3.16 LAN RJ45 Connector
ROCKY-3732EVS
10/100Mbps Ethernet Controllers. You can connect it to your
LAN through RJ45 LAN connector. The pin assignments are as
follows:
• CN16/CN18 : LAN RJ45 Connector
PIN NO. DESCRIPTION
1
2
3
4
5
6

3.17 External LED Connector

The LED connector includes SCSI active LED, Ethernet
Link/Active LED and Ethernet speed LED.
CN17 Connector
LED +
2
4
6
8
10
12
Description
Speed LED
Link/Active LED Link Ok
is equipped
TX+
TX-
RX+
N/C
N/C
RX-
2 4 6 8 10 12
¡ ¡ ¡ ¡ ¡ ¡
¨ ¡ ¡ ¡ ¡ ¡
1 3 5 7 9 11
LED -
1 SCSI Port A active
3 SCSI Port B active
5 LAN 2 Link/Active LED
7 LAN 2 Speed LED
9 LAN 1 Link/Active LED
11 LAN 1 Speed LED
LAN LED Description
LED ON LED OFF
100Mbps 10Mbps
Link Fail
with dual
PIN NO. DESCRIPTION
7 N/C
8 N/C
9 Speed +
10 Speed -
11 Active +
12 Active -
LED Function
LED Flashing
NA
Sending or Receiving
23
Intel 82559
