■ NMEA Settings

D NMEA 0183
(NMEA Settings > NMEA 0183)
Select the data transfer speed for each port to receive data
from external devices.
• 4800 bps: Select to receive position data from an external
GPS receiver.
• 38400 bps: Select to receive AIS data from an external AIS
transponder.
D NMEA 2000
(NMEA Settings > NMEA 2000)
NMEA 2000 is a communication standard used to connect
various marine devices and display units in the vessel.
The transceiver can easily connect to a NMEA 2000
network with its plug-and-play functionality, and display the
information provided from the devices on the network.Select
the sensors in NMEA 2000 network which sends data to the
transceiver.
1. Push [MENU].
2. Select "NMEA 2000," then push [ENT].
(NMEA Settings > NMEA 2000)
3. Select the type of data from the menu screen and push
[ENT].
