4.5.7 LEDS

BICU
Number Monitored Signal
LED102 Blinking : Normal
Stays on or off : CPU defective
LED103 Turns on when the main power switch on.
LED104 Blinking : Normal
Stays on or off : HDD abnormal
LED105 Off : Normal
LED106 Blinking : Normal
Paper Feed Board
Number Monitored Signal
LED101 Turns on 500ms interval : Normal (software)
Turns on 200ms interval : Software error is happening
Stays or of off : Paper feed board defective

4.6 SPECIAL TOOLS AND LUBRICANTS

4.6.3 SPECIAL TOOLS

Part Number
A2309352 Flash Memory Card – 4MB
A2309351 Case – Flash Memory Card
A0069104 Scanner Positioning Pin (4 pcs/set)
54209516 Test Chart – OS-A3 (10 pcs/Set)
A0299387 Digital Multimeter – FLUKE 87

4.6.4 LUBRICANTS

Part Number
A0289300 Grease Barrierta JFE 5 5/2
52039502 Silicone Grease G-501
G0049668 Grease: KS660: SHIN ETSU
SM
SPECIAL TOOLS AND LUBRICANTS
Description
Description
4-75
Q'ty
1
1
1
1
1
Q'ty
1
1
1
A229
