CH-76
5. Self-Diagnosis
If malfunctions are detected in the system, the tire pressure warning system ECU warns the driver by
illuminating the tire pressure warning light after blinking it at 1 Hz intervals for 1 minute, and stores the DTC
(Diagnostic Trouble Code) in the memory.
The DTC that are stored by the tire pressure warning system ECU can be accessed by connecting the SST
(09843-18040) to the DLC3 terminals TC and CG, and reading the blinking of the tire pressure warning light.
They can also be accessed by connecting a hand-held tester. The table below lists the DTC that pertain to this
system. For further details, see the 2007 Camry Hybrid Vehicle Repair Manual (Pub No. RM02H0U).
Service Tip
After the DTC have been detected, it is necessary to identify the wheel that contains the faulty tire
pressure warning system valve & transmitter. It can be identified by performing the operation in
accordance with the prescribed procedure. For details, see the 2007 Camry Hybrid Vehicle Repair
Manual (Pub. No. RM02H0U).
DTC No.
Tire pressure warning system valve & transmitter ID1
C2111/11
operation stop (sleep mode)
Tire pressure warning system valve & transmitter ID2
C2112/12
operation stop (sleep mode)
Tire pressure warning system valve & transmitter ID3
C2113/13
operation stop (sleep mode)
Tire pressure warning system valve & transmitter ID4
C2114/14
operation stop (sleep mode)
Data from tire pressure warning system valve &
C2121/21
transmitter registered to ID1 not received
Data from tire pressure warning system valve &
C2122/22
transmitter registered to ID2 not received
Data from tire pressure warning system valve &
C2123/23
transmitter registered to ID3 not received
Data from tire pressure warning system valve &
C2124/24
transmitter registered to ID4 not received
A malfunction in the tire pressure warning system valve
C2141/41
& transmitter registered to ID1
A malfunction in the tire pressure warning system valve
C2142/42
& transmitter registered to ID2
A malfunction in the tire pressure warning system valve
C2143/43
& transmitter registered to ID3
A malfunction in the tire pressure warning system valve
C2144/44
& transmitter registered to ID4
C2165/65 Abnormal temperature inside ID1 tire
C2166/66 Abnormal temperature inside ID2 tire
C2167/67 Abnormal temperature inside ID3 tire
C2168/68 Abnormal temperature inside ID4 tire
C2171/71 Tire pressure sensor ID not registered
C2176/76 Tire pressure warning system antenna & receiver is error
C2177/77 Initialization incomplete
CHASSIS - TIRE PRESSURE WARNING SYSTEM
Detection Item DTC Deletion Condition
When data is received from a
t transmitter with an ID code that itt ith ID
is registered in the ECU, or the
ID code of the tire pressure ID code of the tire pressure
warning system valve
transmitter is newly registered in transmitter is newly registered in
the ECU.
When a DTC deletion operation When a DTC deletion operation
is implemented or the ID code of
the tire pressure warning valve the tire pressure warning valve
& transmitter is newly registered
in the ECU. in the ECU.
(Continued)
