3.12 CompactFlash Storage Card Socket

The ROCKY-3732EVS configures CompactFlash Storage
Card in IDE Mode(Used IDE 2).
• CN4 : CompactFlash Storage Card Socket pin
assignment
PIN NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
DESCRIPTION
GROUND
D3
D4
D5
D6
D7
CS1#
N/C
GROUND
N/C
N/C
N/C
VCC
N/C
N/C
N/C
N/C
A2
A1
A0
D0
D1
D2
N/C
CARD
DETECT2
PIN NO. DESCRIPTION
26 CARD DETECT1
27 D11
28 D12
29 D13
30 D14
31 D15
32 CS3#
33 N/C
34 IOR#
35 IOW#
36 OBLIGATORY
TO PULL HIGH
37 IRQ15
38 VCC
39 MASTER/SLAVE
40 N/C
41 RESET#
42 IORDY
43 N/C
44 OBLIGATORY
TO PULL HIGH
45 ACTIVE#
46 PDIAG#
47 D8
48 D9
49 D10
50 GROUND
