RJ-45 Gigabit Ethernet Connectors
Pin #
Status
Network link is not established
or system powered off
10 Mbps
100 Mbps
1000 Mbps
Board Interfaces
10BASE-T/
100BASE-TX
1 TX+
2 TX-
3 RX+
4 —
5 —
6 RX-
7 —
8 —

Table 4-5: RJ-45 GbE Pin Definitions

Speed
8
Link
Active
Link
Active
Link
Active

Table 4-6: LAN Status LED Definitions

1000BASE-T
LAN_TX0+
LAN_TX0-
LAN_TX1+
LAN_TX2+
LAN_TX2-
LAN_TX1-
LAN_TX3+
LAN_TX3-
Activity
1
Speed LED
(Green/Amber)
Off
Off
Off
Green
Green
Orange
Orange
cPCI-3620
Activity LED
(Yellow)
Off
On
Blinking
On
Blinking
On
Blinking
