Programming

5 Programming

5.1 Introduction

The frequency converter is programmed for its application
functions using parameters. Parameter are accessed by
pressing either [Quick Menu] or [Main Menu] on the LCP.
(See chapter User Interface for details on using the LCP
function keys.) Parameters may also be accessed through a
5 5
PC using the MCT 10 Set-up Software (see section
5.4.1 Remote Programming with ).
The quick menu is intended for initial start up. Data entered
in a parameter can change the options available in the
parameters following that entry. The quick menu presents
easy guidelines for getting most systems up and running.
The main menu accesses all parameters and allows for
advanced frequency converter applications.

5.2 Quick Setup

0 0 -01 Language
Option:
[0] English
*
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
Svenska
[7] Nederlands
[10] Chinese
Suomi
[22] English US
Greek
Bras.port
Slovenian
32
inverter.ru (812) 702-47-50
VLT Decentral Drive FCD 302 Operating Instructions
Function:
Defines the language to be used in the
display. The frequency converter can be
delivered with 4 different language
packages. English and German are
included in all packages. English cannot
be erased or manipulated.
Part of Language packages 1 - 4
Part of Language packages 1 - 4
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 2
Part of Language package 1
Part of Language package 4
Part of Language package 4
Part of Language package 4
Part of Language package 3
MG.04.F2.02 - VLT is a registered Danfoss trademark
0-01 Language
Option: Function:
Korean Part of Language package 2
Japanese Part of Language package 2
Turkish Part of Language package 4
Trad.Chinese Part of Language package 2
Bulgarian Part of Language package 3
Srpski Part of Language package 3
Romanian Part of Language package 3
Magyar Part of Language package 3
Czech Part of Language package 3
Polski Part of Language package 4
Russian Part of Language package 3
Thai Part of Language package 2
Bahasa Indonesia Part of Language package 2
[52] Hrvatski
1-20 Motor Power [kW]
Range: Function:
Application [Application Enter the nominal motor power in
dependent dependant] kW according to the motor
*
nameplate data. The default value
corresponds to the nominal rated
output of the unit.
This parameter cannot be adjusted
while the motor is running. This
parameter is visible in LCP if
0-03 Regional Settings is Interna-
tional [0].
NOTE
Four sizes down, one size up
from nominal unit rating.
1-22 Motor Voltage
Range:
Size related [10. - 1000. V]
*
1-23 Motor Frequency
Range: Function:
Application [20 - Min - Max motor frequency: 20 - 1000Hz.
dependent 1000 Select the motor frequency value from the
*
Hz] motor nameplate data. If a value different
from 50Hz or 60Hz is selected, it is
necessary to adapt the load independent
settings in 1-50 Motor Magnetisation at
Function:
