HDD & FDD
When On of HDD & FDD, any activity from one of the listed system peripheral
devices wakes up the system
PCI Master
When On of PCI Master, any activity from one of the listed system peripheral
devices wakes up the system.
Wake Up On LAN/Ring
An input signal on the serial Ring Indicator (RI) line (in other words, an
incoming call on the modem) and LAN WOL awakens the system from a soft
off state.

RTC Alarm Resume

When Enabled, your can set the date and time at which the RTC (real-time
clock) alarm awakens the system from Suspend mode.
The following is a list of IRQ's, Interrupt ReQuests, which can be exempted
much as the COM ports and LPT ports above can. When an I/O device wants
to gain the attention of the operating system, it signals this by causing an IRQ
to occur. When the operating system is ready to respond to the request, it
interrupts itself and performs the service.
When set On, activity will neither prevent the system from going into a power
management mode nor awaken it.
•
Primary INTR
•
IRQ3 (COM 2 )
•
IRQ4 (COM 1)
•
IRQ5 (LPT 2)
•
IRQ6 (Floppy Disk)
•
IRQ7 (LPT 1)
•
IRQ8 (RTC Alarm)
•
IRQ9 (IRQ2 Redir)
•
IRQ10 (Reserved)
•
IRQ11 (Reserved)
•
IRQ12 ( PS / 2 Mouse )
•
IRQ13 (Coprocessor)
•
IRQ14 (Hard Disk)
•
IRQ15 (Reserved)
.
