3.3 Parallel Port

This port is usually connected to a printer, The ROCKY-3732EVS
includes an on-board parallel port, accessed through a 26-pin flat-
cable connector CN11.
• CN11 : Parallel Port Connector
PIN NO. DESCRIPTION
1 STROBE#
3 DATA 1
5 DATA 3
7 DATA 5
9 DATA 7
11 BUSY
13 PRINTER SELECT
15 ERROR#
17 PRINTER SELECT
LN#
19 GROUND
21 GROUND
23 GROUND
25 GROUND
2 4 6 ... 22 24 26
¡ ¡ ¡ ... ¡ ¡ ¡
¨ ¡ ¡ ... ¡ ¡ ¡
1 3 5 ... 21 23 25
PIN NO. DESCRIPTION
2 DATA 0
4 DATA 2
6 DATA 4
8 DATA 6
10 ACKNOWLEDGE
12 PAPER EMPTY
14 AUTO FORM FEED #
16 INITIALIZE
18 GROUND
20 GROUND
22 GROUND
24 GROUND
26 NC
