■ Supplied accessories

For the mounting bracket
Mounting bracket
Knob bolts
Screws (M5×20 mm) Spring washers (M5)
Microphone
Screws (5×20 mm) Nuts (M5)
Sponges
Microphone hanger
and screws (3×16 mm)
GPS antenna
DC power cable
(OPC-1174A)*
* 1 Used for the
transceiverʼs
operation check.
(12 V DC only)
Flat washers (M5)
Accessory connectors
6-pin 8-pin
Warning sticker* 2
1
* 2 For only the USA
version.
CONNECTIONS AND MAINTENANCE
D Accessory connectors set up
The accessory connectors are used on the accessory
cables.
* 2
ACC Cable
Solder
Be sure to set this ring to keep the waterproof capability.
* 2
12
These illustrations are for the
8-pin connector.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
