Programming
P P ar. Parameter description
No. #
5-6* Pulse Output
5-60 Terminal 27 Pulse Output Variable
5-62 Pulse Output Max Freq #27
5-63 Terminal 29 Pulse Output Variable
5-65 Pulse Output Max Freq #29
5-66 Terminal X30/6 Pulse Output Variable
5-68 Pulse Output Max Freq #X30/6
5-7* 24V Encoder Input
5 5 5-70 Term 32/33 Pulses per Revolution
5-71 Term 32/33 Encoder Direction
5-9* Bus Controlled
5-90 Digital & Relay Bus Control
5-93 Pulse Out #27 Bus Control
5-94 Pulse Out #27 Timeout Preset
5-95 Pulse Out #29 Bus Control
5-96 Pulse Out #29 Timeout Preset
5-97 Pulse Out #X30/6 Bus Control
5-98 Pulse Out #X30/6 Timeout Preset
44
inverter.ru (812) 702-47-50
VLT Decentral Drive FCD 302 Operating Instructions
Default value
null
App.Dependent
null
App.Dependent
null
App.Dependent
1024 N/A
[0] Clockwise
0 N/A
0.00 %
0.00 %
0.00 %
0.00 %
0.00 %
0.00 %
MG.04.F2.02 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups x TRUE
1 set-up x TRUE
All set-ups TRUE
1 set-up TRUE
Conver- Type
sion index
- Uint8
0 Uint32
- Uint8
0 Uint32
- Uint8
0 Uint32
0 Uint16
- Uint8
0 Uint32
-2 N2
-2 Uint16
-2 N2
-2 Uint16
-2 N2
-2 Uint16
