Programming
1 1 -23 Motor Frequency
Range:
1-24 Motor Current
Range:
Size related
*
NOTE
This parameter cannot be adjusted while the motor is
running.
1-25 Motor Nominal Speed
Range:
Size related [100 - 60000
*
RPM]
NOTE
This parameter cannot be adjusted while the motor is
running.
5-12 Terminal 27 Digital Input
Option: Function:
Select the function from the available digital input range.
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC-brake inverse
Stop inverse
Start
Latched start
Reversing
Start reversing
Enable start forward
Enable start reverse
Jog
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
inverter.ru (812) 702-47-50
VLT Decentral Drive FCD 302 Operating Instructions
Function:
Zero Speed to 1-53 Model Shift Frequency.
For 87Hz operation with 230/400V motors,
set the nameplate data for 230V/50Hz.
Adapt 4-13 Motor Speed High Limit [RPM]
and 3-03 Maximum Reference to the 87Hz
application.
Function:
[0.10 - 10000.00 A]
Function:
Enter the nominal motor speed
value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
