Software DVD  GV-NVR Software DVD  Warranty Card Note: Power adapter can be purchased upon request.
  • Page 54: Overview

    Target Box Camera 3.2 Overview Name Description Resets the camera to factory defaults. See 24 Default Restoring to Factory Default Settings in the Quick Start Guide. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. DC 12V Connects to power.
  • Page 55: Installation

    3.3 Installation You can stand the Target Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Target Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 56 Target Box Camera Connect the network and power cables to the camera. See 3.4 Connecting the Camera in the Quick Start Guide. Access the live view. See 21.2 Accessing the Live View in the Quick Start Guide. Adjust the angle of the camera based on live view and fasten the indicated screw.
  • Page 57: Connecting The Camera

    3.4 Connecting the Camera Connect power using one of the following methods:  Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the GV-IPCAM H.264 Hardware Manual for Target Box Camera on the Software DVD.
  • Page 58: Ir Arctic Box Camera

    IR Arctic Box Camera 4. IR Arctic Box Camera 4.1 Packing List For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E  IR Arctic Box Camera  Screw Anchor x 4  Screw x 4 ...
  • Page 59 For GV-BX2510-E / 5310-E  IR Arctic Box Camera  Screw Anchor x 4  Screw x 4  Washer x 4  5 mm Torx Wrench  Silica Gel Bag  Adhesive Tape  Power Adapter (DC 48V, 2.5A, 120 W max.) ...
  • Page 60: Overview

    IR Arctic Box Camera 4.2 Overview For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E Note: The Iris Screw (no. 7) is only available in GV-BX520D-E / 5300-E. Name Description Silica gel bag Desiccant that keeps the camera housing dry.
  • Page 61 For GV-BX2510-E / 5310-E Name Description Silica gel bag Desiccant that keeps the camera housing dry. Memory Card Inserts a micro SD card (SD/SDHC, version Slot 2.0, Class 10) to store recording data. Turns on when the camera is supplied with Power LED power.
  • Page 62: Installation

    IR Arctic Box Camera 4.3 Installation The IR Arctic Box Camera is designed for outdoor use. Follow the steps below to install your camera. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, you must replace the silica gel bag every time you open the camera and conceal the silica gel bag in the camera within 2 minutes of exposing to open air.
  • Page 63 Based on the live view, adjust the angle of the camera. Loosen the indicated screw with the supplied big torx wrench and adjust the joint. Tilt Adjustment Pan Adjustment...
  • Page 64 IR Arctic Box Camera For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E, adjust for image clarity based on the live view. A. Unscrew the cover with the supplied 4 mm torx wrench. B.
  • Page 65 C. Adjust the focus, zoom and iris screws. For a more precise focus, use GV-IP Device Utility. For details, see 21.3 Adjusting Image Clarity in the Quick Start Guide. Note: Only GV-BX520D-E and GV-BX5300-E contain an iris screw. D. Replace the silica gel bag. Paste the sticker to the front side of the silica gel bag.
  • Page 66 IR Arctic Box Camera For GV-BX2510-E / 5310-E, optionally insert a memory card. A. Open the camera cover using the supplied torx wrench. B. Insert a memory card to the card slot. Memory card slot C. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the silica gel bag several times onto the camera cover to make sure it adheres properly.
  • Page 67: Connecting The Camera

    4.4 Connecting the Camera For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 5300-E Wire Definition RJ-45 Black BNC TV ou Green RCA Audio Out Pink RCA Audio In Foll ow t he steps bel ow to connect t he camera: Optionally connect a speaker (green) and a...
  • Page 68 IR Arctic Box Camera Connect the camera to a GV-PA481 PoE adapter as illustrated to supply power and network access. POWER & DATA OUT DATA IN Rear Panel Ethernet Cable Power Hub/Router GV-BX-E The status LED of the camera will be on. You are ready to access the live view.
  • Page 69 For GV-BX2510-E / 5310-E Wire Definition Green RCA Audio Out Pink RCA Audio In Brown wire Digital Output Yellow wire Digital Input White wire Terminal Block DC 48V TV Out RJ-45 Ethernet/PoE++ 1. Optionally connect the audio out (green), audio in (pink), digital output (brown), digital input (yellow), and GND.
  • Page 70 IR Arctic Box Camera 3. Supply the camera with power and network access using one of the following methods:  Use a GV-PA482 Power over Ethernet adapter to connect the camera to power and network as illustrated below. GV-PA482 PoE adapter is an optional accessory.
  • Page 71: Mini Fixed Dome & Mini Fixed Rugged Dome

    5. Mini Fixed Dome & Mini Fixed Rugged Dome 5.1 Packing List GV-MFD  Mini Fixed Dome  Torx Wrench  Self Tapping Screw x 2  Screw Anchor x 2  Cable stopper  2-pin terminal block (for GV-MFD120 / 130 / 320) ...
  • Page 72 Mini Fixed & Rugged Dome GV-MDR  Mini Fixed Rugged Dome  Torx Wrench  Self Tapping Screw x 2  Screw Anchor x 2  Cable stopper  Cable Connector  Installation sticker  Silica gel bag x 2 ...
  • Page 73: Overview

    5.2 Overview GV-MFD120 / 130 / 320 Name Description Resets the camera to factory default. See Default Button 24. Restoring to Default Settings later in the Quick Start Guide. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle. Built-In Microphone Provides one-way audio.
  • Page 74 Mini Fixed & Rugged Dome Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store recording data. LED Indicator LED Name Description 1. Link Turns only when the network is connected. 2. ACT Turns on when data are being transmitted.
  • Page 75: Gv-Mfd1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series

    GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series Name Description Microphone Receives sound. Pan Screw Loosens the screw to pan. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle. Resets the camera to factory default. See Default Button 24.
  • Page 76 Mini Fixed & Rugged Dome LED Name Description 1. Link Turns on (green) when the network is connected. 2. ACT Turns on (orange) when data are being transmitted. 3. Status Turns on (red) when the system is ready. 4. Power Turns on (green) when power is on.
  • Page 77: Gv-Mdr

    GV-MDR Name Description Silica gel bag Absorbs the moisture inside the camera. Prevents water or moisture from entering Conceal paper the camera. Lens Receives image inputs. Rotation Disc Rotates the camera lens. Pan Disc Pans the camera lens. Tilt Screw Loosens to tilt the camera.
  • Page 78 Mini Fixed & Rugged Dome Name Description Turns red when the power is on. Flashes Power and status orange light twice when the system is ready. LAN LED Turns on when the network is connected. Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store recording data.
  • Page 79 Small Waterproof Connector For this connector type, see GV-MDR, 5.3 Installation to install the supplied cable connector.
  • Page 80: Installation

    Mini Fixed & Rugged Dome 5.3 Installation To install a Mini Fixed Dome, make sure the installing site is shielded from rain and moisture. GV-MFD Series Unscrew the housing cover using the supplied torx wrench. Put the camera on the desired location and make 2 marks on the ceiling for screw anchors.
  • Page 81 Tilt Adjustment Insert a memory card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. Memory Card Slot Adjust image clarity using the GV-IP Device Utility program. For details, see 21.3 Adjusting Image Clarity in the Quick Start Guide. 10.
  • Page 82: Gv-Mdr Series

