3.5.

Model Specific Characteristics

3.5.1.

MQ003xG-CM

3.5.1.1.

Sensor and camera parameters

xiQ model
Sensor parameter (*1)
Brand
Color filter
Type
Pixel Resolution (H × V)
Active area size (H × V)
Sensor diagonal
Optical format
Pixel Size (H × V)
ADC resolution
FWC
Dynamic range
SNR Max
Dark noise
Dark current
DSNU
Sensitivity
Camera parameters
Digitization
Supported bit resolutions
Exposure time (EXP)
Variable Gain Range (VGA)
Refresh rate (MRR)
Supported standard readout modes
Power consumption
typical
Maximum
Mechanical
height
width
depth
weight
table 3-6, MQ003xG-CM, sensor and camera parameters
Notes:
(*1) defined for max. bandwidth. By decreasing bandwidth the minimum exposure time and exposure step will
increase
(*2) the maximum frame rate depends on the temperature of the sensor. The sensor manufacturer guarantees only
480 fps at higher sensor temperatures (e.g. 50-70 °C).
xiQ - Technical Manual Version 1.0
MQ003CG-CM
CMV300ES-3E7C1WP
RGB Bayer mosaic
[pixel]
[mm]
[mm]
[inch]
[µm]
[bit]
[ke-]
[dB]
[dB]
[e-]
[e-/s]
[LSB /s]
10
[V/(Lux s)]
[bit]
[bit/pixel]
[dB]
[fps]
Binning/skipping
0 1x1
1 1x1
[W]
[W]
[mm]
[mm]
[mm]
[g]
MQ003MG-CM
CMV300ES-3E7M1WP
None
Global shutter, overlap mode
648 × 488
4.8 × 3.6
5.9
1/3
7.4 × 7.4
10, (12 TBD)
20
60
>40 (TBD)
20 (RMS)
125 (25°C)
3
6
12
8, 10, (12)
7.4µs to 10sec, in steps of 7.4µs (*1)
8.4
90
pixels fps (*2)
648 × 488 548
648 × 488 548
1.2
1.3
26.4
26.4
24.6 (with C/CS Mount module B)
19.6 (without C/CS Mount module B)
26.4 (with C/CS Mount module B)
22.4 (without C/CS Mount module B)
3.4 (board level camera)
Bit/px
8
10
19
