CONNECTIONS AND MAINTENANCE

■ Mounting the transceiver

The universal mounting bracket supplied with your
transceiver enables overhead or flat mounting.
• Mount the transceiver securely with the 5 supplied (M5 × 20)
screws to a surface that is more than 10 mm thick and can
support more than 5 kg.
• Mount the transceiver so its face is at 90° to your line of
sight when operating.
CAUTION: Keep the transceiver and microphone at least
1 meter (3.3 feet) away from your vessel's magnetic
navigation compass.
NOTE:
• Check the installation angle. The function display may not
be easy to read at some angles.
• When mounting the transceiver on the place that is prone
to strong vibration, use the supplied sponges between the
transceiver and mounting bracket to reduce the vibration.
96
*
Sponges reduce the vibration effects.
See NOTE shown to the left.
Sponge*