    Mini Fixed & Rugged Dome GV-MDR Series Paste the installation sticker on the desired location. The arrow should point toward the direction that the camera faces. Drill one hole on each of the two curves for screw anchors. Drill the circle (30 mm in diameter) if you want to run the cable into the ceiling.
  • Page 83 Install the cable connector to waterproof the cable. You should have 5 parts: Prepare an Ethernet cable with the RJ-45 connector on one end only. Connect the Ethernet cable to the camera cable. Paste the sticker to the camera cable and slide in all the components as shown below.
  • Page 84 Mini Fixed & Rugged Dome IMPORTANT: Item 5 must be secured tightly to waterproof the cable. Access the live view. See 21.2 Accessing the Live View in the Quick Start Guide. Adjust the angles based on the live view. Pan Adjustment Tilt Adjustment Rotational Adjustment...
  • Page 85 Adjust image clarity using the GV-IP Device Utility program. For details, see 21.3 Adjusting Image Clarity in the Quick Start Guide. 10. Insert a memory card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. 11. Replace the silica gel bag. IMPORTANT: The silica gel bag loses it effectiveness when the dry camera is opened.
  • Page 86: Connecting The Camera

    Mini Fixed & Rugged Dome 5.4 Connecting the Camera Refer to the wire definition and illustrations below to connect the power and network. 5.4.1 Wire Definition GV-MFD120 / 130 / 320 The data cable provides connections for power and network access. The wires are illustrated and defined below: Wire Color Definition...
  • Page 87: Power And Network Connection

    5.4.2 Power and Network Connection Use one of the following methods to power on and connect your camera to network:  Wired connection with PoE: Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.
  • Page 88: Vehicle Installation

    Mini Fixed & Rugged Dome 5.4.3 Vehicle Installation To install the Mini Fixed Rugged Dome on a vehicle, clip the ferrite core to the camera cable. The ferrite core must be attached as close as possible to the camera with the maximum distance of 15 cm. Max.
  • Page 89: Target Mini Fixed Dome

    6. Target Mini Fixed Dome 6.1 Packing List  Target Mini Fixed Dome  Screw x 2  Screw Anchor x 2  Focus Adjustment Clip or Ring  GV-IPCAM H.264 Software DVD  GV-NVR Software DVD  Warranty Card Note: The power adapter can be purchased upon request.
  • Page 90: Overview

    Target Mini Fixed Dome 6.2 Overview Name Description Lens Receives image inputs. Pan Screw Loosens the screw to adjust pan angle. Tilt Screw Loosens the screw to adjust tilt angle. Microphone Receives sound. Default Button Resets the camera to factory default. See 24. Restoring to Factory Default Settings.
  • Page 91: Installation

    6.3 Installation The Target Mini Fixed Dome can be installed on the wall or the ceiling. Before installing the camera, make sure the installing site is shielded from rain and moisture. Open the housing cover by turning. Place the camera where you want to install it and make 2 marks on the ceiling or the wall for screw anchors.
  • Page 92 Target Mini Fixed Dome Thread the power and / or network cable(s) through the oval-shaped hole or the cable opening on the side, and connect the camera to network and power. For details, see 6.4 Connecting the Camera. Secure the Target Mini Fixed Dome to the ceiling or the wall with the self-tapping screws.
  • Page 93: Connecting The Camera

    6.4 Connecting the Camera Connect power using one of the following methods:  Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the GV-IPCAM H.264 Hardware Manual for Target Mini Fixed Dome on the Software DVD.
  • Page 94: Target Mini Fixed Rugged Dome

    Target Mini Fixed Rugged Dome 7. Target Mini Fixed Rugged Dome 7.1 Packing List  Target Mini Fixed Rugged Dome  Screw x 2  Screw Anchor x 2  Focus Adjustment Ring  Installation Sticker  Conduit Converter  RJ-45 Connector ...
  • Page 95 Note: Power adapter can be purchased upon request. You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter with a PG21 conduit connector and a self-prepared conduit pipe (of 1/2’’, 3/4’’...
  • Page 96: Overview

    Target Mini Fixed Rugged Dome 7.2 Overview Name Description Lens Receives image inputs. Pan Screw Loosens the screw to adjust pan angle. Tilt Screw Loosens the screw to adjust tilt angle. Resets the camera to factory default. See 24. Default Button Restoring to Factory Default Settings.
  • Page 97: Installation

    7.3 Installation The Target Mini Fixed Rugged Dome can be installed on the wall or ceiling. You must use the supplied waterproof rubber set to waterproof the cable. Paste the installation sticker where you want to install, and drill two holes that are at a diagonal.
  • Page 98 Target Mini Fixed Rugged Dome Unscrew the three screws as indicated below. A back plate can be separated from the bottom. Use the 2 supplied screws to secure the back plate onto the ceiling or the wall where the screw anchors were inserted. Prepare an Ethernet cable with the RJ-45 connector on one end only.
  • Page 99 Install the supplied waterproof rubber set onto the cable(s). The rubber set has two parts. Item 1 comes in two types. For power cable For network cable For network cable (PoE) Slide the waterproof rubber set, and the waterproof cap you previously removed through the cable(s) as shown below.
  • Page 100 Target Mini Fixed Rugged Dome Fit item 1 to item 2, and insert them in the cable opening. Use the supplied ruler to make sure the length of the cable(s) from the bottom of the opening to the end of the cable is under 10 cm. Cap the cable opening with the waterproof cap.
  • Page 101 Thread the cable(s) under the black cable holder. You can loosen the screw on the cable holder if needed. 10. Connect the camera to network and power. For details, see 7.4 Connecting the Camera. 11. Secure the camera to the back plate by tightening the three screws as shown in Step 4.
  • Page 102 Target Mini Fixed Rugged Dome 15. Attach the silica gel bag to the place indicated below, and secure the housing cover using the torx wrench. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air.
  • Page 103: Connecting The Camera

    7.4 Connecting the Camera Connect power using one of the following methods:  Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options, GV-IPCAM H.264 Hardware Manual for Target Mini Fixed Rugged Dome on the Software DVD.
  • Page 104: Bullet Camera (Part I)

    Bullet Camera (Part I) 8. Bullet Camera (Part I) 8.1 Packing List  Bullet Camera  Self Tapping Screw x 3  Plastic Screw Anchor x 3  Torx Wrench x 2  Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screws x 2, Plastic Screw Spacer x 2 and Hexagon Screw x 2) ...
  • Page 105: Overview

    8.2 Overview Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10). Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. Default Button See 24.
  • Page 106: Installation

    Bullet Camera (Part I) 8.3 Installation The Bullet Camera is designed for outdoor use and can be mounted on ceiling and wall. Slide the cable clamp to the camera base. Cable Clamp Install the Bullet Camera to the wall / ceiling. Remove the protection sticker from the camera’s cover.
  • Page 107 Loosen the camera’s cover, adjust the lens and focus, and insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. See 8.3.2 Adjusting Lens and Inserting a Memory Card in the Quick Start Guide. Fasten the camera’s cover.
  • Page 108: Adjusting The Angles

