Fax

Fax switch

The built-in fax switch enables a single telephone connection to
be used to make phone calls, send and receive faxes and use
extra devices. There are four operating modes. Your machine is
preset to FAX mode.
1
The desired operating mode can be selected using
TEL/FAX/AUTO. Press the button until the desired mode
appears.

TEL mode

In TEL mode your fax machine behaves like a normal tele-
phone. If you receive a fax call (you will hear a high-pitched
tone or nothing at all) you can press START/COPY to start fax
reception. Automatic fax reception is turned off.

FAX mode

In FAX mode the machine rings twice and then answers auto-
matically. This mode is only suitable for fax operation.

AUT mode

In AUT mode your machine will ring up to nine times depend-
ing on the setting and will decide whether the incoming call is a
voice or fax call. Faxes are received automatically.
1
To set the number of rings press MENU, 2, 2, 2. The dis-
play shows "22 AUTO RING CNT".
2
Press START/COPY and enter the desired number of
rings.
3 Press START/COPY and then STOP twice.

TAM mode

(not available in all countries)
In this mode you can connect an external telephone answering
machine.
Note: Ensure that the number of rings is greater than the num-
ber of rings set on the external answering machine.
1 To set the number of rings press MENU, 2, 2, 3.
2
Press START/COPY and enter the desired number of
rings.
3
Press START/COPY and then STOP twice.
Note: If the volume level is set to zero, no ringing tone will be
heard but faxes will still be automatically received.

Fax reception from a different phone

(not available in all countries)
If you pick up another phone and hear a fax call (you will hear a
high-pitched tone or nothing at all) you can start the fax
machine using a code. If this does not work, press
START/COPY on the fax machine.
1 To define the code press MENU, 2, 2, 4. The display
shows "24 REM.FX START".
2
Press START/COPY. Use
"OFF".
3
Press START/COPY and enter the last digit of the code.
This always starts with "*".
4
Press START/COPY and then STOP twice.

Inserting a document

Note: It is best only to use A4 documents (80 g/m
smaller than A5 may jam in the machine.
Note: Do not try to send documents that are...
... damp, coated with correction fluid, dirty or have coated surfaces,
... written on in soft pencil, ink, crayon or charcoal,
... taken from newspaper (printer's ink!),
... held by paper clips or staples; always remove these before faxing,
... wrinkled or torn,
... glued together, too thick or too thin or covered with any adhesive
notes ("Post-It ® " notes),
... made of foil or continuous paper.
1
Place the document face down in the document feeder.
2
Adjust the guides to match the width of the document.

Sending a fax

1
Dial the number.
2
To improve the image quality press RESOLUTION.
3 Press START/COPY.
Transmission starts. If the fax machine is unable to establish a
connection, it will redial automatically after a certain time.
Note: If you wish to cancel automatic redial, press STOP. The
document will be ejected.
Note: If you wish to cancel automatic redial without ejecting
the document, press MENU, 7, 7, 3 and then
START/COPY. Press START/COPY to confirm.
/ to select "ON" or
2 ). Documents
