Introduction

1.6 Type Code Description

Position 1 2
F C
P P osition Description
01-03 Product group
Frequency
04-06 converter series 302
07-10 Power size
11-12 Phases, Mains
voltage
13-15 Enclosure
16-17 RFI filter
18 Brake
19 Hardware
configuration
inverter.ru (812) 702-47-50
VLT Decentral Drive FCD 302 Operating Instructions
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 39 39
D 3 0 2 P T 4
Choices/options
FCD Decentral Drive
Advanced performance
PK37 0.37kW/0.5HP
PK55 0.55kW/0.75HP
PK75 0.75kW/1.0HP
P1K1 1.1kW/1.5HP
P1K5 1.5kW/2.0HP
P2K2 2.2kW/3.0HP
P3K0 3.0kW/4.0HP
Installation box only
PXXX (without power section)
T Three phase
4 380-480V AC
Standard Black -
B66 IP66/Type 4X
Standard White -
W66 IP66/Type 4X
Hygienic White -
W69 IP66K/Type 4X
H1 RFI filter class A1/C2
X No brake
Brake chopper +
S mechanical brake Supply
Complete product, small
enclosure, stand alone
1 mount
Complete product, small
2 enclosure, motor mount
Complete product, large
enclosure, stand alone
3 mount
Drive part, small enclosure
X (No installation box)
Drive part, large enclosure
Y (No installation box)
Installation box, small
enclosure, stand alone
R mount (No drive part)
Installation box, small
enclosure, motor mount
S (No drive part)
Installation box, large
enclosure, stand alone
T mount (No drive part)
MG.04.F2.02 - VLT is a registered Danfoss trademark
H 1
Position Description
20 Brackets
21 Threads
22 Switch option
23 Display
24 Sensor plugs
25 Motor plug
26 Mains plug
27 Fieldbus plug
28 Reserved
29-30 A option
31-32 B option
33-37 Reserved
38-39 D option
Not all choices/options are available for each FCD 302
variant. To verify if the appropriate version is available,
please consult the Drive Configurator on the internet: http://
driveconfig.danfoss.com.
NOTE
A and D options for FCD 302 are integrated in the control
card and therefore pluggable options for FC-drives can not
be used here. Future retrofit will require exchange of the
entire control card. B options are pluggable, using the same
concept and parts as for FC-drives.
X A B X X X X X D
Choices/options
X No brackets
E Flat brackets
F 40mm brackets
X No installation box
M Metric threads
X No switch option
Service switch on mains
E side
Service switch on motor
F side
No display connector (No
X installation box)
C With Display Connector
X No sensor plugs
E Direct mount 4xM12
F Direct mount 6xM12
X No motor plug
X No mains plug
X No fieldbus plug
X For future use
AX No A option
A0 PROFIBUS DP
AN EtherNet/IP
AL PROFINET
BX No B option
BR Encoder option
BU Resolver option
XXXXX For future use
DX No D option
D0 24 V DC back-up input