    Bullet Camera (Part I) 8.3.1 Adjusting the Angles The Bullet Camera is designed to be adjustable in three shafts. Tip: The three shafts are designed to offer easy and flexible ceiling / wall mount installation. First Shaft You can adjust the camera body by 360 degrees to the right or the left. Unscrew the panning lock screw with the torx wrench.
  • Page 109 Second Shaft You can adjust the camera body up and down by 90, 112.5, 135, 157.5 or 180 degrees by using the gears inside the camera body and the camera base. Unscrew the tilting lock screw with the torx wrench. Tilting Lock Screw Torx Wrench Hold the camera body, and move the camera base to the right to...
  • Page 110 Bullet Camera (Part I) Third Shaft You can adjust the camera base by 360 degrees. Unscrew the base fixing screw with the torx wrench. Torx Wrench Base Fixing Screw Adjust the angle of camera base, and fasten the base fixing screw. 0~360°...
  • Page 111: Adjusting Lens And Inserting A Memory Card

    8.3.2 Adjusting Lens and Inserting a Memory Card To adjust the camera’s lens to produce a clear image and insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot, follow the steps below. Loosen the camera’s cover. For GV-BL2510-E / 5310-E, loosen the camera’s cover and the screw as indicated below.
  • Page 112 Bullet Camera (Part I) To insert a memory card, follow the steps below. Loosen the fixing screw. Slightly pull out the camera module. Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory card slot. Memory Card Slot Push the camera module back and fasten the fixing screw.
  • Page 113 Insert a new silica gel bag to the camera module. Silica Gel Bag All Bullet Camera except GV-BL2510-E/5310-E GV-BL2510-E/5310-E IMPORTANT: The silica gel bag loses it effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.
  • Page 114: Inserting The Sun-Shield Cover

    Bullet Camera (Part I) 8.3.3 Inserting the Sun-Shield Cover After setting up the Bullet Camera, now you can install the sun-shield cover to the camera. Fasten the hexagon screws either on top or below the camera. Hexagon Screws Put the sun-shield cover on top of hexagon screws. Make sure to aim the rear hexagon screw at the edge of the sun-shield cover’s aperture for optimal sun-shield performance.
  • Page 115: Connecting The Camera

    8.4 Connecting the Camera Connect your Bullet Camera to power, network and the cables needed. 8.4.1 Wire Definition The cable of the Bullet Camera is illustrated and defined below: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow) Audio In (Red)
  • Page 116 Bullet Camera (Part I) Note that the Audio In and Out connectors may also come as terminal blocks: Digital In (Red) DC 12V+ / AC 24V + (Brown) Digital Out (Orange) DC 12V- / AC 24V - (Black) GND (Yellow) Audio In (Brown) Audio Out (Green) Ethernet (PoE)
  • Page 117: Connecting The Power Cable

    8.4.2 Connecting the Power Cable Use one of the following methods to supply power to the camera. Note that GV-BL2510-E / 5310-E do not support PoE.  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. ...
  • Page 118: Bullet Camera (Part Ii)

    Bullet Camera (Part II) 9. Bullet Camera (Part II) 9.1 Packing List  Bullet Camera  Self Tapping Screw x 3  Plastic Screw Anchor x 3  Torx Wrench x 3  Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screw x 2, Plastic Screw Spacer x 2, and Hexagon Screw x 2) ...
  • Page 119: Overview

    9.2 Overview Twist off the camera cover to access the following: Name Description Receives a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10). Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default.
  • Page 120 Bullet Camera (Part II) To access the following interface, remove the camera base using the supplied torx wrench. Name Description LAN / PoE Connects to a 10/100 Ethernet or PoE. Audio In Connects a microphone for audio input. Audio Out Connects a speaker for audio output.
  • Page 121: Installation

    9.3 Installation Follow the steps below to install the Bullet Camera. Paste the supplied sticker to the ceiling/wall. For wall installations, make sure the arrow on the sticker points toward the ceiling. Drill the shaded area, and insert the screw anchor into the three holes. Loosen the indicated screws with the supplied torx wrench to remove the base.
  • Page 122 Bullet Camera (Part II) Loosen the indicated screws and remove the back plate. Back Plate Align and secure the black plate to the wall/ceiling with the supplied self-tapping screws.
  • Page 123 To use a pipe (optional), install the conduit converter using the supplied M3 screws. IMPORTANT: For GV-BL2511-E / 5311-E connected with a power adapter, only install the conduit converter to the indicated exit. Install the Ethernet cable. A. Twist off and remove the cable seal and the conduit connector.
  • Page 124 Bullet Camera (Part II) B. Thread an Ethernet cable (with no RJ-45 connector on one end) from the back panel through the conduit converter (optionally installed at step 6) and then through the cable seal. IMPORTANT: Use the supplied ruler and leave about 10 cm of the Ethernet cable between the connector and the cable seal.
  • Page 125 C. Optionally thread audio wires, adapter wires, and I/O wires through the conduit converter and then through part 1, 2, 3, and 4 of the conduit connector. Tip: To make the threading easier, it is advised to thread the wires in the order described here.
  • Page 126 Bullet Camera (Part II) IMPORTANT: 1. Use the supplied ruler and leave about 10 cm of audio, power, and I/O wires between their connectors and the cable seal. 2. The plugs are used to prevent water from entering the camera housing.
  • Page 127 12. Access the live view. For details, see 21.2 Accessing the Live View in the Quick Start Guide. 13. Adjust the angles of the camera based on the live view. Three shafts can be adjusted. See 8.3.1 Adjusting the Angles. 14.
  • Page 128: Connecting The Camera

    Bullet Camera (Part II) 9.4 Connecting the Camera Power Connection Use one of the following methods to supply power to the camera. Note that GV-BL2511-E / 5311-E do not support PoE.  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.
  • Page 129 I/O Device Connection The camera supports one digital input and one digital output of dry contact. Function Digital Output Digital Input For details on how to enable an installed I/O device, see I/O Settings, Administrator Mode Chapter, GV-IPCAM H.264 Firmware Manual on the Software DVD.
  • Page 130: Ultra Bullet Camera

    Ultra Bullet Camera 10. Ultra Bullet Camera 10.1 Packing List  Ultra Bullet Camera (with Waterproof or Non-Waterproof LAN connector)  Camera Stand  Black Rubber  Self Tapping Screw x 3  Plastic Screw Anchor x 3  Torx Wrench ...
  • Page 131: Overview

    10.2 Overview Panel Name Description Connects to the data cable. For details, see Power & I/O 10.4 Connecting the Camera in the Quick Start Connector Guide. Resets all configurations to factory default. See Default Button 24. Restoring to Default Settings in the Quick Start Guide.
  • Page 132 Ultra Bullet Camera LAN Connector The Ultra Bullet Camera provides two connector types. Select an option based on your installation environment.  Option 1 (Waterproof) To waterproof the cable, install the supplied cable connector. See 10.4.1 Waterproofing the Cable in the Quick Start Guide. ...
  • Page 133: Installation

    10.3 Installation You can install the camera to the ceiling or wall. Follow the steps below. Optionally insert a micro SD card to the camera. A. Unscrew and open the back panel with the supplied torx wrench. B. Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10) into the card slot and replace the silica gel bag.
  • Page 134 B. Put the sun-shield cover on the top of the camera. For optimal sun-shield performance, make sure the rear hexagon screw is at the end of the opening. Sun-Shield Cover IMPORTANT: The GeoVision logo on the sun-shield cover should be closer to the front of the camera.
  • Page 135 C. Fasten the Philips head screws with the plastic screw spacers to mount the sun-shield cover onto the camera.  Ceiling Mount: Fasten one Philips head screw to the top of the camera.  Wall Mount: Fasten two Philips head screws to the top of the camera.
  • Page 136 Ultra Bullet Camera Use the screw anchors and self-tapping screws to secure the camera to the wall. Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 10.4.1 Waterproofing the Cable and 10.4.2 Connecting the Camera. Access the live view.
  • Page 137: Connecting The Camera

