Ecom j2kn pro Operating Instructions Manual page 12

- Gas analysis
- Mean value
- Draught measure.
- Soot...Oil trace
- Data processing
- Adjustments
- Control
- Diagnosis
If measurements are carried out first the
basic module has to be turned on
(switch below the info display). Select
with the cursor keys the sub-menu
"Gas analysis" and confirm with <OK>.
The instrument starts a 1- minute cali-
bration phase and it enquires if you wish
to use the data bank. If you want to
assign the sampled data to a specific
plant, so press <F1> (<F4> = no:
measurement will be performed without
assignment).
Fuel types acc. to 1
Fuel oil (B)
Natural gas (B)
City gas (B)
Coke oven gas (B)
Liquid gas (B)
Use the cursor keys to select the de-
sired fuel type and confirm with <OK>.
* Country specific fuel types programmable on demand.
Page 12
: Perform gas analysis
: Measurement with mean value calculation
: Perform draught or pressure measurement
: Input of soot measurements results
: Assign measurements / Load or send data
: Modify instrument adjustments
: Check operation state of instrument
: Read-out of firing automats
(only in connection with ecom-AK) /
dT-measurement
st
BImSchV*:
Do you wish to
use the data
processing?
ΟΚ> !
ΟΚ ΟΚ
Quit with: <ΟΚ
YES
Fuel type
Fuel oil (B)
CO2max A1
15.4 0.50
! ! ! !
↑ ↑ ↑ ↑ ↓) ↓) ↓) ↓)
Select: (
ecom-J2KN
NO
B
0.007
pro
