Programming
N N OTE
It is important to set motor par. 1-2* correctly, since these
form part of the AMA algorithm. An AMA must be performed
to achieve optimum dynamic motor performance. It may
take up to 10min, depending on the power rating of the
motor.
NOTE
Avoid generating external torque during AMA.
NOTE
5 5
If one of the settings in par. 1-2* is changed, par. 1-30 to par.
1-39, the Advanced Motor Parameters, will return to default
setting.
3-02 Minimum Reference
Range:
Application
dependent dependant]
*
3-03 Maximum Reference
Range:
Application
dependent
*
34
inverter.ru (812) 702-47-50
Function:
[Application Enter the Minimum Reference. The
Minimum Reference is the lowest
value obtainable by summing all
references.
Minimum Reference is active only
when 3-00 Reference Range is set to
Min.- Max. [0].
The Minimum Reference unit
matches:
•
The choice of configuration
in 1-00 Configuration Mode
Configuration Mode: for
Speed closed loop [1], RPM;
for Torque [2], Nm.
•
The unit selected in
3-01 Reference/Feedback
Unit.
Function:
[Application Enter the Maximum Reference. The
dependant] Maximum Reference is the highest
value obtainable by summing all
references.
The Maximum Reference unit
matches:
•
The choice of configuration
in 1-00 Configuration Mode:
for Speed closed loop [1],
RPM; for Torque [2], Nm.
•
The unit selected in
3-00 Reference Range.
MG.04.F2.02 - VLT is a registered Danfoss trademark
VLT Decentral Drive FCD 302 Operating Instructions
3-41 Ramp 1 Ramp up Time
Range:
Application
dependent
3-42 Ramp 1 Ramp Down Time
Range:
Application
dependent
Function:
[Application Enter the ramp-up time, i.e. the
dependant] acceleration time from 0RPM to the
*
synchronous motor speed n
a ramp-up time such that the output
current does not exceed the current
limit in 4-18 Current Limit during
ramping. The value 0.00 corresponds
to 0.01 sec. in speed mode. See ramp-
down time in 3-42 Ramp 1 Ramp Down
Time.
t acc s x n s RPM
Par . 3 − 41 =
Function:
Enter the ramp-down time, i.e. the
[Application deceleration time from the
*
dependant] synchronous motor speed n
Choose a ramp-down time such that
no over-voltage arises in the inverter
due to regenerative operation of the
motor, and such that the generated
current does not exceed the current
limit set in 4-18 Current Limit. The
value 0.00 corresponds to 0.01 s in
speed mode. See ramp-up time in
3-41 Ramp 1 Ramp up Time.
t dec s x n s RPM
Par . 3 − 42 =
. Choose
S
ref RPM
to 0 RPM.
s
ref RPM