    10.4 Connecting the Camera 10.4.1 Waterproofing the Cable Waterproof the option 1 LAN / PoE cable (see 10.2 Overview) using the supplied cable connector. The cable connector can be dissembled into 5 parts: Cut off the RJ-45 connector on one end of the Ethernet cable. Connect the Ethernet cable to the LAN / PoE connector.
  • Page 138 Ultra Bullet Camera Move all the components toward the LAN / PoE connector, fit item 4 to item 2, secure item 3 to the LAN / PoE connector (Item A) and finally secure item 5 to item 2 tightly. IMPORTANT: Item 5 must be secured tightly to waterproof the LAN / PoE connector.
  • Page 139: Wire Definition

    10.4.2 Wire Definition The supplied 4-pin data cable provides connections for power, ground, 1 sensor input and 1 alarm output. The wires are defined below: Wire Color Definition DC 5V Green Digital In Blue Digital Out Black Ground...
  • Page 140: Power Connection

    Ultra Bullet Camera 10.4.3 Power Connection Connect the camera to power using one of the following methods:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. ...
  • Page 141: Target Bullet Camera

    11. Target Bullet Camera 11.1 Packing List  Target Bullet Camera  Sun-Shield Cover  Silica Gel Tape x 2  Supporting Rack  Screw for supporting rack x 3  Screw Anchor x 3  Screw for sun-shield cover ...
  • Page 142: Overview

    Target Bullet Camera 11.2 Overview Panel Name Description Power Connects to the data cable. For details, see Connector 11.4.1 Connecting the Camera. Resets all configurations to factory default. See Default Button 24. Restoring to Factory Default Settings in the Quick Start Guide.
  • Page 143 IMPORTANT: The silica gel loses its effectiveness when the camera is opened. If you open the camera to access the load default button, replace the silica gel tape by taping the new silica gel tape to the inside of the camera cover. Make sure you conceal the silica gel tape in the camera within two minutes of exposing to the open air.
  • Page 144: Installation

    RJ45 connector. Slide the sun-shield cover onto the top of the camera. Note: The GeoVision logo on the sun-shield cover should be closer to the front of the camera. Line up the screw hole on the camera with the opening on the...
  • Page 145 Ceiling Mount: Secure the supporting rack to the opening on the sun-shield cover Wall Mount: Insert and tighten the supplied screw on the sun-shield cover. Secure the supporting rack to the bottom. IMPORTANT: To avoid waterproofing failures, do not open the screw on the camera body (see Note for Waterproofing Failures).
  • Page 146 Target Bullet Camera Install the camera to the wall or ceiling using the screw anchors and self-tapping screws. You can also stand the camera on a plain surface. Remove the protection sticker from the camera’s cover. Connect the wires and cable connector to the camera. See 11.4 Connecting the Camera in the Quick Start Guide.
  • Page 147: Connecting The Camera

    11.4 Connecting the Camera 11.4.1 Wire Definition The data cable provides connections for power, ground and network access. The wires are defined below: Wire Color Definition DC 12V Black Ground Black (thick) PoE, Ethernet...
  • Page 148: Power Connection

    Target Bullet Camera 11.4.2 Power Connection There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. ...
  • Page 149: Vandal Proof Ip Dome (Part I)

    12. Vandal Proof IP Dome (Part I) The information in this chapter applies to GV-VD120D / 121D / 122D / 123D / 220D / 221D / 222D / 223D / 320D / 321D / 322D / 323D / 1500 / 2400 / 3400.
  • Page 150 Vandal Proof IP Dome (Part I)  GV-IPCam H.264 Software  Power Adapter  GV-NVR Software DVD  Warranty Card Note: 1. Focus Adjustment Cap is only needed and supplied for IK10+ models. 2. The power adapter can be excluded upon request.
  • Page 151: Overview

    12.2 Overview Name Description Turns on (green) when the power is on and Power LED turns off when there is no power supply. Turns on (green) when the system Status LED operates normally and turns off when system error occurs. Resets to factory default.
  • Page 152 Vandal Proof IP Dome (Part I) Name Description Zoom Screw Adjusts the zoom of the camera. Focus Screw Adjusts the focus of the camera. Silica Gel Bag Absorbs moisture in the camera body.
  • Page 153: Installation

    12.3 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, there are two ways to install the Vandal Proof IP Dome: hard-ceiling mount and in-ceiling mount. Note: You can also install the camera:  on a power box (of the 4" square and double gang type) using the standard package ...
  • Page 154: Hard-Ceiling Mount

    Vandal Proof IP Dome (Part I) 12.3.1 Hard-Ceiling Mount Unpack the camera package and take out the camera body. Unscrew the housing cover Unscrew thread lock...
  • Page 155 Unscrew the inner housing Take out the camera body Mark the position of four screw holes on the desired installation location, and drill holes in the marked locations. Drill the ellipse part if you wish to put the wires through it.
  • Page 156 Vandal Proof IP Dome (Part I) Insert the screw anchors to the 4 holes on the ceiling. Secure the back cover to the ceiling with 4 ceiling screws. wall Refer to step 1 to secure the camera body with inner housing. Thread the cable through the conduit entry at the side of the back cover.
  • Page 157 Pan Adjustment Tilt Adjustment Rotational Adjustment...
  • Page 158 Vandal Proof IP Dome (Part I) 10. Hold the focus adjustment cap on top of the camera view and adjust for image clarity using the GV-IP Device Utility program. For details, see 21.3 Adjusting Image Clarity in the Quick Start Guide. Focus Screw Zoom Screw 11.
  • Page 159: In-Ceiling Mount

    12.3.2 In-Ceiling Mount Follow step 1 in the Hard-Ceiling Mount section to remove the housing cover, thread lock and back cover, and take out the camera body. Cut out a circle with a diameter of 142 mm on the ceiling. Insert a blue screw to the indicated holes on the camera body.
  • Page 160 Vandal Proof IP Dome (Part I) Screw in a plastic clip to the blue screw, hold it with one hand and use a screw driver to rotate the blue screw until the plastic clip moves half way down. Plastic Clip Secure a T-cap on top of the blue screw with a small screw cap and a T-cap screw.
  • Page 161 Insert the camera to the ceiling with the plastic screws moved inward. Move the blue screws out and rotate the blue screw with a screw driver until the plastic clip and the bottom of the camera body clamps the ceiling tightly. Connect the network and power cables to the camera.
  • Page 162: Connecting The Camera

    Vandal Proof IP Dome (Part I) 12.4 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other cables. 12.4.1 Wire Definition The cables for Vandal Proof IP Dome are illustrated and defined below. Shielding ground DC 12V- / AC 24V- DC 12V+ / AC 24V+ Digital in (oragne) Digital out (brown)
  • Page 163 Note: To use the TV out function, connect the black BNC connector to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface. For details, see Video Settings, Administrator Mode Chapter, GV-IPCam H.264 Firmware Manual on the Software DVD.
  • Page 164: Connecting The Power Cable

    Vandal Proof IP Dome (Part I) 12.4.2 Connecting the Power Cable There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. ...
  • Page 165: Vandal Proof Ip Dome (Part Ii)

