Installation

2.3 Mechanical Installation

2 2

2.3.1 Recommended Tools and Equipment

E E quipment
Screwdrivers
Spanner (Hex)
Slotted
Slotted/Torx
Spanner
Hammer
Drilling machine

2.3.2 Mechanical Dimensions

41
Cable entries, holes sizes (small frame size).
8
inverter.ru (812) 702-47-50
VLT Decentral Drive FCD 302 Operating Instructions
Size Description
8 For fastening screws/mounting
brackets
0.4 x 2.5 For spring loaded power and
control terminals
1.0x5.5/TX20 For cable clamps inside the instal-
lation box
19, 24, 28 For blind-plugs
For knock-out holes (motor mount
version)
For preparing universal adaptor
plate (motor mount version)
331.5
280
6.5
Ø13
315
349.5
ON WARNING ALARM
Bus MS NS1 NS2
MG.04.F2.02 - VLT is a registered Danfoss trademark
Motor side 1xM20, 1xM25
Control side
2xM20, 9xM16
Mains side 2xM25
1)
Also used for 4xM12/6xM12 sensor/acuator sockets.
1)
