USB Keyboard Support

Select Enabled if your system contains a Universal Serial Bus (USB)
controller and you have a USB keyboard.
The Choice: Enabled, Disabled.
OnChip Sound
.
This item allows you to control the onboard AC 97 audio
The Choice: Auto, Disabled.

CPU to PCI Write Buffer

When this field is Enabled, writes from the CPU to the PCI bus are buffered,
to compensate for the speed differences between the CPU and the PCI bus.
When Disabled, the writes are not buffered and the CPU must wait until the
write is complete before starting another write cycle.
The Choice: Enabled,Disabled.

PCI Dynamic Bursting

When Enabled, every write transaction goes to the write buffer. Burstable
transactions then burst on the PCI bus and nonburstable transactions don't.
The Choice: Enabled,Disabled.

PCI Master 0 WS Write

When Enabled, writes to the PCI bus are executed with zero wait states.
The Choice: Enabled,Disabled.

PCI Delay Transaction

The chipset has an embedded 32-bit posted write buffer to support delay
transactions cycles. Select Enabled to support compliance with PCI
specification version 2.1.
The Choice: Enabled,Disabled.
PCI#2 Access #1 Retry
When disabled, PCI#2 will not be disconnected until access finishes . When
enabled, PCI#2 will be disconnected if max retries are attempted without
success.
The Choice: Enabled,Disabled.
PCI Latency Timer(Clock)
PCI Latency Timer setting from 0 to 255.
The Choice: 0 - 255.