    13. Vandal Proof IP Dome (Part II) The information in this chapter applies to GV-VD1530 / 1540 / 2430 / 2440 / 2530 / 2540 / 2540-E / 3430 / 3440 / 5340 / 5340-E. 13.1 Packing List  Vandal Proof IP Dome ...
  • Page 166 Vandal Proof IP Dome (Part II)  RJ-45 Connector x 2  Back Plate  Installation sticker  Screw Anchor x 4 Ceiling mount template  Long Screw x 4  Flat Screw  Short Screw x 2  Silica Gel Bag ...
  • Page 167  Power Adapter  GV-IPCAM H.264 Software  GV-Vandal Proof IP Dome  GV-NVR Software DVD Hardware Installation Guide  Warranty Card Note: You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter and plastic PG21 conduit connector with a self-prepared 1/2’’...
  • Page 168: Overview

    Vandal Proof IP Dome (Part II) 13.2 Overview...
  • Page 169 Name Description LED Indicators The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED (bottom) turns on (green) when the system operates normally and turns off when system error occurs.
  • Page 170: Installation

    Vandal Proof IP Dome (Part II) 13.3 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: You can also install the camera:  on a power box (of the 4" square and double gang type) using the standard package ...
  • Page 171 B. Unplug the conduit connector inside the housing and disintegrate the connector. You should have 4 parts: C. Remove the terminal block from the power adapter. D. Thread the audio wires (optional), TV out wire (optional), adapter wires and I/O wires (optional) through the conduit entry and then through part 1, 2, 3 and 4 of the conduit connector.
  • Page 172 Vandal Proof IP Dome (Part II) 2.6 mm: Audio, BNC 2 mm: DC12V / AC24V 1.8 mm: DIDO IMPORTANT: 1. Use the supplied ruler and leave about 10 cm of power and I/O wires between their connectors and the cable seal; leave at least 11 cm of audio/TV-out wires between their connectors and the cable seal.
  • Page 173 Install the Ethernet cable. A. Rotate to remove the indicated cap and the plug inside. B. Thread an Ethernet cable (the end with no RJ-45 connector) from the back panel through the cable seal. IMPORTANT: Use the supplied ruler and leave about 11 cm of the Ethernet cable between the connector and the cable seal.
  • Page 174 Vandal Proof IP Dome (Part II) Connect the wires to the camera. Install the terminal blocks to the power adapter and I/O devices. See 13.4 Connecting the Camera in the Quick Start Guide. Install the supplied RJ-45 connector to the Ethernet cable. Plug all the connectors to the camera panel.
  • Page 175 Sort out the wires at the back. You can have the wires come out from position A, B or both. The instructions here describe sorting wires for position A. From the back of the camera housing, unscrew and rotate the plate to one side, sort out the wires and secure the plate back.
  • Page 176 Vandal Proof IP Dome (Part II) Secure the back plate to the ceiling. A. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces. Ceiling mount template B. Drill 3 holes for screws. The recommended ones are indicated as ‘1’.
  • Page 177 Secure the camera to the ceiling. Secure the safety lock to the camera using a short screw. Use flat screw for number 1 and small screw for number 2. Thread all the wires into the ceiling and connect them. Note: To use the TV out function, connect the black BNC connector to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface.
  • Page 178 Vandal Proof IP Dome (Part II) C. Secure the camera using the torx wrench Access the live view. See 21.2 Accessing the Live View in the Quick Start Guide. Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment...
  • Page 179 Tilt Adjustment Rotational Adjustment...
  • Page 180 Vandal Proof IP Dome (Part II) 10. Replace the silica gel bag and secure the camera cover using the torx wrench. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air.
  • Page 181: Connecting The Camera

    13.4 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other wires needed. 13.4.1 Connecting the Power Cable There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.
  • Page 182: Connecting The I/O Device

    Vandal Proof IP Dome (Part II) 13.4.2 Connecting the I/O Device The camera support one digital input and one digital output of dry contact. Function Digital Output Digital Input For details on how to enable an installed I/O device, see I/O Settings, Administrator Mode Chapter, GV-IPCAM H.264 Firmware Manual on the Software DVD.
  • Page 183: Target Vandal Proof Ip Dome

    14. Target Vandal Proof IP Dome 14.1 Packing List  Target Vandal Proof IP  Torx Wrench Dome  Screw x 4  Screw Anchor x 4  TV-Out Wire  Audio Wires x 2  Installation sticker  RJ-45 Connector Ceiling mount template...
  • Page 184 Target Vandal Proof IP Dome  Conduit Converter  Water proof rubber set (for RJ-45 and DC12V)  Big Concave hexagon  Small Concave hexagon Wrench Wrench  Silica Gel Bag  Sticker (for Silica Gel Bag)  GV-IPCAM H.264 Software ...
  • Page 185 Note: Power adapter can be purchased upon request. With the supplied Conduit Converter, you can choose to run the wires through a conduit pipe. The installation of conduit converter and conduit pipe is illustrated as below. You may optionally purchase a plastic or metal PG21 conduit connector for a 1/2”...
  • Page 186: Overview

    Target Vandal Proof IP Dome 14.2 Overview 13 12...
  • Page 187 Name Description The power LED (top) turns on (green) when the power is on and turns off when there is no power supply. The status LED (bottom) LED Indicators turns on (green) when the system operates normally and turns off when system error occurs.
  • Page 188: Installation

    Target Vandal Proof IP Dome 14.3 Installation The Target Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Note: You can also install the camera to ceilings, wall corners (concave or convex), and poles using optional mounting kits.
  • Page 189 Thread an Ethernet cable and/or the adapter wire into the camera. Rotate to remove the indicated cap. B. Take out and disintegrate the connector. You should have 3 parts: C. Thread an Ethernet cable (the end without RJ-45 connector) and/or the adapter wire from the back panel. D.
  • Page 190 Target Vandal Proof IP Dome E. If you are using DC 12V, change the connector to the supplied Waterproof rubber set. Remove the terminal block from the power adapter and thread the adapter wire through the rubber. For adapter wire For Ethernet cable For Ethernet cable (PoE) Thread the Ethernet cable and/or the adapter wire through part 2...
  • Page 191 Thread audio wires (optional) into the camera. Rotate to remove the cap of the conduit connector. Take out and disintegrate the connector. You should have 3 parts too. Thread the audio wires from the back panel, remove the plugs of part 1 and thread through the 3 parts of the connector.
  • Page 192 Target Vandal Proof IP Dome Tip: Use a pair of pliers to help you pull the wires through the camera. IMPORTANT: Use the supplied ruler and leave about 10 cm of the audio wires between the connectors and the cable seal. The plugs are used to prevent water from entering the camera housing.
  • Page 193 Sort out the wires at the back. You can have the wires come out from both positions A and B, or from C. Secure the back plate to the ceiling. Paste the sticker to the ceiling. The arrow on the sticker indicates the direction that the camera faces.
  • Page 194 Target Vandal Proof IP Dome Drill A & B holes or only C hole for sorting out the wires according to Figure 5-11. Secure the back plate to the ceiling with the supplied screws. Secure the camera to the ceiling. Secure the safety lock to the camera with the screw you removed from the back plate in step 2.
  • Page 195 Access the live view. See 21.2 Accessing the Live View in the Quick Start Guide. Note: The TV-out function can only be used during installation to adjust the focus of the camera. To use the TV out function, connect the supplied black BNC wire to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface.
  • Page 196 Target Vandal Proof IP Dome Rotational Adjustment 11. Replace the silica gel bag, press all the wires and cables into the notch and secure the camera cover with the torx wrench. IMPORTANT: The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air.
  • Page 197: Connecting The Camera

