Appendix E. How to use Wake-Up
The ROCKY-3732EVS provides two kind of Wake Up Function.
This page describes how to use Modem Wake-Up and LAN Wake-Up
function.
Wake-Up function is working while you use ATX power supply,
Wake-Up By Modem Ring On:
You must set the option Wake Up On LAN/Ring of CMOS SETUP
to be enabled. The ATX power supply will be switched on when there
is a ring signal detected on pin "RI" of serial port.
Wake-Up On LAN:
You must set the option Wake Up On LAN/Ring of CMOS SETUP
to be enabled. When your computer is in power-down status, you can
see LAN Link/Active LED is flashing. This status indicates that the LAN
chip has entered standby mode and waits for Wake-Up signal. You
can use other computers to wake up your computer by sending ID to it.
ID: ID is the address of your system LAN. Every LAN chip has a
factory-
set ID which you can find it from network information in
WINDOWS.
ID's format is xx-xx-xx-xx-xx-xx
Example ID: 00905C21D4
Function
63
