Zooming In And Out - Ellisys USB Explorer 350 User Manual

Press PAGE UP to scroll left or PAGE DN to scroll right.
To jump to another location:
1. Press HOME to jump to the start of the trace, or END to jump to the end of the trace.
To define a new timing view origin:
1. Enter a timestamp value in the
The following values are allowed:
s – seconds
ms – milliseconds
ns – nanoseconds
ps – picoseconds
If a unit is not specified, then the previously displayed unit is used.
2. Press ENTER
Instant Timing
The pane is updated with the new origin.
The Analyzer application retains new timing origin entries. Click the Down arrow
field to view and select previously entered timing origin entries.

12.2 Zooming In and Out

Instant Timing
The pane provides a zoom feature to expand or contract the display in order to view information from
a high level or low level. Various display features are enabled or disabled automatically as the user zooms in our out,
such as character-level information and identifiers for packets, commands, and ordered sets.
To use the mouse to zoom:
1. Place the pointer over the
Or
Click on Zoom .
The pointer changes to a spyglass symbol
2. Press and hold the left mouse button and drag the pointer to the right to zoom in and expand the display, or
drag to the left to zoom out and contract the display.
The mouse cursor automatically rolls around the screen, such that the user can smoothly scroll
large amounts of time without having to press and release the mouse button several times.
114 of 157 | Analyzer Instant Timing Pane
origin box.
Zoom
bar, located at the bottom of the display (recommended).
.
in the origin
