S S ettings
Type
TX Count
Sent
L L FP S Settings
tBurst
tRepeat
S S CD Settings
Data
LBPM Settings
Data
LFPS Selects SuperSpeed LFPS cycles for transmission
SCD Selects SuperSpeed Plus SCD patterns for transmission
LBPM Selects SuperSpeed Plus LBPM patterns for transmission
Specifies the number of patterns selected in Type field
to be sent (up to 64K)
Indicates a running count of patterns transmitted
Provides for definition of LFPS tBurst duration
Provides for definition of LFPS tRepeat duration
SCD1 Select SCD1 for transmission (0010)
SCD2 Select SCD1 for transmission (1101)
Other Custom definition for SCD transmission
Phy Cap Select Phy Capabilities for LBPM
Phy Ready Select Phy Ready for LBPM
Other Define custom value for LBPM data