    14.4 Connecting the Camera There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.  Plug the power adapter to the terminal block by inserting the striped wire to the right pin (-) and the black wire to the left pin (+).
  • Page 198: Fixed Ip Dome

    Fixed IP Dome 15. Fixed IP Dome 15.1 Packing List 15.1.1 Packing List for Hard-Ceiling Mount  Fixed IP Dome  Torx Wrench  Mounting Plate  Short Screw Anchor x 3  Ceiling Screw x 3  Plate Screw x 3 ...
  • Page 199: Packing List For In-Ceiling Mount

    15.1.2 Packing List for In-Ceiling Mount  In-Ceiling Housing Cover  Mounting Plate  Mounting Bracket x 3  Copper Pillar x 3  Copper Pillar Screw x 6  Bracket Screw x 3  Thread Lock Screw  Housing Cover Thread ...
  • Page 200: Overview

    Fixed IP Dome 15.2 Overview 10 11 12 13 14 15 Name Description Focus Screw Adjusts the focus of the camera. Zoom Screw Adjusts the zoom of the camera. Rotational Screw Loosens to adjust the camera angle. Tilt Screw Loosens the screw to tilt the camera. Pan Disc Loosens to pan the camera.
  • Page 201 Name Description Audio Out Connects a speaker for audio output. LAN / PoE Connects to a 10/100 Ethernet or PoE. Connects to I/O devices. For details, see Fixed IP Dome Chapter in the GV-IPCAM I/O Terminal Block H.264 Firmware Manual on the Software DVD.
  • Page 202: Installation

    Fixed IP Dome 15.3 Installation The Fixed IP Dome is designed for indoors. With the standard packing, there are three ways to install the Fixed IP Dome: hard-ceiling mount, in-ceiling mount and wall-surface mount. Note: You may also install the camera to ceilings, wall corners (concave or convex), and poles using the optional mounting kits.
  • Page 203 Take out the camera body Secure the camera body and the mounting plate to the ceiling with the three ceiling screws. Ceiling mounting plate Connect the network and power cables to the camera. See 14.4 Connecting the Camera in the Quick Start Guide. Access the live view.
  • Page 204 Fixed IP Dome Pan Adjustment Tilt Adjustment Rotational Adjustment...
  • Page 205 Adjust for image clarity using the GV-IP Device Utility program. For details, see 21.3 Adjusting Image Clarity in the Quick Start Guide. Focus Screw Zoom Screw Secure the housing cover as shown in step 2. Remove the indicated part when necessary. Note: Adjust the black mask inside the housing cover to make sure the camera view is not obscured.
  • Page 206: In-Ceiling Mount

    Fixed IP Dome 15.3.2 In-Ceiling Mount Follow step 2 in the Hard-Ceiling Mount section to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the ceiling and cut a circle on the ceiling along the edge of the sticker. On the mounting plate, locate the 3 holes labeled as 1 and insert the 3 copper pillars from the back side.
  • Page 207 Place the 3 mounting brackets at the indent next to the copper pillars (labeled as 2 on the mounting plate) and secure them using the 3 bracket screws. Place the mounting plate on the camera body with the copper pillars inserted in the locations indicated below.
  • Page 208 Fixed IP Dome On the back side, make sure the black plastic clips are slightly above the ceiling board and pointing outward. Back Side Front Side 10. Tighten the bracket screws from the front side of the camera. 11. Connect the network and power cables to the camera. See 15.4 Connecting the Camera in the Quick Start Guide.
  • Page 209 15. Place the housing cover on the camera body with the GeoVision logo pointing toward the front of the camera.
  • Page 210: Wall-Surface Mount

    Fixed IP Dome 15.3.3 Wall-Surface Mount Follow step 2 in the Hard-Ceiling Mount section to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the wall. Drill the three red dots, and the ellipse mark only if you wish to run the wires into the wall.
  • Page 211 Follow steps 6 and 7 in the Hard-Ceiling Mount section to adjust the angle, focus and zoom of the camera. Follow step 8 in the Hard-Ceiling Mount section to secure the housing cover.
  • Page 212: Connecting The Camera

    Fixed IP Dome 15.4 Connecting the Camera Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Optionally connect a monitor using a Video Out wire. Enable the function by selecting the signal format in the TV Out field in the Web interface.
  • Page 213: Target Fixed Ip Dome

    16. Target Fixed IP Dome 16.1 Packing List  Target Fixed IP Dome  Torx Wrench  Screw x 3  Screw Anchor x 3  TV-Out Wire  Installation sticker  GV-IPCam H.264 Software DVD  Warranty Card  GV-NVR Software DVD Note: The power adapter can be purchased upon request.
  • Page 214: Overview

    Target Fixed IP Dome 16.2 Overview Name Description Lens Receives image inputs. Focus Screw Adjusts the focus of the camera. Zoom Screw Adjusts the zoom of the camera. Default Resets the camera to factory default. For details, Button see 24. Restoring to Default Settings. TV-Out Provides video inputs (D1 resolution).
  • Page 215 Name Description Turns on (orange) when data are being transmitted. DC 12V Port Connects to power. LAN / PoE Connects to a 10/100 Ethernet or PoE. Tilt Screw Loosens the screw to adjust tilt angle. Note: The TV-out function can only be used during installation to adjust the focus of the camera.
  • Page 216: Installation

    Target Fixed IP Dome 16.3 Installation The Target Fixed Dome can be installed on the wall or the ceiling. Before installing the camera, make sure the installing site is shielded from rain and moisture. Use the supplied torx wrench to loosen three screws on the housing cover, and take out the camera body.
  • Page 217 Note: The TV-out function can only be used during installation to adjust the focus of the camera. To use the TV out function, connect the supplied black BNC wire to a monitor and select your signal format (NTSC or PAL) at the TV Out field on the Web interface. The default signal format is NTSC.
  • Page 218: Connecting The Camera

    Target Fixed IP Dome 16.4 Connecting the Camera Connect power using one of the following methods:  Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual. ...
  • Page 219: Cube Camera

    17. Cube Camera 17.1 Packing List  Cube Camera  Supporting Rack  Screw x 3  Screw Anchor x 3  GV-IPCam H.264 Software  Power Adapter  GV-NVR Software DVD  Warranty Card Note: The power adapter can be excluded upon request.
  • Page 220: Overview

    Cube Camera 17.2 Overview Name Description Microphone Receives sounds. Speaker Plays sounds. Connects to a 10/100 Ethernet. Turns red when the system powers on. Turns Status LED orange when the system is ready. Turns green when the camera is connected to the LAN LED Internet.
  • Page 221: Installation

    17.3 Installation Follow the steps below to install, connect to and adjust your Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws. Screw the camera onto the supporting rack and fasten the indicated screw.
  • Page 222 Cube Camera Adjust the angles of the camera based on live view and fasten the indicated screw.
  • Page 223: Connecting The Camera

    See 21. Accessing the Camera in the Quick Start Guide. IMPORTANT: Be sure to use the GeoVision power adapter to power up the camera. To use your own power cable, make sure you look up the...
  • Page 224: Advanced Cube Camera

