Simple Logger
(2-Channel, DC ±100mV / 1V / 10V
Includes USB cable, one 4-position terminal block connector, DataView
AA alkaline batteries and user manual.
Simple Logger
(1-Channel, ±850V
Includes USB cable, DataView
set of alligator clips and user manual.
Simple Logger
(2-Channel, TRMS 600V Voltage Input & 1V Current Probe Input)
Includes USB cable, DataView
set of alligator clips and user manual. Probes purchased separately.
Simple Logger
(2-Channel, Temperature Thermocouple)
Includes USB cable, Thermocouple - Flexible (1M), K Type, -58° to 480° F, DataView
software, 2x1.5V AA alkaline batteries and user manual.
Simple Logger
(2-Channel, Temp/RH Logger)
Includes USB cable, DataView
Simple Logger
(2-Channel, TRMS, MiniFlex
Includes USB cable, DataView
1.4.1 Recommended Probes for Models L101, L102 & L562
AC Current Probe Model MN261
(24A-100mV/A, 240A-10mV/A, BNC)
NOTE: The MN261 current probe should not be used on applications above
10 or 100 Amps (depending on range) when used with either the L101 or L102
data loggers. Clipping of the input signal could result.
AC Current Probe Model SR661
(10A-100mV/A, 100A-10mV/A, 1000A-1mV/A, BNC)
AC Current Probe Model JM861
(30A-10mV/A, 300A-1mV/A, 3000A-0.1mV/A, BNC)
AC Current Probe Model MN379
(5A-200mV/A; 100A-10mV/A, Lead)
Simple Logger II Series
®
II Model L432 ........................................ Cat. #2126.07
®
II Model L481 ........................................ Cat. #2126.25
®
)
DC
software, 2x1.5V AA alkaline batteries, one set of leads, one
®
II Model L562 ........................................ Cat. #2126.35
®
software, 2x1.5V AA alkaline batteries, one set of leads, one
®
II Model L642 ........................................ Cat. #2126.08
®
II Model L702 ........................................ Cat. #2126.09
®
software, 2x1.5V AA alkaline batteries and user manual.
®
II Model ML912 ..................................... Cat. #2126.37
®
100/1000A
®
software, 2x1.5V AA alkaline batteries and user manual.
®
............................................. Cat. #2115.82
............................................... Cat. #2153.01
)
DC
)
AC
.......................... Cat. #2113.49
........................... Cat. #2110.90
software, 2x1.5V
®
®
7