    Advanced Cube Camera 18. Advanced Cube Camera 18.1 Packing List  Cube Camera  Supporting Rack  Screw x 3  Screw Anchor x 3  GV-IPCam H.264 Software  Power Adapter  GV-NVR Software DVD  Warranty Card Note: The power adapter can be excluded upon request.
  • Page 225: Overview

    18.2 Overview 2 3 4 5 6 7 Name Description Plays sounds for tampering and motion alarm, and listens to the audio around the camera. To Speaker set up alarm sound, see Speaker section, Administrator Mode Chapter, GV-IPCAM H.264 Firmware Manual on the Software DVD. PIR sensor Passive infrared sensor.
  • Page 226 Advanced Cube Camera Name Description Stand screw Connects to the Supporting Rack. Power port Connects to the power adapter. Reflects system status of the camera. See the Ready LED below table. Reflects LAN status of the camera. See the below LAN LED table.
  • Page 227: Installation

    18.3 Installation Follow the steps below to install, connect to and adjust your Advanced Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws. Screw the camera onto the supporting rack and fasten the indicated screw.
  • Page 228 Advanced Cube Camera Adjust the angle of the camera based on live view and fasten the indicated screw. For GV-CAW120/220, to connect to the Internet through wireless service, follow the steps in 21.2.3 Configuring the Wireless Connection in the Quick Start Guide.
  • Page 229: Connecting The Camera

    18.4 Connecting the Camera Use a standard network cable to connect the camera to your network. Connect power using one of the following methods:  Plug the power adapter to the power port.  Use the Power over Ethernet (PoE) function and the power will be provided over the network cable.
  • Page 230: Camera

    PT Camera 19. PT Camera 19.1 Packing List  GV-PT130D/220D/320D  Mounting Base  Mounting Cover  Wall Mount Bracket  Screw Anchor x 3  Long Screw x 3  Short Screw x 3  Round Screw x 3...
  • Page 231  Terminal Block  Washer x 3  Power Adapter  GV-IPCAM H.264 Software  GV-NVR Software DVD  Warranty Card Note: The power adapter can be excluded upon request.
  • Page 232: Overview

    PT Camera 19.2 Overview 6 7 8...
  • Page 233 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN / PoE Connects to a 10/100 Ethernet or PoE. Connects to I/O terminal device. For details, see I/O Terminal Block, PTZ I/O Terminal Block Camera Chapter, GV-IPCAM H.264 Firmware Manual on the Software DVD.
  • Page 234: Installation

    PT Camera 19.3 Installation The GV-PT series is designed for indoor usage. Make sure that the installing location is shielded from rain and moisture. There are two ways to install the camera: Ceiling Mount and L-Shaped Wall Mount. 19.3.1 Ceiling Mount Use the mounting base to make 3 marks on the wall for screw anchors.
  • Page 235 Fix the mounting base (now with the PT Camera attached) to the wall with 3 long screws. Put on the mounting cover. To fit the installation environment, you can cut the parts indicated by arrows to make an opening for wires and cables.
  • Page 236: L-Shaped Wall Mount

    PT Camera 19.3.2 L-Shaped Wall Mount You may wall-mount the GV-PT series with or without the mounting cover. Take the wall mount bracket and make 2 marks on the wall for screw anchors. wall Drill the marks and insert 2 screw anchors. Insert the long screws and leave enough distance (approximately 2 mm) to hang the wall mount bracket later.
  • Page 237 Hang the wall mount bracket on the screws and push the wall mount bracket downward. Make sure the long screws are tightened. Without Mounting Cover Attach the wall mount bracket with the PT Camera using 3  washers and 3 round screws. Screw Washer...
  • Page 238 PT Camera With Mounting Cover To install the mounting cover, attach the mounting base to the  camera and then put on the mounting cover. See steps 3 and 5 in 19.3.1 Ceiling Mount. Attach the wall mount bracket with the PT Camera using 3 round ...
  • Page 239: Connecting The Camera

    19.4 Connecting the Camera Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Connect power using one of the following methods:  plugging the power adapter to the power port. ...
  • Page 240: Pinhole Camera

    Pinhole Camera 20. Pinhole Camera 20.1 Packing List  Pinhole Camera  1 m (3.28 ft) RJ-12 Cable  Camera Adhesive Tape x 2  Installation Sticker  Main Body Mount  Main Body Adhesive Tape...
  • Page 241  M3 Screw x 2  M2 Screw  GV-IPCAM H.264 Software  GV-NVR Software DVD  Warranty Card...
  • Page 242: Overview

    Pinhole Camera 20.2 Overview Camera Lens Main Body...
  • Page 243 Name Description Lens Receives images. Microphone Receives sounds. Lens Screw Loosens to adjust the camera lens. Use the supplied RJ12 cable to connect RJ12 Port the camera lens and main body. Turns on (green) when the camera lens RJ12 Status LED and main body are connected.
  • Page 244: Installation

    Pinhole Camera 20.3 Installation The Pinhole Camera is designed for indoors. You can install the camera lens behind a wall or the ceiling board. Note that the thickness of the wall or ceiling board must be less than 4 mm. Paste the installation sticker on the ceiling or the wall where you want to install the camera lens.
  • Page 245 Paste one of the supplied camera adhesive tapes onto the camera lens. Remove the backing paper on the other side of the adhesive tape and attach the camera lens onto the wall or ceiling. The arrows on the camera lens point toward the top of the camera view.
  • Page 246 Pinhole Camera Loosen the lens screw and adjust the position of the lens so that the metal ring is pressing against the wall or ceiling. Metal ring Lens screw Place the main body mount where you want to install it, and secure the mount using one of the methods below.
  • Page 247 Align the main body with the mount as shown below and secure with the supplied M2 screw. Connect the camera lens and the main body using the RJ-12 cable. Connect the main body to the network and supply power via the PoE cable.
  • Page 248: Connecting The Camera

    Pinhole Camera 20.4 Connecting the Camera Use the supplied RJ12 cable to connect the camera lens and the main body. Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided over the network cable. Status LED The status LED of the camera will be on.
  • Page 249: Accessing The Camera

    21. Accessing the Camera 21.1 System Requirement To access the GV-IP Camera through the Web browser, ensure your PC connects to the network properly and meets this system requirement:  Microsoft Internet Explorer 7.x or later Note: For the users of Internet Explorer 8, additional settings are required.
  • Page 250: Accessing The Live View

    Accessing the Camera 21.2 Accessing the Live View Access or configure your camera according to the camera type and its firmware version: Camera Type & Firmware Default Connection Type Version DHCP  GV-IPCAM H.264 with firmware V1.07 or later An unused IP address is automatically (except GV-PT110D assigned by the DHCP server to the and GV-PTZ010D)
  • Page 251: Checking The Dynamic Ip Address

    21.2.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Install the GV-IP Device Utility program included on the GV-IPCAM H.264 software DVD. Note: The PC installed with GV-IP Device Utility must be under the same LAN with the GV-IPCAM H.264 you wish to configure.
  • Page 252 Accessing the Camera Find the camera with its Mac Address, click on its IP address and select Web Page. The login page appears. Type the default ID and password admin and click Apply to log in.
  • Page 253: Configuring The Ip Address

    Click Apply. The camera is now accessible by entering the assigned IP address on the Web browser. To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one-time installation of GeoVision’s ActiveX component onto your computer.
  • Page 254 Accessing the Camera IMPORTANT: If Dynamic IP Address or PPPoE is enabled, you need to know which IP address the camera will get from DHCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP address.
  • Page 255: Configuring The Wireless Connection

    21.2.3 Configuring the Wireless Connection You may create wireless connection to the Internet for GV-BX1200 series / 1300 series / 1500 series / 2400 series / 3400 series / 5300, GV-MFD1501 Series / 2401 series / 3401 series / 5301 series, and GV-CAW120/220. To set up the wireless LAN for the first time, power on and connect a standard network cable to the camera.
  • Page 256 Accessing the Camera D. Select the Authentication Type using the drop-down list. You can also obtain this information by clicking the Access Point Survey button. E. Type the WPA-PSK Pre-shared Key or WEP depending on the encryption setting for the Access Point. Click Apply to save the configuration.
  • Page 257 Enable wireless LAN. On the Web interface, select Network and LAN. This page appears. Select Wireless for Optional Network Type. To use a dynamic IP address assigned by the DHCP server, select Dynamic IP address. To use a fixed IP address, select Static IP address and type the IP address information.
  • Page 258 Accessing the Camera Unplug the Ethernet cable.
  • Page 259: Adjusting Image Clarity

    21.3 Adjusting Image Clarity You can adjust the image clarity using the GV-IP Device Utility. Make sure that you have connected your GV-IPCAM H.264 to the network and install the GV-IP Device Utility program under the same LAN. Note: This feature is only supported by Box Camera, IR Arctic Box Camera, Bullet Camera, Mini Fixed Dome, Mini Fixed Rugged Dome, Target Mini Fixed Dome, Target Mini Fixed Rugged Dome, Vandal Proof IP Dome, and Fixed IP Dome.
  • Page 260 Accessing the Camera Select Focus Value. The Login dialog box appears. Type the user name and password of the camera selected. The default is admin for both user name and password. This window appears. For IK10+ models (GV-VD120D / 121D / 220D / 221D / 320D / 321D / 1500 / 2400 / 3400 / 1530 / 2430 / 2530 / 3430), hold the supplied Focus Adjustment Cap over the camera view.
  • Page 261 For Target Mini Fixed Dome and Target Mini Fixed Rugged Dome, hold the camera cover close to the lens and use the supplied focus adjustment tool for precise focus adjustment. For Mini Fixed Dome and Mini Fixed Rugged Dome, hold the camera cover close to the lens for precise focus adjustment.
  • Page 262: Using Focus Adjustment Cap

    Accessing the Camera 21.3.1 Using Focus Adjustment Cap There are two types of Focus Adjustment Caps for GV-VD120D / 121D / 220D / 221D / 320D / 321D / 1500 / 2400 / 3400 / 1530 / 2430 / 2530 / 3430. Focus Adjustment Cap Type I: Hold the Focus Adjustment Cap on top of the camera view, keep...
  • Page 263: The Web Interface

    22. The Web Interface 12 13...
  • Page 264 The Web Interface No. Name Function Play Plays live video. Stop Stops playing video. Broadcasts to the surveillance site from a remote PC. Note this function is not available for Ultra Bullet Camera and Target Series. For Cube Camera and Advanced Cube Camera, click the Microphone Push to talk button (from the pop-up menu) for the camera to switch between audio transmission and...
  • Page 265 No. Name Function Enables the PTZ Control Panel or the Visual PTZ. PTZ Control Note this function is supported by PTZ Camera and PT Camera, and only partially supported by GV-IP Panel Cameras with motorized varifocal lens. Enables the I/O Control Panel and Visual Automation.
  • Page 266: Upgrading System Firmware

    Upgrading System Firmware 23. Upgrading System Firmware GeoVision periodically releases updated firmware on the website. The new firmware can be simply loaded into the GV-IPCAM H.264 by using the Web interface or IP Device Utility included in the software DVD.
  • Page 267 Click the Upgrade button to start the upgrade. WARNING: The interruption of power supply during updating causes not only update failures but also damages to the camera. In this case, please contact your sales representative and send your device back to GeoVision for repair.
  • Page 268: Restoring To Default Settings

    Restoring to Default Settings 24. Restoring to Default Settings GeoVision periodically releases updated firmware on the website. You can restore factory default settings through the Web interface or directly on the camera. 24.1 Using the Web Interface On the left menu of Web interface, select Management and select Tools.
  • Page 269: Directly On The Camera

    24.2 Directly on the Camera Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Release the default button when the status LED blinks. This shall take about 8 seconds.
  • Page 270: Ultra Box Camera And Target Box Camera

    Restoring to Default Settings Ultra Box Camera and Target Box Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Release the default button when the status LED blinks.
  • Page 271: Mini Fixed Dome

    Mini Fixed Dome Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button.  GV-MFD120 / 130 / 320 Default button Status LED  GV-MFD1501 Series / 2401 Series / 3401 Series / 5301 Series Release the default button when the status LED blinks.
  • Page 272: Mini Fixed Rugged Dome

    Restoring to Default Settings Mini Fixed Rugged Dome Keep the power and network cables connected to the camera. Press and hold the default button. Status LED Default button Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.
  • Page 273: Target Mini Fixed Target Mini Fixed Rugged Dome

    Status LED Default button Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. Target Mini Fixed Target Mini Fixed Rugged Dome Keep the PoE cable connected to the camera.
  • Page 274: Bullet Camera

    Restoring to Default Settings Status LED Status LED When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. Bullet Camera Keep the power and network cables connected to the camera. Loosen the camera’s cover and remove the Silica Gel Bag. Press and hold the default button for 8 seconds.
  • Page 275: Ultra Bullet Camera

    Ultra Bullet Camera Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button. Default button Release the default button when the status LED blinks. This shall take about 8 seconds. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.
  • Page 276: Vandal Proof Ip Dome

    Restoring to Default Settings Release the default button. When the process of loading default settings is completed, the camera reboots automatically. Replace the Silica Gel Tape inside the camera cover and fasten the camera’s cover immediately. Vandal Proof IP Dome Keep the power and network cables (or PoE) connected to the camera.
  • Page 277: Target Vandal Proof Ip Dome

    Target Vandal Proof IP Dome Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button for about 8 seconds. Release the default button when the status LED blinks. Default Status LED When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.
  • Page 278: Fixed Ip Dome

    Restoring to Default Settings Fixed IP Dome Keep the power and network cables (or PoE) connected to the camera. Use a pin to press and hold the default button on the panel. Status LED Default button Release the default button when the status LED blinks. This shall take about 8 seconds.
  • Page 279: Target Fixed Ip Dome

    Target Fixed IP Dome Keep the power and network cables (or PoE) connected to the camera. Press and hold the default button for about 8 seconds. Release the default button when the status LED blinks. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically...
  • Page 280: Cube Camera

    Restoring to Default Settings Cube Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the panel. Default button Status LED Release the default button when status LED blinks. This shall take about 8 seconds.
  • Page 281: Camera

    When the status LED turns green, the process of loading default settings is completed and the camera is ready for use. PT Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the panel. Default button Release the default button when the status LED blinks.
  • Page 282 Restoring to Default Settings Pinhole Camera Keep the PoE cable connected to the main body. Use a pin to press and hold the Load default button on the panel. Status LED Load Default Release the default button when the status LED blinks. This shall take about 8 seconds.
